zFluor™ 635 succinimidyl ester
Ordering information
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Additional ordering information
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
International | See distributors |
Bulk request | Inquire |
Custom size | Inquire |
Shipping | Standard overnight for United States, inquire for international |
Physical properties
Molecular weight | 1336.89 |
Solvent | DMSO |
Spectral properties
Correction Factor (260 nm) | 0.12 |
Correction Factor (280 nm) | 0.09 |
Extinction coefficient (cm -1 M -1) | 110,0001 |
Quantum yield | 0.221 |
Storage, safety and handling
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
Storage | Freeze (< -15 °C); Minimize light exposure |
UNSPSC | 12171501 |
Overview | SDSProtocol |
Molecular weight 1336.89 | Correction Factor (260 nm) 0.12 | Correction Factor (280 nm) 0.09 | Extinction coefficient (cm -1 M -1) 110,0001 | Quantum yield 0.221 |
Our zFluor™ serial dyes are developed to have the possibly highest photostability at a given wavelength compared to the other similar wavelength dyes on the market. zFluor™ 635 has similar spectral properties to the popular Cy5® (GE Healthcare) and Alexa Fluor® 647 (ThermoFisher). Its high thermal and photostability makes it an excellent choice for single-molecule detection applications and high-resolution microscopy such as PALM, dSTORM and STED. Under the same test conditions, zFluor™ 635 has much higher ozone stability than Cy5® and Alexa Fluor® 647, making it a much better choice for microarray and other biochip-based applications. This feature is extremely useful for fluorescence in-situ hybridization (FISH). In addition, zFluor™-labeled oligonucleotides and peptides are much brighter and more photostable than the ones labeled by Alexa Fluor® 647 and Cy5®. Similarly, zFluor™ 635-labeled oligos demonstrated higher signals than the corresponding conjugates prepared with either Cy5® or Alexa Fluor® 647 in our qPCR tests. The absorption and fluorescence of our zFluor™ 635 dyes are independent of pH in the range of pH 2 to 11. They are well excited at 633 nm of He-Ne laser, the 647 nm line of the Krypton-Ion laser or a diode-laser.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of zFluor™ 635 succinimidyl ester to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 74.8 µL | 374.002 µL | 748.005 µL | 3.74 mL | 7.48 mL |
5 mM | 14.96 µL | 74.8 µL | 149.601 µL | 748.005 µL | 1.496 mL |
10 mM | 7.48 µL | 37.4 µL | 74.8 µL | 374.002 µL | 748.005 µL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Spectrum
Open in Advanced Spectrum Viewer
Spectral properties
Correction Factor (260 nm) | 0.12 |
Correction Factor (280 nm) | 0.09 |
Extinction coefficient (cm -1 M -1) | 110,0001 |
Quantum yield | 0.221 |
Product Family
Name | Excitation (nm) | Emission (nm) |
zFluor™ 647 succinimidyl ester | 648 | 668 |
zFluor™ 633 succinimidyl ester | 623 | 639 |
Citations
View all 1 citations: Citation Explorer
Inner hair cell stereocilia are embedded in the tectorial membrane
Authors: Hakizimana, Pierre and Fridberger, Anders
Journal: Nature Communications (2021): 1--13
Authors: Hakizimana, Pierre and Fridberger, Anders
Journal: Nature Communications (2021): 1--13
