SRB-VAD-FMK [Sulforhodamine B-VAD-FMK]

Product Image
Product Image
Gallery Image 1
Ordering information
Price
Catalog Number
Unit Size
Quantity
Add to cart
Additional ordering information
Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Physical properties
Molecular weight874.01
SolventDMSO
Spectral properties
Absorbance (nm)220
Excitation (nm)559
Emission (nm)577
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12352200
Related products
Rhodamine 700 *CAS 63561-42-2*
Rhodamine 800 *CAS 137993-41-0*
Rhodamine B *CAS 81-88-9*
Rhodamine 6G *CAS 989-38-8*
Sulforhodamine 101, sodium salt
Sulforhodamine B *CAS 3520-42-1*
Sulforhodamine G *CAS 5873-16-5*
Rhodamine 101 Inner Salt *CAS 116450-56-7*
Rhodamine 101 Chloride Salt *CAS 64339-18-0*
Sulforhodamine 101 sodium salt *CAS 465544-24-5*
Rhodamine 110 *CAS 13558-31-1*
5-CR110 [5-Carboxyrhodamine 110] *Single isomer*
6-CR110 [6-Carboxyrhodamine 110] *Single isomer*
5(6)-CR6G [5-(and 6)-Carboxyrhodamine 6G]
5-CR6G [5-Carboxyrhodamine 6G] *Single isomer*
6-CR6G [6-Carboxyrhodamine 6G] *Single isomer*
5(6)-CR6G, SE [5-(and 6)-Carboxyrhodamine 6G, succinimidyl ester] *Mixed isomers*
6-CR6G, SE [6-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer*
5(6)-Carboxyrhodamine 6G cadaverine
5(6)-Carboxyrhodamine 6G ethylenediamine
5-CR6G, SE [5-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer*
5(6)-TAMRA [5(6)-Carboxytetramethylrhodamine] *CAS 98181-63-6*
5-TAMRA [5-Carboxytetramethylrhodamine] *CAS 91809-66-4*
6-TAMRA [6-Carboxytetramethylrhodamine] *CAS 91809-67-5*
5(6)-TAMRA, SE [5-(and-6)-Carboxytetramethylrhodamine, succinimidyl ester] *CAS 246256-50-8*
5-TAMRA, SE [5-Carboxytetramethylrhodamine, succinimidyl ester] *CAS#: 150810-68-7*
6-TAMRA, SE [6-Carboxytetramethylrhodamine, succinimidyl ester] *CAS#: 150810-69-8*
5(6)-ROX [5-(and 6)-Carboxy-X-rhodamine] *CAS 198978-94-8*
5-ROX [5-Carboxy-X-rhodamine] *CAS 216699-35-3*
6-ROX [6-Carboxy-X-rhodamine] *CAS 194785-18-7*
5(6)-ROX, SE [5-(and-6)-Carboxy-X-rhodamine, succinimidyl ester] *Mixed isomers*
5-ROX, SE [5-Carboxy-X-rhodamine, succinimidyl ester] *CAS 209734-74-7*
6-ROX, SE [6-Carboxy-X-rhodamine, succinimidyl ester] *CAS#: 216699-36-4*
5(6)-TRITC [Tetramethylrhodamine-5-(and-6)-isothiocyanate] *CAS 95197-95-8*
5(6)-TAMRA Maleimide [Tetramethylrhodamine-5-(and-6)-maleimide] *Mixed isomers*
5-TRITC [Tetramethylrhodamine-5-isothiocyanate] *CAS 80724-19-2*
6-TRITC [Tetramethylrhodamine-6-isothiocyanate] *CAS 80724-20-5*
6-TAMRA Maleimide [Tetramethylrhodamine-6-maleimide] *CAS 174568-68-4*
5-TAMRA Maleimide [Tetramethylrhodamine-5-maleimide] *CAS 154480-30-5*
Lissamine Rhodamine B Sulfonyl Chloride [Sulforhodamine B sulfonyl chloride] *CAS 62796-29-6*
Sulforhodamine 101 sulfonyl chloride [Texas Red®] *CAS 82354-19-6*
Dihydrorhodamine 123 *CAS 109244-58-8*
Tetramethylrhodamine-dUTP *1 mM in Tris Buffer (pH 7.5)*
Rhodamine 123 *CAS 62669-70-9*
Rhodamine B, hexyl ester, perchlorate
TMRE [Tetramethylrhodamine ethyl ester] *CAS#: 115532-52-0*
TMRM [Tetramethylrhodamine methyl ester] *CAS#: 115532-50-8*
Phalloidin-Tetramethylrhodamine Conjugate
5-dR6G [5-Carboxy-4,7-dichlororhodamine 6G]
6-dR6G [6-Carboxy-4,7-dichlororhodamine 6G]
5-dR110 [5-Carboxy-4,7-dichlororhodamine 110]
6-dR110 [6-Carboxy-4,7-dichlororhodamine 110]
Bis-L-Aspartic acid Beta-rhodamine 110
Bis-Arg-rhodamine 110
Sulforhodamine 101 *CAS 60311-02-6*
5-Carboxyrhodamine 6G maleimide
Rhodamine aldehyde [5-TAMRA aldehyde]
Ac-DEVD-AFC *CAS 201608-14-2*
Ac-DEVD-AMC *CAS 169332-61-0*
Ac-DEVD-CHO *CAS 169332-60-9*
Ac-DEVD-pNA *CAS 189950-66-1*
FITC-C6-DEVD-FMK
Ac-IETD-AFC *CAS 211990-57-7*
Ac-IETD-AMC
Ac-IETD-CHO *CAS 191338-86-0*
Z-IETD-pNA *CAS 219138-21-3*
Z-DEVD-AFC
Z-DEVD-AMC
Z-DEVD-pNA
Z-IETD-AFC *CAS 219138-02-0*
(Z-DEVD)2-R110
(Ac-IETD)2-R110
Z-DEVD-ProRed™ 620
Z-IETD-ProRed™ 620
mFluor™ Violet 450-VAD-FMK
mFluor™ 510-VAD-FMK
TF3-DEVD-FMK
Z-DEVD-FMK
Z-IETD-FMK
Ac-VAD-CHO [Caspase Inhibitor II]
Show More (70)

OverviewpdfSDSpdfProtocol


Molecular weight
874.01
Absorbance (nm)
220
Excitation (nm)
559
Emission (nm)
577
SRB-VAD is a red fluorescent cell-permeable polycaspase inhibitor to target caspases 1, 2, 3, 6, 8, 9, or 10. Once inside the cell, the inhibitor binds covalently to the active caspase, which produces a green fluorescence. When added to a population of cells, the SRB-VAD-FMK probe enters each cell and covalently binds to a reactive cysteine residue that resides on the large subunit of the active caspase heterodimer, thereby inhibiting further enzymatic activity. The bound labeled reagent is retained within the cell, while any unbound reagent will diffuse out of the cell and is washed away. The green fluorescent signal is a direct measure of the amount of active caspase present in the cell at the time the reagent was added. Cells that contain the bound labeled reagent can be analyzed by 96-well plate-based fluorometry, fluorescence microscopy, or flow cytometry. The probe has the spectral properties similar to Cy3® and TRITC, thus the filter set of Cy3® and TRITC can be conveniently used with a flow cytometer or microscope.

Example protocol


AT A GLANCE

Important      It is important to store at <-15 °C and should be stored in cool, dark place.
It can be used within 12 months from the date of receipt.

SAMPLE EXPERIMENTAL PROTOCOL

Following protocol only provides a guideline, and should be modified according to your specific needs.
  1. Prepare a 10 mM stock solution in DMSO.
  2. Prepare a 2X caspase substrate (50 µM) assay solution as the following: 50 µL substrate stock solution, 100 µL DTT (1M), 400 µL EDTA (100 mM), 10 mL Tris Buffer (20 mM), pH =7.4.
  3. Mix equal volume of the caspase standards or samples with 2X caspase substrate assay solution, and incubate the solutions at room temperature for at least 1 hour.
  4. Monitor the fluorescence using a fluorescence microplate reader, or absorbance using an absorbance microplate reader.

Cell Caspase Assays Using Cell-Permeable FMK Caspase Probes
  1. Prepare a 2-5 mM stock solution in DMSO.
  2. Treat cells as desired.
  3. Prepare a 2X permeable caspase substrate (20 µM) assay solution by diluting the DMSO stock solution (from Step 2.1) in Hanks with 20 mM Hepes buffer (HHBS).
  4. Mix equal volume of the treated cells with 2X caspase substrate assay solution (from Step 2.3), and incubate the cells in a 37°C, 5% CO2 incubator for at least1 hour.
  5. Wash the cells with HHBS for at least once.
  6. Monitor the fluorescence intensity by a flow cytometer, a fluorescence microscope or a fluorescence microplate reader.

Cell Caspase Assays Using Cell-Permeable FMK Caspase Probes (For #13470-13476 only)
  1. Prepare a 250X stock solution by adding 50 µL DMSO into the vial.
    Note     For Cat# 13482, prepare a 250X stock solution by adding 200 µL DMSO into the vial.
  2. Treat cells as desired.
  3. Add 250 X DMSO stock solution into the cell solution at a 1:250 ratio (such as 2 µL to 500 µL cells), and incubate the cells in a 37°C, 5% CO2 incubator for 1 hour.
  4. Wash the cells with HHBS for at least once.
  5. Monitor the fluorescence intensity by flow cytometer, fluorescence microscopy or fluorescent microplate reader.

Calculators


Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of SRB-VAD-FMK [Sulforhodamine B-VAD-FMK] to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

0.1 mg0.5 mg1 mg5 mg10 mg
1 mM114.415 µL572.076 µL1.144 mL5.721 mL11.442 mL
5 mM22.883 µL114.415 µL228.83 µL1.144 mL2.288 mL
10 mM11.442 µL57.208 µL114.415 µL572.076 µL1.144 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)Molecular weightVolume (Calculate)Concentration (Calculate)Moles
/=x=

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Absorbance (nm)220
Excitation (nm)559
Emission (nm)577

Product Family


NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Correction Factor (280 nm)
FAM-VAD-FMK493517830000.178
TF4-VAD-FMK578602900000.436
