Ac-DEVD-AFC *CAS 201608-14-2*
Overview | ![]() ![]() |
See also: Apoptosis and Necrosis, Caspases, Cell Viability Assays, Cellular Processes, Chemical Reagents, Classic Dyes, Coumarins, Enzymes
CAS 201608-14-2 | Molecular weight 729.61 | Extinction coefficient (cm -1 M -1) 170001 | Excitation (nm) 376 | Emission (nm) 482 | Quantum yield 0.531 |
Ac-DEVD-AFC is a fluorogenic substrate for caspase 3, a protease that is rapidly activated when cells are exposed to apoptotic conditions and that cleaves poly(ADP-ribose) polymerase. The 7-amido-4-trifluoromethylcoumarin derivatives have better membrane permeability than the 7-amido-4-methylcoumarin derivatives.
Example protocol
AT A GLANCE
Important notes
It is important to store at <-15 °C and should be stored in cool, dark place.
It can be used within 12 months from the date of receipt.
SAMPLE EXPERIMENTAL PROTOCOL
Following protocol only provides a guideline, and should be modified according to your specific needs.
General Solution Caspase Assays Using AMC, AFC, pNA, R110 and ProRed Substrates
- Prepare a 10 mM stock solution in DMSO.
- Prepare a 2X caspase substrate (50 µM) assay solution as the following: 50 µL substrate stock solution, 100 µL DTT (1M), 400 µL EDTA (100 mM), 10 mL Tris Buffer (20 mM), pH =7.4.
- Mix equal volume of the caspase standards or samples with 2X caspase substrate assay solution, and incubate the solutions at room temperature for at least 1 hour.
- Monitor the fluorescence using a fluorescence microplate reader, or absorbance using an absorbance microplate reader.
Cell Caspase Assays Using Cell-Permeable FMK Caspase Probes
- Prepare a 2-5 mM stock solution in DMSO.
- Treat cells as desired.
- Prepare a 2X permeable caspase substrate (20 µM) assay solution by diluting the DMSO stock solution (from Step 2.1) in Hanks with 20 mM Hepes buffer (HHBS).
- Mix equal volume of the treated cells with 2X caspase substrate assay solution (from Step 2.3), and incubate the cells in a 37°C, 5% CO2 incubator for at least1 hour.
- Wash the cells with HHBS for at least once.
- Monitor the fluorescence intensity by a flow cytometer, a fluorescence microscope or a fluorescence microplate reader.
Cell Caspase Assays Using Cell-Permeable FMK Caspase Probes (For #13470-13476 only)
- Prepare a 250X stock solution by adding 50 µL DMSO into the vial.
- Treat cells as desired.
- Add 250 X DMSO stock solution into the cell solution at a 1:250 ratio (such as 2 µL to 500 µL cells), and incubate the cells in a 37°C, 5% CO2 incubator for 1 hour.
- Wash the cells with HHBS for at least once.
- Monitor the fluorescence intensity by flow cytometer, fluorescence microscopy or fluorescent microplate reader.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of Ac-DEVD-AFC *CAS 201608-14-2* to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 137.06 µL | 685.298 µL | 1.371 mL | 6.853 mL | 13.706 mL |
5 mM | 27.412 µL | 137.06 µL | 274.119 µL | 1.371 mL | 2.741 mL |
10 mM | 13.706 µL | 68.53 µL | 137.06 µL | 685.298 µL | 1.371 mL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Spectrum
Open in Advanced Spectrum Viewer
Spectral properties
Extinction coefficient (cm -1 M -1) | 170001 |
Excitation (nm) | 376 |
Emission (nm) | 482 |
Quantum yield | 0.531 |
Product family
Name | Excitation (nm) | Emission (nm) |
Ac-DEVD-AMC *CAS 169332-61-0* | 341 | 441 |
Ac-DEVD-CHO *CAS 169332-60-9* | - | - |
Ac-DEVD-pNA *CAS 189950-66-1* | - | - |
Ac-IETD-AFC *CAS 211990-57-7* | 376 | 482 |
Z-DEVD-AFC | 376 | 482 |
