5-Carboxyrhodamine 6G maleimide

Chemical structure for 5-Caroxyrhodamine 6G maleimide.
Chemical structure for 5-Caroxyrhodamine 6G maleimide.
Ordering information
Price ()Discontinued
Catalog Number353
Unit Size
Find Distributor
Additional ordering information
Telephone1-408-733-1055
Fax1-408-733-1304
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Physical properties
Molecular weight765.74
SolventDMSO
Spectral properties
Absorbance (nm)530
Extinction coefficient (cm -1 M -1)1160001
Excitation (nm)525
Emission (nm)548
Quantum yield0.951
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12171501
Related products
Rhodamine 700 *CAS 63561-42-2*
Rhodamine 800 *CAS 137993-41-0*
Rhodamine B *CAS 81-88-9*
Rhodamine 6G *CAS 989-38-8*
Sulforhodamine 101, sodium salt
Sulforhodamine B *CAS 3520-42-1*
Sulforhodamine G *CAS 5873-16-5*
Rhodamine 101 Inner Salt *CAS 116450-56-7*
Rhodamine 101 Chloride Salt *CAS 64339-18-0*
Sulforhodamine 101 sodium salt *CAS 465544-24-5*
Rhodamine 110 *CAS 13558-31-1*
5-CR110 [5-Carboxyrhodamine 110] *Single isomer*
6-CR110 [6-Carboxyrhodamine 110] *Single isomer*
5(6)-CR6G [5-(and 6)-Carboxyrhodamine 6G]
5-CR6G [5-Carboxyrhodamine 6G] *Single isomer*
6-CR6G [6-Carboxyrhodamine 6G] *Single isomer*
5(6)-CR6G, SE [5-(and 6)-Carboxyrhodamine 6G, succinimidyl ester] *Mixed isomers*
6-CR6G, SE [6-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer*
5(6)-Carboxyrhodamine 6G cadaverine
5(6)-Carboxyrhodamine 6G ethylenediamine
5-CR6G, SE [5-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer*
5(6)-TAMRA [5(6)-Carboxytetramethylrhodamine] *CAS 98181-63-6*
5-TAMRA [5-Carboxytetramethylrhodamine] *CAS 91809-66-4*
6-TAMRA [6-Carboxytetramethylrhodamine] *CAS 91809-67-5*
5(6)-TAMRA, SE [5-(and-6)-Carboxytetramethylrhodamine, succinimidyl ester] *CAS 246256-50-8*
5-TAMRA, SE [5-Carboxytetramethylrhodamine, succinimidyl ester] *CAS#: 150810-68-7*
6-TAMRA, SE [6-Carboxytetramethylrhodamine, succinimidyl ester] *CAS#: 150810-69-8*
5(6)-ROX [5-(and 6)-Carboxy-X-rhodamine] *CAS 198978-94-8*
5-ROX [5-Carboxy-X-rhodamine] *CAS 216699-35-3*
6-ROX [6-Carboxy-X-rhodamine] *CAS 194785-18-7*
5(6)-ROX, SE [5-(and-6)-Carboxy-X-rhodamine, succinimidyl ester] *Mixed isomers*
5-ROX, SE [5-Carboxy-X-rhodamine, succinimidyl ester] *CAS 209734-74-7*
6-ROX, SE [6-Carboxy-X-rhodamine, succinimidyl ester] *CAS#: 216699-36-4*
5(6)-TRITC [Tetramethylrhodamine-5-(and-6)-isothiocyanate] *CAS 95197-95-8*
5(6)-TAMRA Maleimide [Tetramethylrhodamine-5-(and-6)-maleimide] *Mixed isomers*
5-TRITC [Tetramethylrhodamine-5-isothiocyanate] *CAS 80724-19-2*
6-TRITC [Tetramethylrhodamine-6-isothiocyanate] *CAS 80724-20-5*
6-TAMRA Maleimide [Tetramethylrhodamine-6-maleimide] *CAS 174568-68-4*
5-TAMRA Maleimide [Tetramethylrhodamine-5-maleimide] *CAS 154480-30-5*
Lissamine Rhodamine B Sulfonyl Chloride [Sulforhodamine B sulfonyl chloride] *CAS 62796-29-6*
Sulforhodamine 101 sulfonyl chloride [Texas Red®] *CAS 82354-19-6*
SRB-VAD-FMK [Sulforhodamine B-VAD-FMK]
Dihydrorhodamine 123 *CAS 109244-58-8*
Tetramethylrhodamine-dUTP *1 mM in Tris Buffer (pH 7.5)*
Rhodamine 123 *CAS 62669-70-9*
Rhodamine B, hexyl ester, perchlorate
TMRE [Tetramethylrhodamine ethyl ester] *CAS#: 115532-52-0*
TMRM [Tetramethylrhodamine methyl ester] *CAS#: 115532-50-8*
Phalloidin-Tetramethylrhodamine Conjugate
5-dR6G [5-Carboxy-4,7-dichlororhodamine 6G]
6-dR6G [6-Carboxy-4,7-dichlororhodamine 6G]
5-dR110 [5-Carboxy-4,7-dichlororhodamine 110]
6-dR110 [6-Carboxy-4,7-dichlororhodamine 110]
Bis-L-Aspartic acid Beta-rhodamine 110
Bis-Arg-rhodamine 110
Sulforhodamine 101 *CAS 60311-02-6*
Rhodamine aldehyde [5-TAMRA aldehyde]
Show More (57)

OverviewpdfSDSpdfProtocol


Molecular weight
765.74
Absorbance (nm)
530
Extinction coefficient (cm -1 M -1)
1160001
Excitation (nm)
525
Emission (nm)
548
Quantum yield
0.951
5-CR6G maleimide is a thiol-reactive derivative of rhodamine 6G. It is preferred choice (than the mixed isomers) for some complicated biological applications where reproducibility is more critical than material cost since the minor positional difference between 5-CR6G and 6-CR6G might significantly affect some biological properties of the underlying conjugates. Rhodamine 6G is one of the brightest rhodamine dyes, but most of the rhodamine 6G dyes have much lower solubility than other rhodamine dyes. For similar or equivalent spectral properties, iFluor dyes have much better water solubilities.

Calculators


Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of 5-Carboxyrhodamine 6G maleimide to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

0.1 mg0.5 mg1 mg5 mg10 mg
1 mM130.593 µL652.963 µL1.306 mL6.53 mL13.059 mL
5 mM26.119 µL130.593 µL261.185 µL1.306 mL2.612 mL
10 mM13.059 µL65.296 µL130.593 µL652.963 µL1.306 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)Molecular weightVolume (Calculate)Concentration (Calculate)Moles
/=x=

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Absorbance (nm)530
Extinction coefficient (cm -1 M -1)1160001
Excitation (nm)525
Emission (nm)548
Quantum yield0.951
