ReadiLink™ Rapid Cy5 Antibody Labeling Kit Microscale Optimized for Labeling 50 μg Antibody Per Reaction

HeLa cells were incubated with (Tubulin+) or without (Tubulin-) mouse anti-tubulin followed by AAT’s Cy5<sup>®</sup> goat anti-mouse IgG conjugate (Red, Left) or Jackson’s Cy5<sup>®</sup> goat anti-mouse IgG conjugate (Red, Right), respectively. Cell nuclei were stained with Hoechst 33342 (Blue, Cat# 17530).

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
International	See distributors
Bulk request	Inquire
Custom size	Inquire
Shipping	Standard overnight for United States, inquire for international

Request quotation

Spectral properties

Correction Factor (260 nm)	0.02
Correction Factor (280 nm)	0.03
Correction Factor (482 nm)	0.009
Correction Factor (565 nm)	0.09
Extinction coefficient (cm ^-1 M ^-1)	250000¹
Excitation (nm)	651
Emission (nm)	670
Quantum yield	0.27¹, 0.4²

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
UNSPSC	12171501

Direct upgrades

ReadiLink™ Rapid iFluor® 647 Antibody Labeling Kit *Microscale Optimized for Labeling 50 μg Antibody Per Reaction*

ReadiLink™ Rapid iFluor® 647 Antibody Labeling Kit *Production Scale*

Alternative formats

ReadiLink™ Rapid Cy5 Antibody Labeling Kit *Production Scale*

Overview SDS Protocol

Upgrade: ReadiLink™ Rapid iFluor® 647 Antibody Labeling Kit *Microscale Optimized for Labeling 50 μg Antibody Per Reaction*, ReadiLink™ Rapid iFluor® 647 Antibody Labeling Kit *Production Scale*

Correction Factor (260 nm)

0.02

Correction Factor (280 nm)

0.03

Correction Factor (482 nm)

0.009

Correction Factor (565 nm)

0.09

Extinction coefficient (cm ^-1 M ^-1)

250000¹

Excitation (nm)

651

Emission (nm)

670

Quantum yield

0.27¹, 0.4²

Cy5 is one of the most popular fluorescent labeling dyes for preparing orange-red fluorescent bioconjugates. However, most of the commercial Cy5 labeling kits require intensive hands-on time. This Cy5 ReadiLink™ labeling kit is one of the most robust protein labeling kits for preparing Cy5-labeled antibody conjugates or other protein conjugates. It essentially only requires 2 simple mixing steps without a column purification required. The kit provides all the essential components for labeling ~2x50 ug antibody. Each of the two vials of Cy5 dye provided in the kit is optimized for labeling ~50 µg antibody. This Cy5 protein labeling kit provides a convenient method to label monoclonal, polyclonal antibodies or other proteins (>10 kDa).

Figure 1. Overview of the ReadiLink™ Rapid Antibody Labeling protocol. In just two simple steps, and with no purification necessary, covalently label microgram amounts of antibodies in under an hour.

Components

Example protocol

AT A GLANCE

Important

Warm all the components and centrifuge the vials briefly before opening, and immediately prepare the required solutions before starting your conjugation. The following protocol is for recommendation.

PREPARATION OF WORKING SOLUTION

Protein working solution (Solution A)

For labeling 50 µg of protein (assuming the target protein concentration is 1 mg/mL), mix 5 µL (10% of the total reaction volume) of Reaction Buffer (Component B) with 50 µL of the target protein solution.
Note     If you have a different protein concentration, adjust the protein volume accordingly to make ~50 µg of protein available for your labeling reaction.
Note     For labeling 100 µg of protein (assuming the target protein concentration is 1 mg/mL), mix 10 µL (10% of the total reaction volume) of Reaction Buffer (Component B) with 100 µL of the target protein solution.
Note     The protein should be dissolved in 1X phosphate buffered saline (PBS), pH 7.2 - 7.4; if the protein is dissolved in glycine buffer, it must be dialyzed against 1X PBS, pH 7.2 - 7.4, or use Amicon Ultra-0.5, Ultracel-10 Membrane, 10 kDa (cat# UFC501008 from Millipore) to remove free amines or ammonium salts (such as ammonium sulfate and ammonium acetate) that are widely used for protein precipitation.
Note     Impure antibodies or antibodies stabilized with bovine serum albumin (BSA) or gelatin will not be labeled well.
Note     For optimal labeling efficiency, a final protein concentration range of 1 - 2 mg/mL is recommended, with a significantly reduced conjugation efficiency at less than 1 mg/mL.

SAMPLE EXPERIMENTAL PROTOCOL

Run conjugation reaction

Add the protein working solution (Solution A) to ONE vial of labeling dye (Component A), and mix them well by repeatedly pipetting for a few times or vortex the vial for a few seconds.
Note If labeling 100 µg of protein, use both vials (Component A) of labeling dye by dividing the 100 µg of protein into 2 x 50 µg of protein and reacting each 50 µg of protein with one vial of labeling dye. Then combine both vials for the next step.
Keep the conjugation reaction mixture at room temperature for 30 - 60 minutes.
Note The conjugation reaction mixture can be rotated or shaken for longer time if desired.

Stop Conjugation reaction

Add 5 µL (for 50 µg protein) or 10 µL (for 100 µg protein) which is 10% of the total reaction volume of TQ™-Dyed Quench Buffer (Component C) into the conjugation reaction mixture; mix well.
Incubate at room temperature for 10 minutes. The labeled protein (antibody) is now ready to use.

Storage of Protein Conjugate

The protein conjugate should be stored at > 0.5 mg/mL in the presence of a carrier protein (e.g., 0.1% bovine serum albumin). For longer storage, the protein conjugates could be lyophilized or divided into single-used aliquots and stored at ≤ –20°C.

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Correction Factor (260 nm)	0.02
Correction Factor (280 nm)	0.03
Correction Factor (482 nm)	0.009
Correction Factor (565 nm)	0.09
Extinction coefficient (cm ^-1 M ^-1)	250000¹
Excitation (nm)	651
Emission (nm)	670
Quantum yield	0.27¹, 0.4²

Product Family

Name	Excitation (nm)	Emission (nm)	Extinction coefficient (cm ^-1 M ^-1)	Quantum yield	Correction Factor (280 nm)	Correction Factor (260 nm)
ReadiLink™ Rapid FITC Antibody Labeling Kit Microscale Optimized for Labeling 50 μg Antibody Per Reaction	491	516	73000	0.92	0.35	-
ReadiLink™ Rapid Cy3 Antibody Labeling Kit Microscale Optimized for Labeling 50 μg Antibody Per Reaction	555	569	150000¹	0.15¹	0.073	0.07
ReadiLink™ Rapid Cy7 Antibody Labeling Kit Microscale Optimized for Labeling 50 μg Antibody Per Reaction	756	779	250000	0.3	0.036	0.05
ReadiLink™ Rapid XFD488 Antibody Labeling Kit XFD488 Same Structure to Alexa Fluor™ 488	490	520	71000	0.92¹	0.11	0.30
ReadiLink™ Rapid XFD555 Antibody Labeling Kit XFD555 Same Structure to Alexa Fluor™ 555	520	568	150000	0.1¹	0.08	0.08
ReadiLink™ Rapid XFD594 Antibody Labeling Kit XFD594 Same Structure to Alexa Fluor™ 594	375	618	90000	0.66¹	0.56	0.43
ReadiLink™ Rapid XFD647 Antibody Labeling Kit XFD647 Same Structure to Alexa Fluor™ 647	604	671	239000	0.33¹	0.03	0.00
ReadiLink™ Rapid XFD750 Antibody Labeling Kit XFD750 Same Structure to Alexa Fluor™ 750	752	776	240000	0.12¹	0.04	0.00
ReadiLink™ Rapid FITC Antibody Labeling Kit Production Scale	491	516	73000	0.92	0.35	-
ReadiLink™ Rapid Cy3 Antibody Labeling Kit Production Scale	555	569	150000¹	0.15¹	0.073	0.07
ReadiLink™ Rapid XFD488 Antibody Labeling Kit Production Scale	490	520	71000	0.92¹	0.11	0.30
ReadiLink™ Rapid XFD555 Antibody Labeling Kit Production Scale	520	568	150000	0.1¹	0.08	0.08
ReadiLink™ Rapid XFD594 Antibody Labeling Kit Production Scale	375	618	90000	0.66¹	0.56	0.43
ReadiLink™ Rapid Cy7 Antibody Labeling Kit Production Scale	756	779	250000	0.3	0.036	0.05
ReadiLink™ Rapid XFD647 Antibody Labeling Kit Production Scale	604	671	239000	0.33¹	0.03	0.00
ReadiLink™ Rapid XFD750 Antibody Labeling Kit Production Scale	752	776	240000	0.12¹	0.04	0.00
Show More (7)

Images

Figure 1. HeLa cells were incubated with (Tubulin+) or without (Tubulin-) mouse anti-tubulin followed by AAT’s Cy5^® goat anti-mouse IgG conjugate (Red, Left) or Jackson’s Cy5^® goat anti-mouse IgG conjugate (Red, Right), respectively. Cell nuclei were stained with Hoechst 33342 (Blue, Cat# 17530).
