Cell Navigator® Mitochondrion Staining Kit *Green Fluorescence*

Fluorescence images of HeLa cells stained with Cell Navigator® Mitochondrion Staining Kit *Green Fluorescence*. Live cells were stained with mitochondria dye MitoLite™ Green (Green) and imaged using fluorescence microscope with a FITC filter set. After fixation in 4% formaldehyde, the cells were labeled with F-actin dye iFluor® 633-Phalloidin (Cat#23125, Red) and counterstained with Nuclear Blue™ DCS1 (Cat#17548, Blue).
Fluorescence images of HeLa cells stained with Cell Navigator® Mitochondrion Staining Kit *Green Fluorescence*. Live cells were stained with mitochondria dye MitoLite™ Green (Green) and imaged using fluorescence microscope with a FITC filter set. After fixation in 4% formaldehyde, the cells were labeled with F-actin dye iFluor® 633-Phalloidin (Cat#23125, Red) and counterstained with Nuclear Blue™ DCS1 (Cat#17548, Blue).
Mitochondria activity, mitochondrial respiratory enzyme, and ATP level of plasma-treated SCs. Chicken SCs were exposed to 22.0 kV of non-thermal plasma for 120s<strong>.</strong> (A) Imaging of SCs stained with a Cell Navigator Mitochondrial Staining Kit (green fluorescence). Scale bar: 50 μm. (B) Relative fluorescence intensity for mitochondrial staining. (C) NADH level. Activities of (D) cytochrome c oxidase and (E) ATPase synthase in the mitochondria of SCs. (F) ATP level in SCs. (G) ATP5A1 mRNA relative level. Data are represented as the mean ± SD (n = 3 per group). *p < 0.05; **p < 0.01, according to one-way ANOVA and LSD test. Source: <strong>MicroRNA-7450 regulates non-thermal plasma-induced chicken Sertoli cell apoptosis via adenosine monophosphate-activated protein kinase activation</strong> by Zhang et al., <em>Scientific Reports</em>, June 2018.
Ordering information
Price ()
Catalog Number22666
Unit Size
Find Distributor
Additional ordering information
Telephone1-408-733-1055
Fax1-408-733-1304
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Spectral properties
Excitation (nm)508
Emission (nm)528
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
UNSPSC12352200

OverviewpdfSDSpdfProtocol


Excitation (nm)
508
Emission (nm)
528
Our Cell Navigator® fluorescence imaging kits are a set of fluorescence imaging tools for labeling sub-cellular organelles such as membranes, lysosomes, mitochondria and nuclei etc. The selective labeling of live cell compartments provides a powerful method for studying cellular events in a spatial and temporal context. This particular kit is designed to label mitochondria of live cells in green fluorescence. The kit uses a proprietary dye that selectively accumulates in mitochondria probably vial the mitochondrial membrane potential gradient. The mitochondrial indicator is a hydrophobic compound that easily permeates intact live cells, and trapped in mitochondria after it gets into cells. This fluorescent mitochondrial indicator is retained in mitochondria for long time since the indicator carries a cell-retaining group. This key feature significantly increases its staining efficiency. The labeling protocol is robust, requiring minimal hands-on time. It can be readily adapted for a wide variety of fluorescence platforms such as microplate assays, immunocytochemistry and flow cytometry. It is useful for a variety of studies, including cell adhesion, chemotaxis, multidrug resistance, cell viability, apoptosis and cytotoxicity. The kit provides all the essential components with an optimized cell-labeling protocol. It is suitable for proliferating and non-proliferating cells, and can be used for both suspension and adherent cells.

Platform


Fluorescence microscope

ExcitationFITC filter set
EmissionFITC filter set
Recommended plateBlack wall/clear bottom

Components


Component A: MitoLite™ Green1 vial (100 µL, 500X DMSO stock solution)
Component B: Live Cell Staining Buffer1 bottle (50 mL)

Example protocol


AT A GLANCE

Protocol summary

  1. Prepare cells
  2. Add Mitolite™ Green working solution
  3. Incubate at 37°C for 30 minutes to 2 hours
  4. Analyze the cells under fluorescence microscope at Ex/Em = 485/525 nm (FITC filter set)

Important notes
Thaw all the components at room temperature before starting the experiment.

PREPARATION OF WORKING SOLUTION

Add 20 µL of 500X Mitolite™ Green  (Component A) into 10 mL of Live Cell Staining Buffer (Component B) to make Mitolite™ Green working solution. Protect from light. Note: 20 µL of 500X Mitolite™ Green (Component A) is enough for one 96-well plate. The optimal concentration of the fluorescent mitochondrial indicator varies depending on the specific application. The staining conditions may be modified according to the particular cell type and the permeability of the cells or tissues to the probe.

For guidelines on cell sample preparation, please visit
https://www.aatbio.com/resources/guides/cell-sample-preparation.html

SAMPLE EXPERIMENTAL PROTOCOL

For adherent cells:

  1. Grow cells either in a 96-well black wall/clear bottom plate (100 µL/well/96-well plate) or on cover-slips inside a petri dish filled with the appropriate culture medium.

  2. When cells reach the desired confluence, add equal volume of Mitolite™ Green working solution.

  3. Incubate the cells in a 37°C, 5% CO2 incubator for 30 minutes to 2 hours.

  4. Replace Mitolite™ Green working solution with Hanks and 20 mM Hepes buffer (HHBS) or buffer of your choice (e.g. the buffer with growth medium at 1:1 concentration).

  5. Observe the cells using a fluorescence microscope with FITC filter set (Ex/Em = 485/525 nm). Note: It’s recommended to increase either the labeling concentration or the incubation time to allow the dye to accumulate if the cells do not appear to be sufficiently stained.

For suspension cells:

  1. Centrifuge the cells at 1000 rpm for 5 minutes to obtain a cell pellet and aspirate the supernatant.

  2. Resuspend the cell pellets gently in pre-warmed (37°C) growth medium, and add equal volume of Mitolite™ Green working solution.

  3. Incubate the cells in a 37°C, 5% CO2 incubator for 30 minutes to 2 hours.

  4. Replace Mitolite™ Green working solution with Hanks and 20 mM Hepes buffer (HHBS) or buffer of your choice (e.g. the buffer with growth medium at 1:1 concentration).

  5. Observe the cells using a fluorescence microscope with FITC filter set (Ex/Em = 485/525 nm). Note: It is recommended to increase either the labeling concentration or the incubation time to allow the dye to accumulate if the cells do not appear to be sufficiently stained. Suspension cells may be attached to cover-slips that have been treated with BD Cell-Tak® (BD Biosciences) and stained as adherent cells.

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Excitation (nm)508
Emission (nm)528
