Cy3®-streptavidin conjugate

HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by AAT's Cy3®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by AAT's Cy3®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by AAT's Cy3®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
Ordering information
Price
Catalog Number
Unit Size
Quantity
Add to cart
Additional ordering information
Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
ShippingStandard overnight for United States, inquire for international
Request quotation
Physical properties
Molecular weight~52000
SolventWater
Spectral properties
Correction Factor (260 nm)0.07
Correction Factor (280 nm)0.073
Extinction coefficient (cm -1 M -1)1500001
Excitation (nm)555
Emission (nm)569
Quantum yield0.151
Storage, safety and handling
Certificate of OriginDownload PDF
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12352200
Related products
Cy3NS acid *CAS 1032678-01-5*
Cy3NS succinimidyl ester
Cy3 trans-cyclooctene [Cy3 TCO]
Cy3 tetrazine
Cy3 phosphoramidite
Cy3® goat anti-mouse IgG (H+L)
Cy3® goat anti-mouse IgG (H+L) *Cross Adsorbed*
Cy3® goat anti-rabbit IgG (H+L)
Cy3® goat anti-rabbit IgG (H+L) *Cross Adsorbed*
Cy3 tyramide
Cy3DIGE NHS ester
Cy3B acid
Cy3B maleimide
Cy3 aldehyde
Cy3B azide
Cy3B alkyne
Cy3B DBCO
Cy3B TCO
Cy3B PEG8 methyltetrazine
Cy3B Tetrazine
Cy3B NHS ester
Cy3.5 Dye qPCR Calibration Plate *Optimized for ABI7500 Fast 96-Well*
Cy3.5 tetrazine
RPE-iFluor® 647-streptavidin conjugate
RPE-iFluor® 750-streptavidin conjugate
APC-iFluor® 750-streptavidin conjugate
Texas Red®-streptavidin conjugate
trFluor™ Eu-streptavidin conjugate
trFluor™ Tb-streptavidin conjugate
mFluor™ Violet 450-streptavidin conjugate
mFluor™ Violet 510-streptavidin conjugate
mFluor™ Violet 540-streptavidin conjugate
mFluor™ Blue 570-streptavidin conjugate
mFluor™ Green 620-streptavidin conjugate
mFluor™ Yellow 630-streptavidin conjugate
mFluor™ Red 700-streptavidin conjugate
mFluor™ Red 780-streptavidin conjugate
iFluor® 350-streptavidin conjugate
iFluor® 405-streptavidin conjugate
iFluor® 488-streptavidin conjugate
iFluor® 514-streptavidin conjugate
iFluor® 532-streptavidin conjugate
iFluor® 594-streptavidin conjugate
iFluor® 633-streptavidin conjugate
iFluor® 647-streptavidin conjugate
iFluor® 680-streptavidin conjugate
iFluor® 700-streptavidin conjugate
iFluor® 750-streptavidin conjugate
iFluor® 546-streptavidin conjugate
iFluor® 568-streptavidin conjugate
RPE-Cy7-streptavidin conjugate
iFluor® 790-streptavidin conjugate
iFluor® 800-streptavidin conjugate
iFluor® 820-streptavidin conjugate
iFluor® 840-streptavidin conjugate
iFluor® 860-streptavidin conjugate
MegaWox™ polyHRP-Streptavidin Conjugate
RPE-Cy5-streptavidin conjugate
mFluor™ UV455-streptavidin conjugate
mFluor™ Violet 545-streptavidin conjugate
mFluor™ Violet 550-streptavidin conjugate
mFluor™ Violet 590-streptavidin conjugate
mFluor™ Violet 610-streptavidin conjugate
mFluor™ UV420-streptavidin conjugate
Show More (54)

OverviewpdfSDSpdfProtocol


Molecular weight
~52000
Correction Factor (260 nm)
0.07
Correction Factor (280 nm)
0.073
Extinction coefficient (cm -1 M -1)
1500001
Excitation (nm)
555
Emission (nm)
569
Quantum yield
0.151
Streptavidin conjugates are widely used together with a conjugate of biotin for specific detection of a variety of proteins, protein motifs, nucleic acids and other molecules since streptavidin has a very high binding affinity for biotin. This Cy3-streptavidin conjugate comprises streptavidin (as the biotin-binding protein) with Cy3 covalently attached (as the fluorescent label). Our Cy3-streptavidin conjugate was prepared using AAT Bioquest's proprietary labeling technology. It demonstrated much brighter signal compared to the similar Cy3-streptavidin conjugates from other commercial sources, thus can significantly increase assay sensitivities. It is commonly used as a second step reagent for indirect immunofluorescent staining, when used in conjunction with biotinylated primary antibodies. It is a valuable tool for biotin-streptavidin-based biological assays and tests using flow cytometry with a Cy3 filter set. A variety of the complementary biotinylated reagents are available from numerous commercial vendors.

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Correction Factor (260 nm)0.07
Correction Factor (280 nm)0.073
Extinction coefficient (cm -1 M -1)1500001
Excitation (nm)555
Emission (nm)569
Quantum yield0.151

Product Family


NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yieldCorrection Factor (260 nm)Correction Factor (280 nm)
Cy3 biotin conjugate55556915000010.1510.070.073
RPE-streptavidin conjugate56557419600000.82-0.175
APC-streptavidin conjugate651660730000--0.195
PerCP-streptavidin conjugate477678406000--0.22
FITC-streptavidin conjugate491516730000.92-0.35
Cy5®-streptavidin conjugate65167025000010.271, 0.420.020.03
Cy7®-streptavidin conjugate7567792500000.30.050.036
XFD350-streptavidin conjugate *XFD350 Same Structure to Alexa Fluor™ 350*34344119000-0.250.19
XFD488-streptavidin conjugate *XFD488 Same Structure to Alexa Fluor™ 488*499520730000.9210.30.11
XFD594-streptavidin conjugate *XFD594 Same Structure to Alexa Fluor™ 594*590618920000.6610.430.56
Show More (1)
