NBD-Cl [4-Chloro-7-nitrobenzofurazan] *CAS 10199-89-0*
Ordering information
| Price | |
| Catalog Number | |
| Unit Size | |
| Quantity |
Additional ordering information
| Telephone | 1-800-990-8053 |
| Fax | 1-800-609-2943 |
| sales@aatbio.com | |
| Quotation | Request |
| International | See distributors |
| Shipping | Standard overnight for United States, inquire for international |
Physical properties
| Molecular weight | 199.55 |
| Solvent | DMSO |
Spectral properties
| Extinction coefficient (cm -1 M -1) | 22000 |
| Excitation (nm) | 467 |
| Emission (nm) | 539 |
Storage, safety and handling
| H-phrase | H303, H313, H333 |
| Hazard symbol | XN |
| Intended use | Research Use Only (RUO) |
| R-phrase | R20, R21, R22 |
| Storage | Freeze (< -15 °C); Minimize light exposure |
| UNSPSC | 12171501 |
| Overview |  SDSProtocol |
CAS 10199-89-0 | Molecular weight 199.55 | Extinction coefficient (cm -1 M -1) 22000 | Excitation (nm) 467 | Emission (nm) 539 |
NBD-Cl is widely used to label peptides, proteins, drugs and other biomolecules. It is also a popular derivatizing reagent for HPLC analysis. NBD-Cl is non-fluorescent, and generates fluorescent adducts upon reacting with aliphatic amines or thiol compounds. It reacts with amino groups such as aliphatic amines, amino acids, peptides, and proteins to form highly fluorescent compounds. The NBD-amine adducts have ?ex = 464 nm and ?em = 512 nm in aqueous solutions. The fluorescence spectra of NBD-amine adducts are highly environment-sensitive, the fluorescence intensity decreases significantly in aqueous solutions. NBD-Cl also reacts with thiol group to form fluorescent adducts, but the thiol adducts are much less fluorescent than the amine adducts.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of NBD-Cl [4-Chloro-7-nitrobenzofurazan] *CAS 10199-89-0* to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
| 0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
| 1 mM | 501.128 µL | 2.506 mL | 5.011 mL | 25.056 mL | 50.113 mL |
| 5 mM | 100.226 µL | 501.128 µL | 1.002 mL | 5.011 mL | 10.023 mL |
| 10 mM | 50.113 µL | 250.564 µL | 501.128 µL | 2.506 mL | 5.011 mL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
| Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
| / | = | x | = |
Spectrum
Open in Advanced Spectrum Viewer
Spectral properties
| Extinction coefficient (cm -1 M -1) | 22000 |
| Excitation (nm) | 467 |
| Emission (nm) | 539 |
Product Family
| Name | Excitation (nm) | Emission (nm) | Extinction coefficient (cm -1 M -1) |
| NBD-F [4-Fluoro-7-nitrobenzofurazan] *CAS 29270-56-2* | 467 | 539 | 22000 |
| CL-APC [Cross linked-AlloPhycocyanin] | 651 | 660 | 700000 |
Images
Figure 1. Chemical structure for NBD-Cl [4-Chloro-7-nitrobenzofurazan] *CAS 10199-89-0*
