Protonex™ NIR 770 NHS ester

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
International	See distributors
Bulk request	Inquire
Custom size	Inquire
Shipping	Standard overnight for United States, inquire for international

Physical properties

Molecular weight	535.64
Solvent	DMSO

Spectral properties

Excitation (nm)	748
Emission (nm)	769

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
Storage	Freeze (< -15 °C); Minimize light exposure

Overview SDS Protocol

Molecular weight

535.64

Excitation (nm)

748

Emission (nm)

769

Protonex™ NIR 770 NHS ester is the only cell-permeable acidotropic pH dye commercially available for developing NIR pH probes. It is an excellent building block that can be readily used for developing site-specific pH sensors for monitoring pH fluctuation in a spatial environment. It can be readily conjugated to amino-containing biomolecules (such as antibodies, peptides and amino-modified oligos). It easily penetrates live cell membranes, thus can be used for monitoring pH changes in live cells. It is complimentary to CypHer7E that is cell-impermeable, and often used to study most classes of cell surface receptors which internalize into the endocytic pathway when activated by a ligand. Protonex™ NIR 770 NHS ester is a flexible, generic fluorophore that can be coupled to a receptor or epitope tag antibody and monitors neutral to acidic intracellular events. It is one of the very few acidotropic pH probes that exhibit NIR fluorescence.

Calculators

Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Protonex™ NIR 770 NHS ester to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

	0.1 mg	0.5 mg	1 mg	5 mg	10 mg
1 mM	186.693 µL	933.463 µL	1.867 mL	9.335 mL	18.669 mL
5 mM	37.339 µL	186.693 µL	373.385 µL	1.867 mL	3.734 mL
10 mM	18.669 µL	93.346 µL	186.693 µL	933.463 µL	1.867 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)		Molecular weight		Volume (Calculate)		Concentration (Calculate)		Moles
	/		=		x		=

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Excitation (nm)	748
Emission (nm)	769

Images

Figure 1. Image of Hela cells stained with Protonex™ NIR 770 NHS ester. Hela cells were washed 3 times with HH buffer and then incubated with 10 µM of Protonex™ NIR 770 NHS ester in HH buffer for 30 min at 37°C. The cells were then washed 3 times with HH buffer and incubated with HH buffer or pH=5.0 and pH=8.0 buffer (Cat# 21235) containing 10 µM of nigericin for 5 min at 37°C. Images were acquired using a fluorescence microscope equipped with a Cy7 filter set.
