iFluor® 450 Tyramide *Superior Replacement for Opal 480*

Fluorescence IHC of formaldehyde-fixed, paraffin-embedded human lung adenocarcinoma positive tissue using iFluor<strong>™</strong> 450 Tyramide. Human lung adenocarcinoma positive tissue sections were stained with Mouse anti-EpCAM or Control Mouse IgG antibody and then incubated with polyHRP-labeled Goat anti-Mouse IgG secondary antibody followed by iFluor® 450 Tyramide™ (Cat#45097).
Fluorescence IHC of formaldehyde-fixed, paraffin-embedded human lung adenocarcinoma positive tissue using iFluor<strong>™</strong> 450 Tyramide. Human lung adenocarcinoma positive tissue sections were stained with Mouse anti-EpCAM or Control Mouse IgG antibody and then incubated with polyHRP-labeled Goat anti-Mouse IgG secondary antibody followed by iFluor® 450 Tyramide™ (Cat#45097).
<strong>Superior sensitivity with iFluor® 450 tyramide.</strong> HeLa cells were incubated with primary anti-tubulin antibodies followed by detection with HRP-Goat anti-Mouse IgG and<strong><em> </em></strong>iFluor® 450 tyramide (Left) or Alexa Fluor® 450 tyramide (Right). Fluorescence images were taken on a Keyence BZ-X710 fluorescence microscope equipped with a FITC filter set.
Ordering information
Price ()
Catalog Number45097
Unit Size
Find Distributor
Additional ordering information
Telephone1-408-733-1055
Fax1-408-733-1304
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Physical properties
Molecular weight625.78
SolventDMSO
Spectral properties
Correction Factor (260 nm)0.45
Correction Factor (280 nm)0.27
Extinction coefficient (cm -1 M -1)400001
Excitation (nm)451
Emission (nm)502
Quantum yield0.821
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12171501
