Ac-DEVD-AFC *CAS 201608-14-2*

Chemical structure for Ac-DEVD-AFC *CAS 201608-14-2*
Chemical structure for Ac-DEVD-AFC *CAS 201608-14-2*
Ordering information
Price ()
Catalog Number13401
Unit Size
Find Distributor
Additional ordering information
Telephone1-408-733-1055
Fax1-408-733-1304
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Physical properties
Molecular weight729.61
SolventDMSO
Spectral properties
Extinction coefficient (cm -1 M -1)170001
Excitation (nm)376
Emission (nm)482
Quantum yield0.531
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12352200

OverviewpdfSDSpdfProtocol


CAS
201608-14-2
Molecular weight
729.61
Extinction coefficient (cm -1 M -1)
170001
Excitation (nm)
376
Emission (nm)
482
Quantum yield
0.531
Ac-DEVD-AFC is a fluorogenic substrate for caspase 3, a protease that is rapidly activated when cells are exposed to apoptotic conditions and that cleaves poly(ADP-ribose) polymerase. The 7-amido-4-trifluoromethylcoumarin derivatives have better membrane permeability than the 7-amido-4-methylcoumarin derivatives.

Example protocol


AT A GLANCE

Important notes

It is important to store at <-15 °C and should be stored in cool, dark place.

It can be used within 12 months from the date of receipt.

SAMPLE EXPERIMENTAL PROTOCOL

Following protocol only provides a guideline, and should be modified according to your specific needs.

General Solution Caspase Assays Using AMC, AFC, pNA, R110 and ProRed Substrates

  1. Prepare a 10 mM stock solution in DMSO.

  2. Prepare a 2X caspase substrate (50 µM) assay solution as the following: 50 µL substrate stock solution, 100 µL DTT (1M), 400 µL EDTA (100 mM), 10 mL Tris Buffer (20 mM), pH =7.4.

  3. Mix equal volume of the caspase standards or samples with 2X caspase substrate assay solution, and incubate the solutions at room temperature for at least 1 hour.

  4. Monitor the fluorescence using a fluorescence microplate reader, or absorbance using an absorbance microplate reader.

Cell Caspase Assays Using Cell-Permeable FMK Caspase Probes

  1. Prepare a 2-5 mM stock solution in DMSO.

  2. Treat cells as desired.

  3. Prepare a 2X permeable caspase substrate (20 µM) assay solution by diluting the DMSO stock solution (from Step 2.1) in Hanks with 20 mM Hepes buffer (HHBS).

  4. Mix equal volume of the treated cells with 2X caspase substrate assay solution (from Step 2.3), and incubate the cells in a 37°C, 5% CO2 incubator for at least1 hour.

  5. Wash the cells with HHBS for at least once.

  6. Monitor the fluorescence intensity by a flow cytometer, a fluorescence microscope or a fluorescence microplate reader.

Cell Caspase Assays Using Cell-Permeable FMK Caspase Probes (For #13470-13476 only)

  1. Prepare a 250X stock solution by adding 50 µL DMSO into the vial.

  2. Treat cells as desired.

  3. Add 250 X DMSO stock solution into the cell solution at a 1:250 ratio (such as 2 µL to 500 µL cells), and incubate the cells in a 37°C, 5% CO2 incubator for 1 hour.

  4. Wash the cells with HHBS for at least once.

  5. Monitor the fluorescence intensity by flow cytometer, fluorescence microscopy or fluorescent microplate reader.

Calculators


Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Ac-DEVD-AFC *CAS 201608-14-2* to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

0.1 mg0.5 mg1 mg5 mg10 mg
1 mM137.06 µL685.298 µL1.371 mL6.853 mL13.706 mL
5 mM27.412 µL137.06 µL274.119 µL1.371 mL2.741 mL
10 mM13.706 µL68.53 µL137.06 µL685.298 µL1.371 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)Molecular weightVolume (Calculate)Concentration (Calculate)Moles
/=x=

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Extinction coefficient (cm -1 M -1)170001
Excitation (nm)376
Emission (nm)482
Quantum yield0.531

Citations


View all 5 citations: Citation Explorer
Mitophagy regulates mitochondrial network signaling, oxidative stress, and apoptosis during myoblast differentiation
Authors: Baechler, Brittany L and Bloemberg, Darin and Quadrilatero, Joe
Journal: Autophagy (2019): 1606--1619
Structure-dependent induction of apoptosis by hepatotoxic pyrrolizidine alkaloids in the human hepatoma cell line HepaRG: Single versus repeated exposure
Authors: Waizenegger, Julia and Braeuning, Albert and Templin, Markus and Lampen, Alfonso and Hessel-Pras, Stefanie
Journal: Food and Chemical Toxicology (2018)
pH-Assisted surface functionalization of selenium nanoparticles with curcumin to achieve enhanced cancer chemopreventive activity
Authors: Yu, Shaoxuan and Wang, Yanru and Zhang, Wentao and Zhang, Yuhuan and Zhu, Wenxin and Liu, Yingnan and Zhang, Daohong and Wang, Jianlong
Journal: RSC Advances (2016): 72213--72223

References


View all 67 references: Citation Explorer
In vivo and in vitro sensitization of leukemic cells to adriamycin-induced apoptosis by pentoxifylline. Involvement of caspase cascades and IkappaBalpha phosphorylation
Authors: Lerma-Diaz JM, Hern and ez-Flores G, Dominguez-Rodriguez JR, Ortiz-Lazareno PC, Gomez-Contreras P, Cervantes-Munguia R, Scott-Algara D, Aguilar-Lemarroy A, Jave-Suarez LF, Bravo-Cuellar A.
Journal: Immunol Lett (2006): 149
Measurement of two caspase activities simultaneously in living cells by a novel dual FRET fluorescent indicator probe
Authors: Wu X, Simone J, Hewgill D, Siegel R, Lipsky PE, He L.
Journal: Cytometry A (2006): 477
Quantitative measurement of caspase-3 activity in a living starfish egg
Authors: Sakaue M, Motoyama Y, Yamamoto K, Shiba T, Teshima T, Chiba K.
Journal: Biochem Biophys Res Commun (2006): 878
Photoreceptor cell apoptosis induced by the 2-nitroimidazole radiosensitizer, CI-1010, is mediated by p53-linked activation of caspase-3
Authors: Miller TJ, Schneider RJ, Miller JA, Martin BP, Al-Ubaidi MR, Agarwal N, Dethloff LA, Philbert MA.
Journal: Neurotoxicology (2006): 44
Diallyl Trisulfide Induces Apoptosis of Human Gastric Cancer Cell Line MGC803 Through Caspase-3 Pathway.
Authors: Xiao XL, Peng J, Su Q, Xiang SL, Tang GH, Huang YS, Zhou XT.
Journal: Ai Zheng (2006): 1247
Asymmetric dimethylarginine induces apoptosis via p38 MAPK/caspase-3-dependent signaling pathway in endothelial cells
Authors: Jiang DJ, Jia SJ, Dai Z, Li YJ.
Journal: J Mol Cell Cardiol (2006): 529
Multiparameter measurement of caspase 3 activation and apoptotic cell death in NT2 neuronal precursor cells using high-content analysis
Authors: Fennell M, Chan H, Wood A.
Journal: J Biomol Screen (2006): 296
Serofendic acid, a neuroprotective substance derived from fetal calf serum, inhibits mitochondrial membrane depolarization and caspase-3 activation
Authors: Kume T, Taguchi R, Katsuki H, Akao M, Sugimoto H, Kaneko S, Akaike A.
Journal: Eur J Pharmacol (2006): 69
Homogeneous, bioluminescent protease assays: caspase-3 as a model
Authors: O'Brien MA, Daily WJ, Hesselberth PE, Moravec RA, Scurria MA, Klaubert DH, Bulleit RF, Wood KV.
Journal: J Biomol Screen (2005): 137
Caspase-3 activation and induction of PARP cleavage by cyclic dipeptide cyclo(Phe-Pro) in HT-29 cells
Authors: Brauns SC, Dealtry G, Milne P, Naude R, Van de Venter M.
Journal: Anticancer Res (2005): 4197
