ReadiLink™ iFluor® 488 FISH Fluorescence Imaging Kit

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
International	See distributors
Bulk request	Inquire
Custom size	Inquire
Shipping	Standard overnight for United States, inquire for international

Physical properties

Solvent

Water

Spectral properties

Correction Factor (260 nm)	0.21
Correction Factor (280 nm)	0.11
Extinction coefficient (cm ^-1 M ^-1)	75000¹
Excitation (nm)	491
Emission (nm)	516
Quantum yield	0.9¹

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
Storage	Freeze (< -15 °C); Minimize light exposure

Overview SDS Protocol

Correction Factor (260 nm)

0.21

Correction Factor (280 nm)

0.11

Extinction coefficient (cm ^-1 M ^-1)

75000¹

Excitation (nm)

491

Emission (nm)

516

Quantum yield

0.9¹

Fluorescence in situ hybridization (FISH) technology is an effective tool for detecting specific nucleic acid targets in a biological specimen. Detection of a nucleic acid target in situ is achieved through the hybridization of a fluorescent dye-labeled nucleic acid probe of complementary sequence to the specimen. The Readilink™ iFluor® 488 FISH fluorescence imaging kit is a convenient tool for labeling a target DNA using an iFluor® 488 labeled FISH probe via in situ hybridization. The kit provides Taq DNA polymerase enzyme, which incorporates iFluor® 488-dUTPs in the target DNA through Polymerase Chain Reaction (PCR). Our proprietary iFluor® dyes are brighter and more photostable than traditional fluorescent labels, providing the desired resolution and signal.

Platform

Thermal Cycler

Recommended plate

PCR Microplate

Components

Example protocol

SAMPLE EXPERIMENTAL PROTOCOL

Before using, thaw all components to room temperature and mix thoroughly by vortexing.

Note: The following protocol can be used as a general guideline to standard DNA FISH. Optimization may be necessary for your experimental system.

Prepare the following reaction mixes as indicated in Table 1.

Table 1. Reagents composition per well for each reaction.

Components	Volume (25 µL/reaction)	Final Conc.
FISH Reaction mix (2X)	12.5 µL	1X
Upstream primer, 10 µM	0.25-2.5 µL	0.1-1.0 µM
Downstream primer, 10 µM	0.25-2.5 µL	0.1-1.0 µM
DNA template	1-5 µL	Optimized conc.
iFluor® 488-dUTP	2.5 µL
dNTP mix	1 µL
Water, nuclease-free	25 µL

Carefully mix the reagents by gentle vortexing followed by a brief centrifuge.
Set up the plate in the qPCR instrument and run as indicated in Table 2.

Table 2. Thermal cycling parameters.

Parameter

Polymerase Activation

PCR (30-40 cycles)

Hold

Denature

Anneal

Extend

Temperature

95 °C

95 °C

55-65 °C

68-72 °C

Time (m:ss)

0:20

0:30

1:00

1:00

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Correction Factor (260 nm)	0.21
Correction Factor (280 nm)	0.11
Extinction coefficient (cm ^-1 M ^-1)	75000¹
Excitation (nm)	491
Emission (nm)	516
Quantum yield	0.9¹

Product Family

Name	Excitation (nm)	Emission (nm)	Extinction coefficient (cm ^-1 M ^-1)	Quantum yield	Correction Factor (260 nm)	Correction Factor (280 nm)	Correction Factor (656 nm)
ReadiLink™ iFluor® 555 FISH Fluorescence Imaging Kit	557	570	100000¹	0.64¹	0.23	0.14	-
ReadiLink™ iFluor® 647 FISH Fluorescence Imaging Kit	656	670	250000¹	0.25¹	0.03	0.03	0.0793

Images

Figure 1. Telomere quantitative fluorescence in situ hybridization in metaphase HeLa cells using iFluor® 488-dUTP labeled telomere probes. Probes were created using the ReadiLink™ iFluor® 488 FISH Fluorescence Imaging kit.
