Texas Red®-streptavidin conjugate

HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by Texas Red®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by Texas Red®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
Ordering information
Price ()
Catalog Number16911
Unit Size
Find Distributor
Additional ordering information
Telephone1-408-733-1055
Fax1-408-733-1304
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Physical properties
Molecular weight52000
SolventWater
Spectral properties
Correction Factor (260 nm)0.23
Correction Factor (280 nm)0.36
Correction Factor (565 nm)0.4472
Extinction coefficient (cm -1 M -1)1160001
Excitation (nm)586
Emission (nm)603
Quantum yield0.931, 0.352
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12352200
Related products
Texas Red-X, succinimidyl ester *Single isomer* *178623-11-5*
Texas Red® hydrazide *Single Isomer*
Texas Red® cadaverine *Single Isomer*
Texas Red® maleimide *Single Isomer*
Texas Red® azide *Single Isomer*
Texas Red® alkyne *Single Isomer*
Texas Red® goat anti-mouse IgG (H+L)
Texas Red® goat anti-mouse IgG (H+L) *Cross Adsorbed*
Texas Red® goat anti-rabbit IgG (H+L)
Texas Red® goat anti-rabbit IgG (H+L) *Cross Adsorbed*
Texas Red-DHPE *CAS 187099-99-6*
Texas Red-X, succinimidyl ester *Mixed isomers* *CAS 216972-99-5*
Texas Red TCO *Single isomer*
Texas Red-X, acid *CAS 199745-67-0*
RPE-streptavidin conjugate
APC-streptavidin conjugate
PerCP-streptavidin conjugate
RPE-iFluor® 647-streptavidin conjugate
RPE-iFluor® 750-streptavidin conjugate
APC-iFluor® 750-streptavidin conjugate
FITC-streptavidin conjugate
Cy3®-streptavidin conjugate
Cy5®-streptavidin conjugate
Cy7®-streptavidin conjugate
HRP-streptavidin conjugate
AP-streptavidin conjugate [Streptavidin-alkaline phosphatase conjugate]
trFluor™ Eu-streptavidin conjugate
trFluor™ Tb-streptavidin conjugate
mFluor™ Violet 450-streptavidin conjugate
mFluor™ Violet 510-streptavidin conjugate
mFluor™ Violet 540-streptavidin conjugate
mFluor™ Blue 570-streptavidin conjugate
mFluor™ Green 620-streptavidin conjugate
mFluor™ Yellow 630-streptavidin conjugate
mFluor™ Red 700-streptavidin conjugate
mFluor™ Red 780-streptavidin conjugate
iFluor® 350-streptavidin conjugate
iFluor® 405-streptavidin conjugate
iFluor® 488-streptavidin conjugate
iFluor® 514-streptavidin conjugate
iFluor® 532-streptavidin conjugate
iFluor® 555-streptavidin conjugate
iFluor® 633-streptavidin conjugate
iFluor® 647-streptavidin conjugate
iFluor® 680-streptavidin conjugate
iFluor® 700-streptavidin conjugate
iFluor® 750-streptavidin conjugate
iFluor® 546-streptavidin conjugate
iFluor® 568-streptavidin conjugate
XFD350-streptavidin conjugate *XFD350 Same Structure to Alexa Fluor™ 350*
XFD488-streptavidin conjugate *XFD488 Same Structure to Alexa Fluor™ 488*
XFD594-streptavidin conjugate *XFD594 Same Structure to Alexa Fluor™ 594*
RPE-Cy7-streptavidin conjugate
iFluor® 790-streptavidin conjugate
iFluor® 800-streptavidin conjugate
iFluor® 820-streptavidin conjugate
iFluor® 840-streptavidin conjugate
iFluor® 860-streptavidin conjugate
MegaWox™ polyHRP-Streptavidin Conjugate
RPE-Cy5-streptavidin conjugate
Show More (60)

OverviewpdfSDSpdfProtocol


Molecular weight
52000
Correction Factor (260 nm)
0.23
Correction Factor (280 nm)
0.36
Correction Factor (565 nm)
0.4472
Extinction coefficient (cm -1 M -1)
1160001
Excitation (nm)
586
Emission (nm)
603
Quantum yield
0.931, 0.352
Streptavidin conjugates are widely used together with a conjugate of biotin for specific detection of a variety of proteins, protein motifs, nucleic acids and other molecules since streptavidin has a very high binding affinity for biotin. This Texas Red-streptavidin conjugate comprises streptavidin (as the biotin-binding protein) with Texas Red covalently attached (as the fluorescent label). Our Texas Red-streptavidin conjugate was prepared using AAT Bioquest's proprietary labeling technology. It demonstrated much brighter signal compared to the similar Texas Red-streptavidin conjugates from other commercial sources, thus can significantly increase assay sensitivities. It is commonly used as a second step reagent for indirect immunofluorescent staining, when used in conjunction with biotinylated primary antibodies. It is a valuable tool for biotin-streptavidin-based biological assays and tests using flow cytometry with a Texas Red filter set. A variety of the complementary biotinylated reagents are available from numerous commercial vendors.

Calculators


Common stock solution preparation

Table 1. Volume of Water needed to reconstitute specific mass of Texas Red®-streptavidin conjugate to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

0.1 mg0.5 mg1 mg5 mg10 mg
1 mM1.923 µL9.615 µL19.231 µL96.154 µL192.308 µL
5 mM384.615 nL1.923 µL3.846 µL19.231 µL38.462 µL
10 mM192.308 nL961.538 nL1.923 µL9.615 µL19.231 µL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)Molecular weightVolume (Calculate)Concentration (Calculate)Moles
/=x=

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Correction Factor (260 nm)0.23
Correction Factor (280 nm)0.36
Correction Factor (565 nm)0.4472
Extinction coefficient (cm -1 M -1)1160001
Excitation (nm)586
Emission (nm)603
Quantum yield0.931, 0.352
