iFluor® 450 Styramide *Superior Replacement for Opal Polaris 480*

Power Styramide™ Signal Amplification (PSA™) system is one of the most sensitive methods that can detect extremely low-abundance targets in cells and tissues with improved fluorescence signal 10-50 times higher than the widely used tyramide (TSA) reagents. In combination with our superior iFluor® dyes that have higher florescence intensity, increased photostability and enhanced water solubility, the iFluor® dye-labeled Styramide™ conjugates can generate fluorescence signal with significantly higher precision and sensitivity (more than 100 times) than standard ICC/IF/IHC. PSA utilizes the catalytic activity of horseradish peroxidase (HRP) for covalent deposition of fluorophores in situ. PSA radicals have much higher reactivity than tyramide radicals, making the PSA system much faster, more robust and sensitive than the traditional TSA reagents. Compared to tyramide reagents, the Styramide™ conjugates have ability to label the target at higher efficiency and thus generate significantly higher fluorescence signal. Styramide™ conjugates also allow significantly less consumption of primary antibody compared to standard directly conjugate method or tyramide amplification with the same level of sensitivity. iFluor® 450 Styramide is optimized to be alternative to Opal Polaris 480 or other spectrally similar fluorescent tyramide conjugates or TSA reagents.

Example protocol

AT A GLANCE

Protocol Summary
  1. Fix/permeabilize/block cells or tissue
  2. Add primary antibody in blocking buffer
  3. Add HRP-conjugated secondary antibody
  4. Prepare Styramide™ working solution and apply in cells or tissue for 5-10 minutes at room temperature

PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles

Styramide™ stock solution (100X)

Add 100 µL of DMSO into the vial of iFluor® 514 Styramide conjugate to make 100X Styramide stock solution.

Note: Make single-use aliquots and store unused 100X stock solution at 2-8 °C, protected from light. Avoid repeat freeze-thaw cycles.

Hydrogen peroxide stock solution

Add 10 µL of 3% hydrogen peroxide (not provided) to 90 µL of ddH2O.

Note: Prepare the 100X H2O2 solution fresh on the day of use.

PREPARATION OF WORKING SOLUTION

Styramide™ working solution (1X)

Every 1 mL of Reaction Buffer requires 10 µL of Styramide stock solution and 10 µL of H2O2 stock solution.

Note: The Styramide provided is enough for 100 tests based on 100 µL of Styramide working solution needed per coverslip or per well in a 96-well microplate.

Note: The Styramide working solution must be used within 2 hours after preparation and avoid direct exposure to light.

Secondary antibody-HRP working solution

Make appropriate concentration of secondary antibody-HRP working solution as per the manufacturer's recommendations.

SAMPLE EXPERIMENTAL PROTOCOL

This protocol is applicable for both cells and tissues staining.

Cell fixation and permeabilization
  1. Fix the cells or tissue with 3.7% formaldehyde or paraformaldehyde, in PBS at room temperature for 20 minutes.
  2. Rinse the cells or tissue with PBS twice.
  3. Permeabilize the cells with 0.1% Triton X-100 solution for 1-5 minutes at room temperature.
  4. Rinse the cells or tissue with PBS twice.
Tissue fixation, deparaffinization and rehydration

Deparaffinize and dehydrate the tissue according to the standard IHC protocols. Perform antigen retrieval with the preferred specific solution/protocol as needed. A protocol can be found at:

https://www.aatbio.com/resources/guides/paraffin-embedded-tissue-immunohistochemistry-protocol.html

Peroxidase labeling
  1. Optional: Quench endogenous peroxidase activity by incubating cell or tissue sample in peroxidase quenching solution (such as 3% hydrogen peroxide) for 10 minutes. Rinse with PBS twice at room temperature.
  2. Optional: If using HRP-conjugated streptavidin, it is advisable to block endogenous biotins by biotin blocking buffer.
  3. Block with preferred blocking solution (such as PBS with 1% BSA) for 30 minutes at 4 °C.
  4. Remove blocking solution and add primary antibody diluted in recommended antibody diluent for 60 minutes at room temperature or overnight at 4 °C.
  5. Wash with PBS three times for 5 minutes each.
  6. Apply 100 µL of secondary antibody-HRP working solution to each sample and incubate for 60 minutes at room temperature.

    Note: Incubation time and concentration can be varied depending on the signal intensity.

  7. Wash with PBS three times for 5 minutes each.
Styramide labeling
  1. Prepare and apply 100 µL of Styramide working solution to each sample and incubate for 5-10 minutes at room temperature.

    Note: If you observe a non-specific signal, you can shorten the incubation time with Styramide. You should optimize the incubation period using positive and negative control samples at various incubation time points. Or you can use a lower concentration of Styramide in the working solution.

  2. Rinse with PBS three times.
Counterstain and fluorescence imaging
  1. Counterstain the cell or tissue samples as needed. AAT provides a series of nucleus counterstain reagents as listed in Table 1. Follow the instruction provided with the reagents.
  2. Mount the coverslip using a mounting medium with anti-fading properties.

    Note: To ensure optimal results, it is recommended to use either ReadiUse™ microscope mounting solution (Cat. 20009) or FluoroQuest™ TSA/PSA Antifade Mounting Medium *Optimized for Tyramide and Styramide Imaging* (Cat. 44890) instead of Vectashield® mounting media. There are instances where Vectashield® mounting media may not be suitable for certain TSA/PSA conjugates.

  3. Use the appropriate filter set to visualize the signal from the Styramide labeling.

Table 1. Products recommended for nucleus counterstain.

Cat# Product Name Ex/Em (nm)
17548 Nuclear Blue™ DCS1 350/461
17550 Nuclear Green™ DCS1 503/526
17551 Nuclear Orange™ DCS1 528/576
17552 Nuclear Red™ DCS1 642/660

Spectrum

Product family

NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yieldCorrection Factor (260 nm)Correction Factor (280 nm)
iFluor® 450 maleimide4515024000010.8210.450.27
iFluor® 350 Styramide *Superior Replacement for Alexa Fluor 350 tyramide*3454502000010.9510.830.23
iFluor® 488 Styramide *Superior Replacement for Alexa Fluor 488 tyramide and Opal 520*4915167500010.910.210.11
iFluor® 546 Styramide *Superior Replacement for Alexa Fluor 546 tyramide*54155710000010.6710.250.15
iFluor® 555 Styramide *Superior Replacement for Alexa Fluor 555 tyramide and Opal 570*55757010000010.6410.230.14
iFluor® 568 Styramide *Superior Replacement for Alexa Fluor 568 tyramide*56858710000010.5710.340.15
iFluor® 594 Styramide *Superior Replacement for Alexa Fluor 594 tyramide*58760320000010.5310.050.04
iFluor® 647 Styramide *Superior Replacement for Alexa Fluor 647 tyramide*65667025000010.2510.030.03
iFluor® 680 Styramide *Superior Replacement for Alexa Fluor 680 tyramide and Opal 690*68470122000010.2310.0970.094
iFluor® 700 Styramide *Superior Replacement for Alexa Fluor 700 tyramide*69071322000010.2310.090.04
iFluor® 750 Styramide *Superior Replacement for Alexa Fluor 750 tyramide*75777927500010.1210.0440.039
iFluor® 790 Styramide *Superior Replacement for Alexa Fluor 790 tyramide*78781225000010.1310.10.09
iFluor® 514 Styramide *Superior Replacement for Opal 540*5115277500010.8310.2650.116
iFluor® 532 Styramide5375609000010.6810.260.16
iFluor® 633 Styramide *Superior Replacement for Opal 650*64065425000010.2910.0620.044
iFluor® 440 Styramide4344804000010.6710.3520.229
iFluor® 460 Styramide468493800001~0.810.980.46
iFluor® 610 Styramide61062811000010.8510.320.49
iFluor® 660 Styramide66367825000010.2610.070.08
iFluor® 405 Styramide4034273700010.9110.480.77
iFluor® 450 Tyramide *Superior Replacement for Opal 480*4515024000010.8210.450.27
iFluor® 570 Styramide *Superior Replacement for Alexa Fluor 568 tyramide*55757012000010.581--
iFluor® 670 Styramide *Replacement for Opal 690*67168220000010.5510.030.033
iFluor® 450 acid4515024000010.8210.450.27
Show More (15)

References

View all 1 references: Citation Explorer
A robust multiplex immunofluorescence and digital pathology workflow for the characterisation of the tumour immune microenvironment.
Authors: Viratham Pulsawatdi, Amélie and Craig, Stephanie G and Bingham, Victoria and McCombe, Kris and Humphries, Matthew P and Senevirathne, Seedevi and Richman, Susan D and Quirke, Phil and Campo, Leticia and Domingo, Enric and Maughan, Timothy S and James, Jacqueline A and Salto-Tellez, Manuel
Journal: Molecular oncology (2020): 2384-2402
Page updated on October 10, 2024

Ordering information

Price
Unit size
Catalog Number45010
Quantity
Add to cart

Additional ordering information

Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
Technical SupportContact us
Purchase orderSend to sales@aatbio.com
ShippingStandard overnight for United States, inquire for international
Request quotation

Physical properties

Molecular weight

683.78

Solvent

DMSO

Spectral properties

Correction Factor (260 nm)

0.45

Correction Factor (280 nm)

0.27

Extinction coefficient (cm -1 M -1)

400001

Excitation (nm)

451

Emission (nm)

502

Quantum yield

0.821

Storage, safety and handling

H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22

Storage

Freeze (< -15 °C); Minimize light exposure
UNSPSC12171501

Platform

Fluorescence microscope

ExcitationFITC filter set
EmissionFITC filter set
Recommended plateBlack wall, clear bottom
Fluorescence IHC of formaldehyde-fixed paraffin-embedded tissue. Human lung adenocarcinoma sections were incubated with&nbsp;Mouse mAb EpCAM and then incubated with HRP-labeled Goat anti-mouse IgG secondary antibody followed by iFluor® 450 Styramide&trade; (Cat#45010) stain. Fluorescence images were taken using the FITC filter set.
Fluorescence IHC of formaldehyde-fixed paraffin-embedded tissue. Human lung adenocarcinoma sections were incubated with&nbsp;Mouse mAb EpCAM and then incubated with HRP-labeled Goat anti-mouse IgG secondary antibody followed by iFluor® 450 Styramide&trade; (Cat#45010) stain. Fluorescence images were taken using the FITC filter set.
Fluorescence IHC of formaldehyde-fixed paraffin-embedded tissue. Human lung adenocarcinoma sections were incubated with&nbsp;Mouse mAb EpCAM and then incubated with HRP-labeled Goat anti-mouse IgG secondary antibody followed by iFluor® 450 Styramide&trade; (Cat#45010) stain. Fluorescence images were taken using the FITC filter set.
