Fluo-8FF™, AM
Ordering information
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Additional ordering information
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
Quotation | Request |
International | See distributors |
Shipping | Standard overnight for United States, inquire for international |
Physical properties
Dissociation constant (Kd, nM) | 10000 |
Molecular weight | 1082.91 |
Solvent | DMSO |
Spectral properties
Correction Factor (260 nm) | 1.076 |
Correction Factor (280 nm) | 0.769 |
Extinction coefficient (cm -1 M -1) | 23430 |
Excitation (nm) | 495 |
Emission (nm) | 516 |
Quantum yield | 0.161 |
Storage, safety and handling
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
Storage | Freeze (< -15 °C); Minimize light exposure |
UNSPSC | 12352200 |
Related products
Overview | ![]() ![]() |
See also: Calcium Indicators, Chemical Reagents, Classic Dyes, Fluo-8, Fluoresceins, Intracellular Ions, Physiological Probes
Molecular weight 1082.91 | Dissociation constant (Kd, nM) 10000 | Correction Factor (260 nm) 1.076 | Correction Factor (280 nm) 0.769 | Extinction coefficient (cm -1 M -1) 23430 | Excitation (nm) 495 | Emission (nm) 516 | Quantum yield 0.161 |
Calcium measurements are critical for numerous biological investigations. Fluorescent probes that show spectral responses upon binding Ca2+ have enabled researchers to investigate changes in intracellular free Ca2+ concentrations by using fluorescence microscopy, flow cytometry, fluorescence spectroscopy, and fluorescence microplate readers. Fluo-3 AM and Fluo-4 AM are most commonly used among the visible light-excitable calcium indicators for live-cell calcium imaging. However, Fluo-3 AM and Fluo-4 AM are only moderately fluorescent in live cells upon esterase hydrolysis and require harsh cell loading conditions to maximize their cellular calcium responses. Fluo-8® dyes are developed to improve cell loading and calcium response while maintaining the convenient Fluo-3 and Fluo-4 spectral wavelengths of Ex/Em = ∼490/∼520 nm. Fluo-8® AM can be loaded into cells at room temperature, while Fluo-3 AM and Fluo-4 AM require 37°C for cell loading. In addition, Fluo-8® AM is two times brighter than Fluo-4 AM and four times brighter than Fluo-3 AM. AAT Bioquest offers a set of our outstanding Fluo-8® reagents with different calcium-binding affinities (Fluo-8® Kd = 389 nM; Fluo-8H™ Kd = 232 nM; Fluo-8L™ Kd = 1.86 µM; Fluo-8FF™ Kd = 10 µM). We also offer versatile packing sizes to meet your special needs (e.g., 1 mg, 10x50 µg, 20x50 µg, and HTS packages) with no additional packaging charge.
Platform
Fluorescence microscope
Excitation | FITC |
Emission | FITC |
Recommended plate | Black wall/clear bottom |
Fluorescence microplate reader
Excitation | 490 |
Emission | 525 |
Cutoff | 515 |
Recommended plate | Black wall/clear bottom |
Instrument specification(s) | Bottom read mode/Programmable liquid handling |
Example protocol
PREPARATION OF STOCK SOLUTIONS
Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.
Fluo-8FF™ AM Stock Solution
Prepare a 2 to 5 mM stock solution of Fluo-8FF™ AM in high-quality, anhydrous DMSO.PREPARATION OF WORKING SOLUTION
Fluo-8FF™ AM Working Solution
On the day of the experiment, either dissolve Fluo-8FF™ AM in DMSO or thaw an aliquot of the indicator stock solution to room temperature. Prepare a dye working solution of 2 to 20 µM in a buffer of your choice (e.g., Hanks and Hepes buffer) with 0.04% Pluronic® F-127. For most cell lines, Fluo-8FF™ AM at a final concentration of 4-5 μM is recommended. The exact concentration of indicators required for cell loading must be determined empirically.Note The nonionic detergent Pluronic® F-127 is sometimes used to increase the aqueous solubility of Fluo-8FF™ AM. A variety of Pluronic® F-127 solutions can be purchased from AAT Bioquest.
Note If your cells contain organic anion-transporters, probenecid (1-2 mM) may be added to the dye working solution (final in well concentration will be 0.5-1 mM) to reduce leakage of the de-esterified indicators. A variety of ReadiUse™ probenecid products, including water-soluble, sodium salt, and stabilized solution, can be purchased from AAT Bioquest.
SAMPLE EXPERIMENTAL PROTOCOL
Following is our recommended protocol for loading AM esters into live cells. This protocol only provides a guideline and should be modified according to your specific needs.
- Prepare cells in growth medium overnight.
- On the next day, add 1X Fluo-8FF™ AM working solution into your cell plate.
Note If your compound(s) interfere with the serum, replace the growth medium with fresh HHBS buffer before dye-loading. - Incubate the dye-loaded plate in a cell incubator at 37 °C for 30 to 60 minutes.
Note Incubating the dye for longer than 2 hours can improve signal intensities in certain cell lines. - Replace the dye working solution with HHBS or buffer of your choice (containing an anion transporter inhibitor, such as 1 mM probenecid, if applicable) to remove any excess probes.
- Add the stimulant as desired and simultaneously measure fluorescence using either a fluorescence microscope equipped with a FITC filter set or a fluorescence plate reader containing a programmable liquid handling system such as an FDSS, FLIPR, or FlexStation, at 490/525 nm cutoff 515 nm.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of Fluo-8FF™, AM to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 92.344 µL | 461.719 µL | 923.438 µL | 4.617 mL | 9.234 mL |
5 mM | 18.469 µL | 92.344 µL | 184.688 µL | 923.438 µL | 1.847 mL |
10 mM | 9.234 µL | 46.172 µL | 92.344 µL | 461.719 µL | 923.438 µL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Spectrum
Open in Advanced Spectrum Viewer


Spectral properties
Correction Factor (260 nm) | 1.076 |
Correction Factor (280 nm) | 0.769 |
Extinction coefficient (cm -1 M -1) | 23430 |
Excitation (nm) | 495 |
Emission (nm) | 516 |
Quantum yield | 0.161 |
Product Family
Name | Excitation (nm) | Emission (nm) | Extinction coefficient (cm -1 M -1) | Quantum yield |
Fluo-8®, AM | 495 | 516 | 23430 | 0.161 |
Fluo-8H™, AM | 495 | 516 | 23430 | 0.161 |
Fluo-8L™, AM | 495 | 516 | 23430 | 0.161 |
Fluo-4 AM *Ultrapure Grade* *CAS 273221-67-3* | 495 | 528 | 82000 | 0.161 |
Fluo-3, AM *CAS 121714-22-5* | 506 | 515 | 86,0001 | 0.151 |
Fluo-3, AM *UltraPure grade* *CAS 121714-22-5* | 506 | 515 | 86,0001 | 0.151 |
Fluo-3, AM *Bulk package* *CAS 121714-22-5* | 506 | 515 | 86,0001 | 0.151 |
Fluo-3FF, AM *UltraPure grade* *Cell permeant* | 506 | 515 | 86,0001 | 0.151 |
Fluo-5F, AM *Cell permeant* | 494 | 516 | - | - |
Show More (2) |
Images

Figure 1. U2OS cells were seeded overnight at 40,000 cells per 100 uL per well in a 96-well black all/clear bottom costar plate. The growth medium was removed, and the cells were incubated with 100 uL of 4 uM Fluo-3 AM, Fluo-4 AM or Fluo-8® AM in HHBS at 37 °C for 1 hour. The cells were washed twice with 200 uL HHBS, then imaged with a fluorescence microscope using FITC channel.
