Fluo-8H™, AM

U2OS cells were seeded overnight at 40,000 cells per 100 uL per well in a 96-well black all/clear bottom costar plate.  The growth medium was removed, and the cells were incubated with 100 uL of 4 uM Fluo-3 AM, Fluo-4 AM or Fluo-8® AM in HHBS at 37 °C for 1 hour. The cells were washed twice with 200 uL HHBS, then imaged with a fluorescence microscope using FITC channel.
U2OS cells were seeded overnight at 40,000 cells per 100 uL per well in a 96-well black all/clear bottom costar plate.  The growth medium was removed, and the cells were incubated with 100 uL of 4 uM Fluo-3 AM, Fluo-4 AM or Fluo-8® AM in HHBS at 37 °C for 1 hour. The cells were washed twice with 200 uL HHBS, then imaged with a fluorescence microscope using FITC channel.
U2OS cells were seeded overnight at 40,000 cells per 100 uL per well in a 96-well black all/clear bottom costar plate.  The growth medium was removed, and the cells were incubated with 100 uL of 4 uM Fluo-3 AM, Fluo-4 AM or Fluo-8® AM in HHBS at 37 °C for 1 hour. The cells were washed twice with 200 uL HHBS, then imaged with a fluorescence microscope using FITC channel.
Ordering information
Price
Catalog Number
Unit Size
Quantity
Add to cart
Additional ordering information
Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
ShippingStandard overnight for United States, inquire for international
Request quotation
Physical properties
Dissociation constant (Kd, nM)232
Molecular weight1074.98
SolventDMSO
Spectral properties
Correction Factor (260 nm)1.076
Correction Factor (280 nm)0.769
Extinction coefficient (cm -1 M -1)23430
Excitation (nm)495
Emission (nm)516
Quantum yield0.161
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12352200
Related products
Fluo-8®, sodium salt
Fluo-8®, potassium salt
Fluo-8H™, sodium salt
Fluo-8L™, sodium salt
Fluo-8L™, potassium salt
Fluo-8FF™, potassium salt
Chemical Phosphorylation Reagent I (CPR I)
Cell Meter™ Mitochondrial Hydroxyl Radical Detection Kit *Red Fluorescence*
Cal Green™ 1, hexapotassium salt
Cal Green™ 1, AM [Equivalent to Calcium Green-1, AM]
Cal-590™-Dextran Conjugate *MW 3,000*
Cal-590™-Dextran Conjugate *MW 10,000*
Cal-590™ AM
Cal-590™, sodium salt
Cal-590™, potassium salt
Cal-630™ AM
Cal-630™, sodium salt
Cal-630™, potassium salt
Cal-630™-Dextran Conjugate *MW 3,000*
Cal-630™-Dextran Conjugate *MW 10,000*
Fluo-4, Pentapotassium Salt
Cal Red™ R525/650 potassium salt
Cal Red™ R525/650 AM
Cal-520®-Dextran Conjugate *MW 3,000*
Cal-520®-Dextran Conjugate *MW 10,000*
Cal-520®-Biotin Conjugate
Cal-520®-Biocytin Conjugate
Cal-520® NHS Ester
Cal-520® maleimide
Fluo-3, pentasodium salt
Fluo-3, pentapotassium salt
Fluo-3, pentaammonium salt
Fluo-3FF, pentapotassium salt
Cal-520®, AM
Cal-520®, sodium salt
Cal-520®, potassium salt
Cal-520FF™, AM
Cal-520FF™, potassium salt
Screen Quest™ Fluo-8 Medium Removal Calcium Assay Kit *Optimized for Difficult Cell Lines*
Screen Quest™ Fluo-8 No Wash Calcium Assay Kit
Mag-Fluo-4 potassium salt
Mag-Fluo-4 AM
Fluo-2, potassium salt
Fluo-5F, pentapotassium Salt *Cell impermeant*
Fluo-5N, pentapotassium Salt *Cell impermeant*
Cal-520N™, AM
Cal-520N™, potassium salt
Screen Quest™ Fluo-4 No Wash Calcium Assay Kit
Calbryte™ 520 AM
Calbryte™ 520, potassium salt
Calbryte™ 590 AM
Calbryte™ 590, potassium salt
Calbryte™ 630 AM
Calbryte™ 630, potassium salt
Screen Quest™ Calbryte-520 Probenecid-Free and Wash-Free Calcium Assay Kit
Screen Quest™ Calbryte-590 Probenecid-Free and Wash-Free Calcium Assay Kit
Calbryte™-520L AM
Calbryte™-520L, potassium salt
Cal-500™, potassium salt
Cal-500™ AM
Cal-670™, potassium salt
Cal-670™-Dextran Conjugate *MW 3,000*
Cal-670™-Dextran Conjugate *MW 10,000*
Cal-770™, potassium salt
Cal-770™-Dextran Conjugate *MW 3,000*
Cal-770™-Dextran Conjugate *MW 10,000*
Calbryte™-520XL azide
Calbryte™-520XL, potassium salt
Calbryte™-520XL AM
Calbryte™-520XL-Dextran
Cal-520L®-Dextran Conjugate *MW 10,000*
RatioWorks™ Cal-520L®/Cy5-Dextran Conjugate *MW 10,000*
Cal-520L™ maleimide
RatioWorks™ Cal-520®/zFluor 647™ -Dextran Conjugate *MW 10,000*
Cal-590L® Dextran Conjugate *MW 10,000*
RatioWorks™ Cal-590L®/Cy5-Dextran Conjugate *MW 10,000*
Cal-520® amine
Cal-520® azide
Cal-520® alkyne
Show More (69)

OverviewpdfSDSpdfProtocol


Molecular weight
1074.98
Dissociation constant (Kd, nM)
232
Correction Factor (260 nm)
1.076
Correction Factor (280 nm)
0.769
Extinction coefficient (cm -1 M -1)
23430
Excitation (nm)
495
Emission (nm)
516
Quantum yield
0.161
Calcium measurements are critical for numerous biological investigations. Fluorescent probes that show spectral responses upon binding Ca2+ have enabled researchers to investigate changes in intracellular free Ca2+ concentrations by using fluorescence microscopy, flow cytometry, fluorescence spectroscopy, and fluorescence microplate readers. Fluo-3 AM and Fluo-4 AM are most commonly used among the visible light-excitable calcium indicators for live-cell calcium imaging. However, Fluo-3 AM and Fluo-4 AM are only moderately fluorescent in live cells upon esterase hydrolysis and require harsh cell loading conditions to maximize their cellular calcium responses. Fluo-8® dyes are developed to improve cell loading and calcium response while maintaining the convenient Fluo-3 and Fluo-4 spectral wavelengths of Ex/Em = ∼490/∼520 nm. Fluo-8® AM can be loaded into cells at room temperature, while Fluo-3 AM and Fluo-4 AM require 37°C for cell loading. In addition, Fluo-8® AM is two times brighter than Fluo-4 AM and four times brighter than Fluo-3 AM. AAT Bioquest offers a set of our outstanding Fluo-8® reagents with different calcium-binding affinities (Fluo-8® Kd = 389 nM; Fluo-8H™ Kd = 232 nM; Fluo-8L™ Kd = 1.86 µM; Fluo-8FF™ Kd = 10 µM). We also offer versatile packing sizes to meet your special needs (e.g., 1 mg, 10x50 µg, 20x50 µg, and HTS packages) with no additional packaging charge.

Platform


Fluorescence microscope

ExcitationFITC
EmissionFITC
Recommended plateBlack wall/clear bottom

Fluorescence microplate reader

Excitation490
Emission525
Cutoff515
Recommended plateBlack wall/clear bottom
Instrument specification(s)Bottom read mode/Programmable liquid handling

Example protocol


PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles

Fluo-8H™ AM Stock Solution
  1. Prepare a 2 to 5 mM stock solution of Fluo-8H™ AM in high-quality, anhydrous DMSO.

PREPARATION OF WORKING SOLUTION

Fluo-8H™ AM Working Solution
  1. On the day of the experiment, either dissolve Fluo-8H™ AM in DMSO or thaw an aliquot of the indicator stock solution to room temperature.

  2. Prepare a 2 to 20 µM Fluo-8H™ AM working solution in a buffer of your choice (e.g., Hanks and Hepes buffer) with 0.04% Pluronic® F-127. For most cell lines, Fluo-8H™ AM at a final concentration of 4-5 μM is recommended. The exact concentration of indicators required for cell loading must be determined empirically.

    Note: The nonionic detergent Pluronic® F-127 is sometimes used to increase the aqueous solubility of Fluo-8H™ AM. A variety of Pluronic® F-127 solutions can be purchased from AAT Bioquest.

    Note: If your cells contain organic anion-transporters, probenecid (1-2 mM) may be added to the dye working solution (final in well concentration will be 0.5-1 mM) to reduce leakage of the de-esterified indicators. A variety of ReadiUse™ Probenecid products, including water-soluble, sodium salt, and stabilized solutions, can be purchased from AAT Bioquest.

SAMPLE EXPERIMENTAL PROTOCOL

Following is our recommended protocol for loading AM esters into live cells. This protocol only provides a guideline and should be modified according to your specific needs.

  1. Prepare cells in growth medium overnight.
  2. On the next day, add 1X Fluo-8H™ AM working solution to your cell plate.

    Note: If your compound(s) interfere with the serum, replace the growth medium with fresh HHBS buffer before dye-loading.

  3. Incubate the dye-loaded plate in a cell incubator at 37 °C for 30 to 60 minutes.

    Note: Incubating the dye for longer than 2 hours can improve signal intensities in certain cell lines.

  4. Replace the dye working solution with HHBS or buffer of your choice (containing an anion transporter inhibitor, such as 1 mM probenecid, if applicable) to remove any excess probes.
  5. Add the stimulant as desired and simultaneously measure fluorescence using either a fluorescence microscope equipped with a FITC filter set or a fluorescence plate reader containing a programmable liquid handling system such as an FDSS, FLIPR, or FlexStation, at 490/525 nm cutoff 515 nm.

Calculators


Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Fluo-8H™, AM to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

0.1 mg0.5 mg1 mg5 mg10 mg
1 mM93.025 µL465.125 µL930.25 µL4.651 mL9.302 mL
5 mM18.605 µL93.025 µL186.05 µL930.25 µL1.86 mL
10 mM9.302 µL46.512 µL93.025 µL465.125 µL930.25 µL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)Molecular weightVolume (Calculate)Concentration (Calculate)Moles
/=x=

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Correction Factor (260 nm)1.076
Correction Factor (280 nm)0.769
Extinction coefficient (cm -1 M -1)23430
Excitation (nm)495
Emission (nm)516
Quantum yield0.161

Product Family


NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yield
Fluo-8®, AM495516234300.161
Fluo-8L™, AM495516234300.161
Fluo-8FF™, AM495516234300.161
Fluo-4 AM *Ultrapure Grade* *CAS 273221-67-3*495528820000.161
Fluo-3, AM *CAS 121714-22-5*50651586,00010.151
Fluo-3, AM *UltraPure grade* *CAS 121714-22-5*50651586,00010.151
Fluo-3, AM *Bulk package* *CAS 121714-22-5*50651586,00010.151
Fluo-3FF, AM *UltraPure grade* *Cell permeant*50651586,00010.151
Fluo-5F, AM *Cell permeant*494516--
Fluo-5N, AM *Cell permeant*494516--
Show More (1)
