FluoroQuest™ Mounting Medium with DAPI

HeLa cells were stained with mouse anti-tubulin and then followed with iFluor<sup>TM</sup> 610 goat anti-mouse IgG (H+L). Cells were mounted in FluoroQuest™ Mounting Medium with DAPI (Cat# 20004).

Western corn rootworm midgut morphology after feeding with Vpb4Da2. Vpb4Da2 staining by Alexa-fluor-488 conjugated secondary antibody is in green. Nuclei staining by DAPI is in blue. (A) Longitudinal section of the midgut after 6 h exposure to Vpb4Da2. (B) Cross section after 48 h exposure to Vpb4Da2. (C) Cross section after 96 h exposure to Vpb4Da2. (A) and (B) White arrows indicate blebbing of the epithelial cells. (A), (B) and (C) White arrowheads designate a complete or near complete loss of the apical microvilli layer. (D), (E), and (F) Are untreated controls where black arrowheads indicate the intact apical microvilli layer. Scale bars are all 50 μm.
Source: <b>Structural and functional insights into the first Bacillus thuringiensis vegetative insecticidal protein of the Vpb4 fold, active against western corn rootworm</b> by
Kouadio JL, Zheng M, Aikins M, Duda D, Duff S, et al. <em>PLOS ONE</em> Dec. 2021.

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
Quotation	Request
International	See distributors
Shipping	Standard overnight for United States, inquire for international

Physical properties

Solvent

Water

Spectral properties

Extinction coefficient (cm ^-1 M ^-1)	27000
Excitation (nm)	359
Emission (nm)	457

Storage, safety and handling

H-phrase	H303, H313, H340
Hazard symbol	T
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R68
Storage	Refrigerated (2-8 °C); Minimize light exposure
UNSPSC	12352200

Overview SDS Protocol

Extinction coefficient (cm ^-1 M ^-1)

27000

Excitation (nm)

359

Emission (nm)

457

FluoroQuest™ with DAPI is an aqueous mounting medium for preserving fluorescence of tissue and cell smears. This mounting medium is fortified with DAPI which is a counterstain for DNA. For use in in situ hybridization techniques or other methods where fluorescence of DNA staining is required. DAPI excites at 360 nm and emits at 460 nm, producing a blue fluorescence. RNA is also stained with DAPI.

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Extinction coefficient (cm ^-1 M ^-1)	27000
Excitation (nm)	359
Emission (nm)	457

Images

Figure 1. HeLa cells were stained with mouse anti-tubulin and then followed with iFluor^TM 610 goat anti-mouse IgG (H+L). Cells were mounted in FluoroQuest™ Mounting Medium with DAPI (Cat# 20004).

Figure 2. Chemical structure for FluoroQuest™ Mounting Medium with DAPI

Figure 3. Western corn rootworm midgut morphology after feeding with Vpb4Da2. Vpb4Da2 staining by Alexa-fluor-488 conjugated secondary antibody is in green. Nuclei staining by DAPI is in blue. (A) Longitudinal section of the midgut after 6 h exposure to Vpb4Da2. (B) Cross section after 48 h exposure to Vpb4Da2. (C) Cross section after 96 h exposure to Vpb4Da2. (A) and (B) White arrows indicate blebbing of the epithelial cells. (A), (B) and (C) White arrowheads designate a complete or near complete loss of the apical microvilli layer. (D), (E), and (F) Are untreated controls where black arrowheads indicate the intact apical microvilli layer. Scale bars are all 50 μm. Source: Structural and functional insights into the first Bacillus thuringiensis vegetative insecticidal protein of the Vpb4 fold, active against western corn rootworm by Kouadio JL, Zheng M, Aikins M, Duda D, Duff S, et al. PLOS ONE Dec. 2021.
