Phalloidin-iFluor® 633 Conjugate

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
International	See distributors
Bulk request	Inquire
Custom size	Inquire
Shipping	Standard overnight for United States, inquire for international

Physical properties

Molecular weight	1703.99
Solvent	DMSO

Spectral properties

Correction Factor (260 nm)	0.062
Correction Factor (280 nm)	0.044
Extinction coefficient (cm ^-1 M ^-1)	250000¹
Excitation (nm)	640
Emission (nm)	654
Quantum yield	0.29¹

Storage, safety and handling

Certificate of Origin	Download PDF
H-phrase	H301, H311, H331
Hazard symbol	T
Intended use	Research Use Only (RUO)
R-phrase	R23, R24, R25
Storage	Freeze (< -15 °C); Minimize light exposure
UNSPSC	12352200

Overview SDS Protocol

Molecular weight

1703.99

Correction Factor (260 nm)

0.062

Correction Factor (280 nm)

0.044

Extinction coefficient (cm ^-1 M ^-1)

250000¹

Excitation (nm)

640

Emission (nm)

654

Quantum yield

0.29¹

This deep red fluorescent phalloidin conjugate (equivalent to Alexa Fluor® 633-labeled phalloidin) selectively binds to F-actins. Used at nanomolar concentrations, phalloidin derivatives are convenient probes for labeling, identifying and quantitating F-actins in formaldehyde-fixed and permeabilized tissue sections, cell cultures or cell-free experiments. Phalloidin binds to actin filaments much more tightly than to actin monomers, leading to a decrease in the rate constant for the dissociation of actin subunits from filament ends, essentially stabilizing actin filaments through the prevention of filament depolymerization. Moreover, phalloidin is found to inhibit the ATP hydrolysis activity of F-actin. Phalloidin functions differently at various concentrations in cells. When introduced into the cytoplasm at low concentrations, phalloidin recruits the less polymerized forms of cytoplasmic actin as well as filamin into stable "islands" of aggregated actin polymers, yet it does not interfere with stress fibers, i.e. thick bundles of microfilaments. The property of phalloidin is a useful tool for investigating the distribution of F-actin in cells by labeling phalloidin with fluorescent analogs and using them to stain actin filaments for light microscopy. Fluorescent derivatives of phalloidin have turned out to be enormously useful in localizing actin filaments in living or fixed cells as well as for visualizing individual actin filaments in vitro. Fluorescent phalloidin derivatives have been used as an important tool in the study of actin networks at high resolution. AAT Bioquest offers a variety of fluorescent phalloidin derivatives with different colors for multicolor imaging applications.

Example protocol

AT A GLANCE

Protocol Summary

Prepare samples in microplate wells
Remove liquid from samples in the plate
Add Phalloidin-iFluor™ 633 Conjugate solution (100 μL/well)
Stain the cells at room temperature for 20 to 90 minutes
Wash the cells
Examine the specimen under microscope with Cy5 filter

Important Warm the vial to room temperature and centrifuge briefly before opening.

Storage and Handling Conditions

The solution should be stable for at least 6 months if store at -20 °C. Protect the fluorescent conjugates from light, and avoid freeze/thaw cycles.
Note Phalloidin is toxic, although the amount of toxin present in a vial could be lethal only to a mosquito (LD50 of phalloidin = 2 mg/kg), it should be handled with care.

PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

Phalloidin-iFluor™ 633 Conjugate stock solution

Add 30 µL of DMSO into the powder and mix well.

PREPARATION OF WORKING SOLUTION

Phalloidin-iFluor™ 633 Conjugate working solution

Add 1 µL of Phalloidin-iFluor™ 633 Conjugate solution to 1 mL of PBS with 1% BSA.
Note The stock solution of phalloidin conjugate should be aliquoted and stored at -20 °C. protected from light.
Note Different cell types might be stained differently. The concentration of phalloidin conjugate working solution should be prepared accordingly.

SAMPLE EXPERIMENTAL PROTOCOL

Stain the cells

Perform formaldehyde fixation. Incubate cells with 3.0–4.0 % formaldehyde in PBS at room temperature for 10–30 minutes.
Note Avoid any methanol containing fixatives since methanol can disrupt actin during the fixation process. The preferred fixative is methanol-free formaldehyde.
Rinse the fixed cells 2–3 times in PBS.
Optional: Add 0.1% Triton X-100 in PBS into fixed cells for 3 to 5 minutes to increase permeability. Rinse the cells 2–3 times in PBS.
Add 100 μL/well (96-well plate) of Phalloidin-iFluor™ 633 Conjugate working solution into the fixed cells, and stain the cells at room temperature for 20 to 90 minutes.
Rinse cells gently with PBS 2 to 3 times to remove excess phalloidin conjugate before plating, sealing and imaging under microscope with Cy5 filter set.

Calculators

Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Phalloidin-iFluor® 633 Conjugate to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

	0.1 mg	0.5 mg	1 mg	5 mg	10 mg
1 mM	58.686 µL	293.429 µL	586.858 µL	2.934 mL	5.869 mL
5 mM	11.737 µL	58.686 µL	117.372 µL	586.858 µL	1.174 mL
10 mM	5.869 µL	29.343 µL	58.686 µL	293.429 µL	586.858 µL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)		Molecular weight		Volume (Calculate)		Concentration (Calculate)		Moles
	/		=		x		=

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Correction Factor (260 nm)	0.062
Correction Factor (280 nm)	0.044
Extinction coefficient (cm ^-1 M ^-1)	250000¹
Excitation (nm)	640
Emission (nm)	654
Quantum yield	0.29¹

Product Family

Name	Excitation (nm)	Emission (nm)	Extinction coefficient (cm ^-1 M ^-1)	Quantum yield	Correction Factor (260 nm)	Correction Factor (280 nm)
Phalloidin-iFluor® 350 Conjugate	345	450	20000¹	0.95¹	0.83	0.23
Phalloidin-iFluor® 405 Conjugate	403	427	37000¹	0.91¹	0.48	0.77
Phalloidin-iFluor® 488 Conjugate	491	516	75000¹	0.9¹	0.21	0.11
Phalloidin-iFluor® 514 Conjugate	511	527	75000¹	0.83¹	0.265	0.116
Phalloidin-iFluor® 532 Conjugate	537	560	90000¹	0.68¹	0.26	0.16
Phalloidin-iFluor® 555 Conjugate	557	570	100000¹	0.64¹	0.23	0.14
Phalloidin-iFluor® 594 Conjugate	588	604	180000¹	0.53¹	0.05	0.04
Phalloidin-iFluor® 647 Conjugate	656	670	250000¹	0.25¹	0.03	0.03
Phalloidin-iFluor® 680 Conjugate	684	701	220000¹	0.23¹	0.097	0.094
Phalloidin-iFluor® 700 Conjugate	690	713	220000¹	0.23¹	0.09	0.04
Phalloidin-iFluor® 750 Conjugate	757	779	275000¹	0.12¹	0.044	0.039
Phalloidin-iFluor® 790 Conjugate	787	812	250000¹	0.13¹	0.1	0.09
iFluor® 633-streptavidin conjugate	640	654	250000¹	0.29¹	0.062	0.044
Show More (4)

Images

Figure 1. Fluorescence images of HeLa cells stained with Phalloidin-iFluor® 633 Conjugate using fluorescence microscope with a Cy5 filter set. Live cells were stained with mitochondria dye MitoLite™ Green (Cat#22666, Green) and imaged. After fixation in 4% formaldehyde, the cells were labeled with F-actin dye iFluor® 633-Phalloidin (Red) and counterstained with Nuclear Blue™ DCS1 (Cat#17548, Blue).

Figure 2. Chemical structure for Phalloidin-iFluor® 633 Conjugate
