Calcein Deep Red™

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
Quotation	Request
International	See distributors
Shipping	Standard overnight for United States, inquire for international

Physical properties

Molecular weight	373.66
Solvent	DMSO

Spectral properties

Excitation (nm)	643
Emission (nm)	663

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
Storage	Freeze (< -15 °C); Minimize light exposure
UNSPSC	12352200

Overview SDS Protocol

Molecular weight

373.66

Excitation (nm)

643

Emission (nm)

663

Calcein AM is one the most popular fluorescent probes used for labeling and monitoring cellular functions of live cells. However, the single color of Calcein AM makes it impossible to use this valuable reagent in the multicolor applications. For example, it is impossible to use Calcein AM in GFP-tranfacted cells due to the same color to GFP. To address this color limitation of Calcein AM, we have developed Calcein Orange™, Calcein Red™ and Calcein Deep Red™. These new Calcein AM analogs enable the multicolor labeling and functional analysis of live cells in combination with Calcein AM. Calcein Deep Red™ is the esterase-hydrolyzed product of Calcein Deep Red™ acetate in cells. Calcein Deep Red™ dye can be monitored with the common Cy5 filter set. It is used as a fluorescence reference standard for Calcein Deep Red™ acetate.

Platform

Flow cytometer

Excitation	640 nm laser
Emission	660/20 nm filter
Instrument specification(s)	APC channel

Fluorescence microscope

Excitation	Cy5 filter set
Emission	Cy5 filter set
Recommended plate	Black wall/clear bottom

Fluorescence microplate reader

Excitation	620
Emission	660
Cutoff	630
Recommended plate	Solid black

Example protocol

Calculators

Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Calcein Deep Red™ to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

	0.1 mg	0.5 mg	1 mg	5 mg	10 mg
1 mM	267.623 µL	1.338 mL	2.676 mL	13.381 mL	26.762 mL
5 mM	53.525 µL	267.623 µL	535.246 µL	2.676 mL	5.352 mL
10 mM	26.762 µL	133.811 µL	267.623 µL	1.338 mL	2.676 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)		Molecular weight		Volume (Calculate)		Concentration (Calculate)		Moles
	/		=		x		=

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Excitation (nm)	643
Emission (nm)	663

Product Family

Name	Excitation (nm)	Emission (nm)
Calcein Red™ AM	562	576
LysoBrite™ Deep Red	597	619

Images

Figure 1. Images of Live HeLa cells stained with Calcein Deep Red™ (Cat#21902) and Calcein Deep Red™ AM(Cat.22011 ). Calcein Deep Red™ cannot permeate intact live cells.
