Mag-Fluo-4 AM

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
Quotation	Request
International	See distributors
Shipping	Standard overnight for United States, inquire for international

Physical properties

Dissociation constant (K_d, nM)	22000
Molecular weight	817.65
Solvent	DMSO

Spectral properties

Extinction coefficient (cm ^-1 M ^-1)	82000
Excitation (nm)	495
Emission (nm)	528
Quantum yield	0.16¹

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
Storage	Freeze (< -15 °C); Minimize light exposure
UNSPSC	12352200

Overview SDS Protocol

Molecular weight

817.65

Dissociation constant (K_d, nM)

22000

Extinction coefficient (cm ^-1 M ^-1)

82000

Excitation (nm)

495

Emission (nm)

528

Quantum yield

0.16¹

The cell-permeant Mag-Fluo-4 AM is an analog of Fluo-4 AM with a Kd for Mg ion of 4.7 mM and a Kd for Ca ion of 22 µM, making it useful as an intracellular Mg ion indicator as well as a low-affinity Ca ion indicator. This low-affinity fluorescent Ca ion indicator has been used to accurately track the kinetics of the spatially averaged free Ca ion transient in skeletal muscle. Mag-fluo-4 yields reliable kinetic information about the spatially averaged free Ca ion transient in skeletal muscle.

Platform

Flow cytometer

Excitation	488 nm laser
Emission	530/30 nm filter
Instrument specification(s)	FITC channel

Fluorescence microscope

Excitation	FITC filter set
Emission	FITC filter set
Recommended plate	Black wall/clear bottom

Fluorescence microplate reader

Excitation	490
Emission	525
Cutoff	515
Recommended plate	Black wall/clear bottom
Instrument specification(s)	Bottom read mode/Programmable liquid handling

Example protocol

PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

Mag-Fluo-4 AM Stock Solution

Prepare a 2 to 5 mM stock solution of Mag-Fluo-4 AM in high-quality, anhydrous DMSO.

PREPARATION OF WORKING SOLUTION

Mag-Fluo-4 AM Working Solution

On the day of the experiment, either dissolve Mag-Fluo-4 AM in DMSO or thaw an aliquot of the indicator stock solution to room temperature. Prepare a dye working solution of 2 to 20 µM in a buffer of your choice (e.g., Hanks and Hepes buffer) with 0.04% Pluronic® F-127. For most cell lines, Mag-Fluo-4 AM at a final concentration of 4 to 5 μM is recommended. The exact concentration of indicators required for cell loading must be determined empirically.
Note The nonionic detergent Pluronic® F-127 is sometimes used to increase the aqueous solubility of Mag-Fluo-4 AM. A variety of Pluronic® F-127 solutions can be purchased from AAT Bioquest.
Note If your cells contain organic anion-transporters, probenecid (1-2 mM) may be added to the dye working solution (final in well concentration will be 0.5-1 mM) to reduce leakage of the de-esterified indicators. A variety of ReadiUse™ probenecid products, including water-soluble, sodium salt, and stabilized solution, can be purchased from AAT Bioquest.

SAMPLE EXPERIMENTAL PROTOCOL

Following is our recommended protocol for loading AM esters into live cells. This protocol only provides a guideline and should be modified according to your specific needs.

Prepare cells in growth medium overnight.
On the next day, add 1X Mag-Fluo-4 AM working solution into your cell plate.
Note If your compound(s) interfere with the serum, replace the growth medium with fresh HHBS buffer before dye-loading.
Incubate the dye-loaded plate in a cell incubator at 37 °C for 30 to 60 minutes.
Note Incubating the dye for longer than 1 hour can improve signal intensities in certain cell lines.
Replace the dye working solution with HHBS or buffer of your choice (containing an anion transporter inhibitor, such as 1 mM probenecid, if applicable) to remove any excess probes.
Add the stimulant as desired and simultaneously measure fluorescence using either a fluorescence microscope equipped with a FITC filter set or a fluorescence plate reader containing a programmable liquid handling system such as an FDSS, FLIPR, or FlexStation, at Ex/Em = 490/525 nm cutoff 515 nm.

Calculators

Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Mag-Fluo-4 AM to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

	0.1 mg	0.5 mg	1 mg	5 mg	10 mg
1 mM	122.302 µL	611.509 µL	1.223 mL	6.115 mL	12.23 mL
5 mM	24.46 µL	122.302 µL	244.603 µL	1.223 mL	2.446 mL
10 mM	12.23 µL	61.151 µL	122.302 µL	611.509 µL	1.223 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)		Molecular weight		Volume (Calculate)		Concentration (Calculate)		Moles
	/		=		x		=

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Extinction coefficient (cm ^-1 M ^-1)	82000
Excitation (nm)	495
Emission (nm)	528
Quantum yield	0.16¹

Images

Figure 1. Chemical structure for Mag-Fluo-4 AM
