Rhod-FF, AM
Ordering information
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Additional ordering information
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
International | See distributors |
Bulk request | Inquire |
Custom size | Inquire |
Shipping | Standard overnight for United States, inquire for international |
Physical properties
Dissociation constant (Kd, nM) | 19000 |
Molecular weight | 1145.90 |
Solvent | DMSO |
Spectral properties
Excitation (nm) | 553 |
Emission (nm) | 577 |
Storage, safety and handling
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
Storage | Freeze (< -15 °C); Minimize light exposure |
UNSPSC | 12352200 |
Overview | ![]() ![]() |
Molecular weight 1145.90 | Dissociation constant (Kd, nM) 19000 | Excitation (nm) 553 | Emission (nm) 577 |
Calcium measurement is critical for numerous biological investigations. Fluorescent probes that show spectral responses upon binding Ca2+ have enabled researchers to investigate changes in intracellular free Ca2+ concentrations by using fluorescence microscopy, flow cytometry, fluorescence spectroscopy and fluorescence microplate readers. Rhod-FF AM is cell-permeable, and generates Rhod-FF upon esterase hydrolysis in cells. Rhod-FF has a lower binding affinity for Ca2+ and is suitable for Ca2+ measurements from 10 to 200 uM. Like the parent Rhod-2 indicator, Rhod-FF is essentially nonfluorescent in the absence of divalent cations and exhibits strong fluorescence enhancement with no spectral shift upon binding Ca2+.
Platform
Fluorescence microscope
Excitation | TRITC filter set |
Emission | TRITC filter set |
Recommended plate | Black wall/clear bottom |
Fluorescence microplate reader
Excitation | 540 |
Emission | 590 |
Cutoff | 570 |
Recommended plate | Black wall/clear bottom |
Instrument specification(s) | Bottom read mode/Programmable liquid handling |
Example protocol
PREPARATION OF STOCK SOLUTIONS
Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.
Rhod-FF AM Stock Solution
Prepare a 2 to 5 mM stock solution of Rhod-FF AM in high-quality, anhydrous DMSO.PREPARATION OF WORKING SOLUTION
Rhod-FF AM Working Solution
On the day of the experiment, either dissolve Rhod-FF AM in DMSO or thaw an aliquot of the indicator stock solution to room temperature. Prepare a dye working solution of 2 to 20 µM in a buffer of your choice (e.g., Hanks and Hepes buffer) with 0.04% Pluronic® F-127. For most cell lines, Rhod-FF AM at a final concentration of 4-5 μM is recommended. The exact concentration of indicators required for cell loading must be determined empirically.Note The nonionic detergent Pluronic® F-127 is sometimes used to increase the aqueous solubility of Rhod-FF AM. A variety of Pluronic® F-127 solutions can be purchased from AAT Bioquest.
Note If your cells contain organic anion-transporters, probenecid (1-2 mM) may be added to the dye working solution (final in well concentration will be 0.5-1 mM) to reduce leakage of the de-esterified indicators. A variety of ReadiUse™ probenecid products, including water-soluble, sodium salt, and stabilized solution, can be purchased from AAT Bioquest.
SAMPLE EXPERIMENTAL PROTOCOL
Following is our recommended protocol for loading AM esters into live cells. This protocol only provides a guideline and should be modified according to your specific needs.
- Prepare cells in growth medium overnight.
- On the next day, add 1X Rhod-FF AM working solution into your cell plate.
Note If your compound(s) interfere with the serum, replace the growth medium with fresh HHBS buffer before dye-loading. - Incubate the dye-loaded plate in a cell incubator at 37 °C for 30 to 60 minutes.
Note Incubating the dye for longer than 1 hour can improve signal intensities in certain cell lines. - Replace the dye working solution with HHBS or buffer of your choice (containing an anion transporter inhibitor, such as 1 mM probenecid, if applicable) to remove any excess probes.
- Add the stimulant as desired and simultaneously measure fluorescence using either a fluorescence microscope equipped with a TRITC filter set or a fluorescence plate reader containing a programmable liquid handling system such as an FDSS, FLIPR, or FlexStation, at Ex/Em = 540/590 nm cutoff 570 nm.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of Rhod-FF, AM to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 87.268 µL | 436.338 µL | 872.676 µL | 4.363 mL | 8.727 mL |
5 mM | 17.454 µL | 87.268 µL | 174.535 µL | 872.676 µL | 1.745 mL |
10 mM | 8.727 µL | 43.634 µL | 87.268 µL | 436.338 µL | 872.676 µL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Product Family
Name | Excitation (nm) | Emission (nm) | Quantum yield |
Fura-FF, AM [Fura-2FF, AM] *CAS 348079-12-9* | 336 | 505 | - |
Rhod-2, AM *CAS#: 145037-81-6* | 553 | 577 | 0.11 |
Rhod-2, AM *UltraPure Grade* *CAS#: 145037-81-6* | 553 | 577 | 0.11 |
Rhod-5N, AM | 557 | 580 | - |
Rhod-4™, AM | 523 | 551 | 0.11 |
Citations
View all 2 citations: Citation Explorer
Activation of mitochondrial transient receptor potential vanilloid 1 channel contributes to microglial migration
Authors: Miyake, Takahito and Shirakawa, Hisashi and Nakagawa, Takayuki and Kaneko, Shuji
Journal: Glia (2015): 1870--1882
Authors: Miyake, Takahito and Shirakawa, Hisashi and Nakagawa, Takayuki and Kaneko, Shuji
Journal: Glia (2015): 1870--1882
ER stress in human hepatic cells treated with Efavirenz: mitochondria again
Authors: Apostolova, Nadezda and Gomez-Sucerquia, Leysa J and Alegre, Fern and o , undefined and Funes, Haryes A and Victor, Victor M and Barrachina, Maria D and Blas-Garcia, Ana and Esplugues, Juan V
Journal: Journal of hepatology (2013): 780--789
Authors: Apostolova, Nadezda and Gomez-Sucerquia, Leysa J and Alegre, Fern and o , undefined and Funes, Haryes A and Victor, Victor M and Barrachina, Maria D and Blas-Garcia, Ana and Esplugues, Juan V
Journal: Journal of hepatology (2013): 780--789
References
View all 2 references: Citation Explorer
Ionic calcium determination in skim milk with molecular probes and front-face fluorescence spectroscopy: simple linear regression
Authors: Gangidi RR, Metzger LE.
Journal: J Dairy Sci (2006): 4105
Authors: Gangidi RR, Metzger LE.
Journal: J Dairy Sci (2006): 4105
Measurement of limestone biodeterioration using the Ca2+ binding fluorochrome Rhod-5N
Authors: McNamara CJ, Perry TDt, Bearce K, Hern and ez-Duque G, Mitchell R.
Journal: J Microbiol Methods (2005): 245
Authors: McNamara CJ, Perry TDt, Bearce K, Hern and ez-Duque G, Mitchell R.
Journal: J Microbiol Methods (2005): 245
