Overview

Ex/Em (nm)571/585
Storage Freeze (<-15 °C)
Minimize light exposure
InstrumentsFluorescence microplate reader
Category Neurobiology
Reactive Oxygen Species
Related Redox Enzymes
Myeloperoxidase (MPO), most abundantly present in neutrophils and monocytes, is a green hemoprotein having peroxidase activity. It catalyzes the reaction of hydrogen peroxide and halide ions to form cytotoxic acids and other intermediates; and plays an important role in the oxygen-dependent killing of tumor cells and microorganisms. MPO deficiency is a hereditary deficiency of the enzyme, which predisposes to immune deficiency. There are considerable interests in the development of therapeutic MPO inhibitors. Our Amplite™ Myeloperoxidase Assay Kit provides a quick and sensitive method for the measurement of myeloperoxidase in solution and in cell lysates. It can be performed in a convenient 96-well or 384-well microtiter-plate format and easily adapted to automation without a separation step. The kit uses our Amplite™ Red substrate which enables a dual recordable mode. The signal can be easily read by either a fluorescence microplate reader at Ex/Em = 540/590 nm or an absorbance microplate reader at ~576 nm. With the Amplite™ Myeloperoxidase Assay Kit, we have detected as little as 0.1 mU/ml myeloperoxidase in a 100 µL reaction volume. The kit can be automated for high throughput screenings of MPO inhibitors.




Spectrum Advanced Spectrum Viewer

Sorry, your browser does not support inline SVG. Relative Intensity (%) 100 80 60 40 20 0 Sorry, your browser does not support inline SVG.
Sorry, your browser does not support inline SVG. Sorry, your browser does not support inline SVG.
Move mouse over grid to display wavelength & intensity values.

300
400
500
600
700
800
900
Wavelength (nm)





Protocol


Quick Preview

This protocol only provides a guideline, and should be modified according to your specific needs.
At a glance

Protocol summary

  1. MPO standards or test samples (50 µL)
  2. Add MPO working solution (50 µL)
  3. Incubate at room temperature for 30 - 60 min
  4. Read fluorescence intensity at Ex/Em = 540/590 nm (cut off 570 nm)

Important notes
Thaw all the kit components to room temperature before starting the experiment.

Key parameters
Instrument:Fluorescence microplate reader
Excitation:540 nm
Emission:590 nm
Cutoff:570 nm
Recommended plate:Solid black
Preparation of stock solutions
Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

1. Amplite™ Red stock solution (250X):
Add 40 µL of DMSO (Component E) into the vial of Amplite™ Red substrate (Component A). The stock solution should be used promptly. Note: The Amplite™ Red substrate is unstable in the presence of thiols such as dithiothreitol (DTT) and 2-mercaptoethanol. The final concentration of DTT or 2-mercaptoethanol in the reaction should be no higher than 10 µM. The Amplite™ Red substrate is also unstable at high pH (>8.5). Therefore, the reaction should be performed at pH 7 – 8. The provided assay buffer, pH 7.4, is recommended.

2. H2O2 stock solution (500X, 10 mM):
Add 10 µL of 3% H2O2 (0.88M, Component C) into 870 µL of Assay Buffer (Component B). Note: The diluted H2O2 solution is not stable. The unused portion should be discarded.

3. Myeloperoxidase (MPO) standard solution (200 mU/mL):
Add 50 µL of Assay Buffer (Component B) into the vial of Myeloperoxidase Standard (Component D). Note: One vial contains approximately 5 - 10 mU myeloperoxidase.

Preparation of standard solution
MPO standard

For convenience, use the Serial Dilution Planner: https://www.aatbio.com/tools/serial-dilution/11301

Add 20 µL of 200 mU/mL MPO standard solution into 380 µL of Assay Buffer (Component B) to get 10 mU/mL MPO standard solution (MPO7). Take 10 mU/mL MPO standard solution to perform 1:3 serial dilutions to get remaining serially diluted MPO standards (MPO6 - MPO1).

Preparation of working solution

Add 20 μL of Amplite™ Red Stock Solution (250X) and 10 μL of H2O2 (500X) into 5 mL of Assay Buffer (Component B) to make a total volume of 5.03 mL MPO working solution. Protect from light.

Sample experimental protocol

Table 1. Layout of MPO standards and test samples in a 96-well solid black microplate. MPO= myeloperoxidase standards (MPO1 - MPO7, 0.01 to 10 mU/mL); BL=blank control; TS = test samples.

BL BL TS TS
MPO1 MPO1 ... ...
MPO2 MPO2 ... ...
MPO3 MPO3
MPO4 MPO4
MPO5 MPO5
MPO6 MPO6
MPO7 MPO7

Table 2. Reagent composition for each well. Note that high concentration of MPO may cause reduced fluorescence signal due to the over oxidation of Amplite™ Red substrate (to a non-fluorescent product).

Well Volume Reagent
MPO1 - MPO7 50 µL Serial Dilution (0.01 to 10 mU/mL)
BL 50 µL Assay Buffer (Component B)
TS 50 µL test sample
  1. Prepare myeloperoxidase standards (MPO), blank controls (BL), and test samples (TS) according to the layout provided in Tables 1 and 2. For a 384-well plate, use 25 µL of reagent per well instead of 50 µL.

  2. Add 50 µL of MPO working solution to each well of myeloperoxidase standard, blank control, and test samples to make the total MPO assay volume of 100 µL/well. For a 384-well plate, add 25 µL of MPO working solution into each well instead, for a total volume of 50 µL/well.

  3. Incubate the reaction for 30 to 60 minutes at room temperature, protected from light.

  4. Monitor the fluorescence intensity with a fluorescence plate reader at Excitation = 530 - 570 nm, Emission = 590 - 600 nm (optimal Ex/Em = 540/590 nm, cut off = 570 nm). Note: The contents of the plate can also be transferred to a white clear bottom plate and read by an absorbance microplate reader at the wavelength of 576 ± 5 nm. The absorption detection has lower sensitivity compared to that of the fluorescence reading.
Example data analysis and figures

The reading (RFU) obtained from the blank standard well is used as a negative control. Subtract this value from the other standards' readings to obtain the base-line corrected values. Then, plot the standards' readings to obtain a standard curve and equation. This equation can be used to calculate Myeloperoxidase samples. We recommend using the Online Linear Regression Calculator which can be found at:

https://www.aatbio.com/tools/linear-logarithmic-semi-log-regression-online-calculator/

Figure 1. Myeloperoxidase dose response was measured with Amplite™ Fluorimetric Myeloperoxidase Assay Kit in a 96-well solid black plate using a Gemini fluorescence microplate reader (Molecular Devices).

Disclaimer
AAT Bioquest provides high-quality reagents and materials for research use only. For proper handling of potentially hazardous chemicals, please consult the Safety Data Sheet (SDS) provided for the product. Chemical analysis and/or reverse engineering of any kit or its components is strictly prohibited without written permission from AAT Bioquest. Please call 408-733-1055 or email info@aatbio.com if you have any questions.





References & Citations

The inhibitory effect of dinitrosyl iron complexes (NO donors) on myeloperoxidase activity
Authors: NP Akentieva, NA Sanina, AR Gizatullin, NY Shmatko, NS Goryachev, NI Shkondina, TR Prikhodchenko, SM Aldoshin
Journal: (2017): 389--393
