Phalloidin Conjugates

Phalloidin conjugates stain F-actin in fixed and permeabilized cells with high-affinity.

Phalloidin is a bicyclic heptapeptide isolated from the poisonous death cap mushroom, Amanita phalloides. Its high binding affinity for the grooves between filamentous actin (F-actin) over monomeric G-actin is widely used to visualize and quantitate F-actin in tissue sections, cell cultures, or cell-free preparations. Compared to actin-specific antibodies, the non-specific binding of phalloidin is negligible, thus providing minimal background and high contrast during cellular imaging. Once bound to F-actin, phalloidin shifts the equilibrium of monomers and filaments toward the filaments side and inhibits ATP-hydrolysis. The interaction stabilizes actin filaments by preventing subunit dissociation, and it promotes actin polymerization by lowering the critical concentration.

When conjugated to fluorescent dyes, phalloidin can be used at nanomolar concentrations to label and visualize F-actin in fixed and permeabilized cells, cell cultures, and cell-free experiments, as well as formaldehyde-fixed and permeabilized tissue sections. Phalloidin conjugates exhibit similar affinity for all types and sizes of actin filaments, binding in a stoichiometric ratio of 1:1 (phallotoxin:actin) in both muscle and nonmuscle cells. Compared to antibodies, phalloidin derivatives' are small (< 2 kDa), and phalloidin-bound filaments do not impede the functional properties of the filaments. The small size also permits denser F-actin labeling producing more detailed stains when imaged at higher resolutions. In addition, because actin is evolutionarily conserved, the binding properties of phalloidin derivatives can be utilized in staining a wide range of animal and plant cells.

Example protocol

AT A GLANCE

Protocol Summary
  1. Prepare samples in microplate wells
  2. Remove liquid from samples in the plate
  3. Add Phalloidin-iFluor™ 488 Conjugate solution (100 μL/well)
  4. Stain the cells at room temperature for 20 to 90 minutes
  5. Wash the cells
  6. Examine the specimen under microscope with FITC filter
Important      Warm the vial to room temperature and centrifuge briefly before opening.

Storage and Handling Conditions
The solution should be stable for at least 6 months if store at -20 °C. Protect the fluorescent conjugates from light, and avoid freeze/thaw cycles.
Note     Phalloidin is toxic, although the amount of toxin present in a vial could be lethal only to a mosquito (LD50 of phalloidin = 2 mg/kg), it should be handled with care.

PREPARATION OF WORKING SOLUTION

Phalloidin-iFluor™ 488 Conjugate working solution
Add 1 µL of Phalloidin-iFluor™ 488 Conjugate solution to 1 mL of PBS with 1% BSA.
Note     The stock solution of phalloidin conjugate should be aliquoted and stored at -20 °C. protected from light.
Note     Different cell types might be stained differently. The concentration of phalloidin conjugate working solution should be prepared accordingly.

SAMPLE EXPERIMENTAL PROTOCOL

Stain the cells
  1. Perform formaldehyde fixation. Incubate cells with 3.0–4.0 % formaldehyde in PBS at room temperature for 10–30 minutes.
    Note     Avoid any methanol containing fixatives since methanol can disrupt actin during the fixation process. The preferred fixative is methanol-free formaldehyde.
  2. Rinse the fixed cells 2–3 times in PBS.
  3. Optional: Add 0.1% Triton X-100 in PBS into fixed cells for 3 to 5 minutes to increase permeability. Rinse the cells 2–3 times in PBS.
  4. Add 100 μL/well (96-well plate) of Phalloidin-iFluor™ 488 Conjugate working solution into the fixed cells, and stain the cells at room temperature for 20 to 90 minutes.
  5. Rinse cells gently with PBS 2 to 3 times to remove excess phalloidin conjugate before plating, sealing and imaging under microscope with FITC filter set.

Spectrum

Product family

NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yieldCorrection Factor (260 nm)Correction Factor (280 nm)
Phalloidin-iFluor® 350 Conjugate3454502000010.9510.830.23
Phalloidin-iFluor® 405 Conjugate4034273700010.9110.480.77
Phalloidin-iFluor® 514 Conjugate5115277500010.8310.2650.116
Phalloidin-iFluor® 532 Conjugate5375609000010.6810.260.16
Phalloidin-iFluor® 555 Conjugate55757010000010.6410.230.14
Phalloidin-iFluor® 594 Conjugate58760320000010.5310.050.04
Phalloidin-iFluor® 633 Conjugate64065425000010.2910.0620.044
Phalloidin-iFluor® 647 Conjugate65667025000010.2510.030.03
Phalloidin-iFluor® 680 Conjugate68470122000010.2310.0970.094
Phalloidin-iFluor® 700 Conjugate69071322000010.2310.090.04
Phalloidin-iFluor® 750 Conjugate75777927500010.1210.0440.039
Phalloidin-iFluor® 790 Conjugate78781225000010.1310.10.09
iFluor® 488-streptavidin conjugate4915167500010.910.210.11
Show More (4)

Citations

View all 361 citations: Citation Explorer
Mechanotransduction pathways regulating YAP nuclear translocation under Yoda1 and vibration in osteocytes
Authors: Lin, Chun-Yu and Sassi, Amel and Wu, Yuning and Seaman, Kimberly and Tang, Wentian and Song, Xin and Bienenstock, Raphael and Yokota, Hiroki and Sun, Yu and Geng, Fei and others,
Journal: Bone (2024): 117283
Peptide-based Self-adaptive Implant Coating Sequentially Regulates Bone Regeneration to Enhance Interfacial Osseointegration
Authors: Huang, Wei and Zhou, Wei and Liu, Yang and Xuan, Nie and Zhu, Chen and Xiong, Liming and Zhou, Jing
Journal: (2024)
Effects of Arthrospira platensis on Human Umbilical Vein Endothelial Cells
Authors: Kr{\"u}ger-Genge, Anne and Harb, Kudor and Braune, Steffen and Jung, Conrad HG and Westphal, Sophia and B{\"a}r, Stefanie and Mauger, Olivia and K{\"u}pper, Jan-Heiner and Jung, Friedrich
Journal: Life (2024): 1253
Inhibitory impact of a mesoporous silica nanoparticle-based drug delivery system on Porphyromonas gingivalis-induced bone resorption
Authors: Li, Mengya and Sun, Jian and Zhao, Dong and Zhang, Wen and Xu, Qingan
Journal: Journal of Materials Science: Materials in Medicine (2024): 56
Tristetraprolin affects invasion-associated genes expression and cell motility in triple-negative breast cancer model
Authors: Hubiernatorova, Anastasiia and Novak, Josef and Vaskovicova, Michaela and Sekac, David and Kropyvko, Serhii and Hodny, Zdenek
Journal: Cytoskeleton (2024)

References

View all 127 references: Citation Explorer
Phalloidin perturbs the interaction of human non-muscle myosin isoforms 2A and 2C1 with F-actin
Authors: Diensthuber RP, Muller M, Heissler SM, Taft MH, Chizhov I, Manstein DJ.
Journal: FEBS Lett (2011): 767
Improved penile histology by phalloidin stain: circular and longitudinal cavernous smooth muscles, dual-endothelium arteries, and erectile dysfunction-associated changes
Authors: Lin G, Qiu X, F and el TM, Albersen M, Wang Z, Lue TF, Lin CS.
Journal: Urology (2011): 970 e1
Labeling cytoskeletal F-actin with rhodamine phalloidin or fluorescein phalloidin for imaging
Authors: Chazotte B., undefined
Journal: Cold Spring Harb Protoc (2010): pdb prot4947
pH-(low)-insertion-peptide (pHLIP) translocation of membrane impermeable phalloidin toxin inhibits cancer cell proliferation
Authors: An M, Wijesinghe D, Andreev OA, Reshetnyak YK, Engelman DM.
Journal: Proc Natl Acad Sci U S A (2010): 20246
In vitro inhibition of OATP-mediated uptake of phalloidin using bile acid derivatives
Authors: Herraez E, Macias RI, Vazquez-Tato J, Vicens M, Monte MJ, Marin JJ.
Journal: Toxicol Appl Pharmacol (2009): 13
Page updated on October 9, 2024

Ordering information

Price
Conjugate
Unit size
Catalog Number
Quantity
Add to cart

Additional ordering information

Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
Technical SupportContact us
Purchase orderSend to sales@aatbio.com
ShippingStandard overnight for United States, inquire for international
Request quotation

Physical properties

Molecular weight

~1400

Solvent

DMSO

Spectral properties

Correction Factor (260 nm)

0.21

Correction Factor (280 nm)

0.11

Extinction coefficient (cm -1 M -1)

750001

Excitation (nm)

491

Emission (nm)

516

Quantum yield

0.91

Storage, safety and handling

Certificate of OriginDownload PDF
H-phraseH301, H311, H331
Hazard symbolT
Intended useResearch Use Only (RUO)
R-phraseR23, R24, R25

Storage

Freeze (< -15 °C); Minimize light exposure
UNSPSC12352200
Fluorescence images of HeLa cells stained with Phalloidin-iFluor® 488 Conjugate using fluorescence microscope with a FITC filter set (Green). The cells were fixed in 4% formaldehyde, co-labeled with mitochondria dye MitoLite&trade; Red FX600 (Cat#2677, Red) and Nuclear Blue&trade; DCS1 (Cat#17548, Blue).
Fluorescence images of HeLa cells stained with Phalloidin-iFluor® 488 Conjugate using fluorescence microscope with a FITC filter set (Green). The cells were fixed in 4% formaldehyde, co-labeled with mitochondria dye MitoLite&trade; Red FX600 (Cat#2677, Red) and Nuclear Blue&trade; DCS1 (Cat#17548, Blue).
Fluorescence images of HeLa cells stained with Phalloidin-iFluor® 488 Conjugate using fluorescence microscope with a FITC filter set (Green). The cells were fixed in 4% formaldehyde, co-labeled with mitochondria dye MitoLite&trade; Red FX600 (Cat#2677, Red) and Nuclear Blue&trade; DCS1 (Cat#17548, Blue).
<strong>Figure 2.</strong> MDA-MB-231 breast cancer cell grew for 24 h. Cells were stained with Phalloidin-iFluor 488 Conjugate (ATT Bioquest) following manufacturer&rsquo;s instruction. Images were acquired with a 63x/1.4NA objective on a Zeiss laser-scanning confocal microscope by the Advanced Bio-Imaging Facility (ABIF) at McGill.&nbsp;Displayed is the Max Intensity Projection of 19 images with 0.2 um spacing in Z.
Enterobacteriaceae (Lipid A) in the liver of the uninfected and the liver fluke-infected hamsters. a. An uninfected hamster. b. 3D reconstruction of the internal surface of a bile duct after confocal microscopy reveals the presence of Enterobacteriaceae Lipid A. c. Bacteria inside the gut of the O. viverrini parasite. d. Enterobacteriaceae presence inside small bile ducts of an O. viverrini–infected hamster. e. Penetration of bacteria through the injured epithelium in the bile duct of an O. felineus–infected hamster. f. A multilayered epithelium in the bile duct of a C. sinensis–infected hamster. E: epithelial cells; BD: bile duct; red color: Lipid A of Enterobacteriaceae; green color: actin filaments (Phalloidin 488 staining); blue color: nuclei (DAPI staining). E: epithelium of bile duct; BD: bile duct; G: gut of a worm. Source: <b><em>Opisthorchis viverrini</em>, <em>Clonorchis sinensis</em> and <em>Opisthorchis felineus</em> liver flukes affect mammalian host microbiome in a species-specific manner</b> by Pakharukova <em>et. al.</em>, <em>PLoS Negl Trop Dis</em>. Feb. 2023.
Conditioning of GelMA-AlgMA bioinks for skeletal muscle tissue engineering. Modulation of GelMA-AlgMA bioink mechanical properties of GelMA with 0 %,1 % and 2 % AlgMA (n = 9). Confocal images of C2C12 cells after 14 days of differentiation with stained MHC (red), F-actin (green) and nuclei (blue). Actin was stained with Phalloidin-iFluor 488. Scale bar = 100 μm. Source: <b>3D bioprinted functional skeletal muscle models have potential applications for studies of muscle wasting in cancer cachexia</b> by Andrea García-Lizarribar et.al., <em>Biomaterials Advances</em> April 2023.
Myogenic differentiation in 3D bioprinted models. Immunostaining of C2C12 cells after 15 days in bioprinted rings cultured in differentiation medium (DM) and growth medium (GM). Nuclei are stained in blue and green corresponds to F-actin (n = 4). Scale bar = 200 μm. Actin was stained with Phalloidin-iFluor 488.
Source: <b>3D bioprinted functional skeletal muscle models have potential applications for studies of muscle wasting in cancer cachexia</b> by Andrea García-Lizarribar et.al., <em>Biomaterials Advances</em> April 2023.
