Amplite® Rapid Colorimetric Biotin Quantitation Kit *Optimized to Use with Nanodrop*

Ordering information
Price
Catalog Number
Unit Size
Quantity
Add to cart
Additional ordering information
Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
ShippingStandard overnight for United States, inquire for international
Request quotation
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
Related products
Biotin *CAS 58-85-5*
Biotin, succinimidyl ester *CAS 35013-72-0*
Biotin ethylenediamine *CAS 1217450-40-2*
Biotin cadaverine
Biotin C2 maleimide
Biotin-4-fluorescein *CAS 1032732-74-3*
Biotin hydrazide *CAS 66640-86-6*
Biotin-X NTA [Biotin-X nitrilotriacetic acid, potassium salt] *CAS 856661-92-2*
Biotin-X, succinimidyl ester *CAS 72040-63-2*
Biotin PEG2 amine *CAS 138529-46-1*
Biotin PEG2 maleimide *CAS 305372-39-8*
Biotin PEG2 succinimidyl ester
Biotin-PEG3-azide *CAS 875770-34-6*
Biotin Azide
Biotin Alkyne *CAS 773888-45-2*
Biotin PEG4 succinimidyl ester
ReadiView™ biotin acid
ReadiView™ biotin amine
ReadiView™ biotin hydrazide
ReadiView™ biotin maleimide
ReadiView™ biotin succinimidyl ester
ReadiLink™ Protein Biotinylation Kit *Powered by ReadiView™ Biotin Visionization Technology*
Amplite® Colorimetric Biotin Quantitation Kit
Biotin-11-dUTP *1 mM in TE Buffer (pH 7.5)* *CAS 86303-25-5*
Biotin-16-dUTP *1 mM in TE Buffer (pH 7.5)* *CAS 136632-31-0*
Biotin-20-dUTP *1 mM in TE Buffer (pH 7.5)*
Cal-520®-Biotin Conjugate
Phalloidin-Biotin Conjugate
FMOC-Lys(Biotin)-OH
Biotin-14-dCTP *1 mM in Tris Buffer (pH 7.5)*
Biotin PEG3 amine
Annexin V-Biotin conjugate
N6-Methyladenosine-Biotin conjugate
Biotin Styramide *Superior Replacement for Biotin Tyramide*
Cy5 biotin conjugate
Biotin-cAMP conjugate
2',3'-cGAMP-Biotin conjugate
Cy5.5 biotin conjugate
Biotin-PEG4-tyramide
HRP-Biotin Conjugate
Biotin-11-dATP *1 mM in Tris Buffer (pH 7.5)*
Biotin-11-dGTP *1 mM in Tris Buffer (pH 7.5)*
Biotin NTA
Biotin-X IDA
ReadiCleave™ SSL biotin NHS ester
Biotin-dT Phosphoramidite
ReadiLink™ Biotin Nick Translation dsDNA Labeling Kit
ReadiLink™ Biotin Oligo and ssDNA Labeling Kit
AF532 PEG4 biotin conjugate
Biotin PEG 4 Alkyne
Cy3 biotin conjugate
Cy7 biotin conjugate
Biotin C2 Azide
mFluor™ UV 375 Biotin Conjugate
mFluor™ UV 460 Biotin Conjugate
mFluor™ Violet 500 Biotin Conjugate
mFluor™ Violet 540 Biotin Conjugate
mFluor™ Red 780 Biotin Conjugate
Biotin Phosphoramidite
Bio-16-UTP [Biotin-16-UTP] *1 mM*
Biotin PEG4 amine
mFluor™ Violet 450-PEG4-Biotin Conjugate
Acridinium Biotin Conjugate
FastClick™ Biotin Azide
FastClick™ Biotin Alkyne
ReadiLeave™ Reversible Biotin Succinimidyl Ester
ReadiLeave™ Reversible Biotin Maleimide
ReadiLeave™ Reversible Biotin Azide
ReadiLeave™ Reversible Biotin Alkyne
ReadiLeave™ Reversible Biotin Amine
Xylazine-Biotin Conjugate
Amplite® Fluorimetric Biotin Quantitation Kit
Portelite™ Rapid Fluorimetric Biotin Quantitation Kit *Optimized to Use with CytoCite™ and Qubit™ Fluorometers*
Biotin-PEG2-azide *CAS 945633-30-7*
Show More (64)

OverviewpdfSDSpdfProtocol


Amplite™ Colorimetric Biotin Quantitation Kit is designed to quantify the number of biotins attached to a protein or other macromolecule with a Nanodrop Spectrometer. The kit uses HABA (4’-hydroxyazobenzene-2-carboxylic acid) reagent that demonstrates a dramatic spectral change when bound to avidin. Biotin easily displaces HABA from the HABA/avidin complex, resulting in a decrease of absorption at 500 nm. By measuring the absorbance change before and after the addition of the biotin-containing sample at 500 nm, the amount of biotin in a sample can be quantified spectrophotometrically. The kit is best used to determine biotin concentration in the range from 2 to 16 µM. It is optimized to use with Nanodrop spectrometer. Biotin is a relatively small molecule that is routinely conjugated to antibodies and proteins with minimal interference of their biological activity. The avidin/streptavidin-biotin interaction is the strongest known binding pair between a protein and its ligand. The biotin-avidin interaction has been extensively explored for a variety of biological applications.

Components


Example protocol


PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles

100X Avidin Stock Solution
  1. To prepare a 100X Avidin stock solution, add 40 µL of ddH2O into the vial of Avidin (Component A), and mix thoroughly.

    Note: Any unused 100X Avidin stock solution should be divided into single-use aliquots and stored at -20°C.

PREPARATION OF WORKING SOLUTION

HABA/Avidin Working Solution
  1. To prepare a HABA/avidin working solution, add 2 µL of the 100X Avidin stock solution into 200 µL of the HABA assay buffer (Component B), and mix thoroughly.

    Note: Any unused HABA/avidin working solution can be store for up to one week at 4°C.

SAMPLE EXPERIMENTAL PROTOCOL

Quantitate Amount Biotin with a Nanodrop
  1. Prepare the following controls and samples as outlined in the table below:

    Positive ControlNegative ControlTest Sample*
    d-Biotin (Component C): 2 µLddH2O: 2 µL2 µL
    HABA/Avidin working solution: 18 µLHABA/Avidin working solution: 18 µLHABA/Avidin working solution: 18 µL

    Note: To ensure the concentration of biotin falls within the assay's linear range (2-16 μM of biotin final concentration), it is necessary to test the biotin-containing samples at several dilutions.

    Note: To ensure assay accuracy, avoid using buffers containing potassium, as it causes precipitation.

    Note: Free biotin must be separated from the biotinylated protein by gel filtration or dialysis.

  2. Incubate the reaction mixture at room temperature for 5 minutes, protected from light. Avoid creating bubbles during pipetting.

  3. Monitor absorbance at 500 nm using a Nanodrop Spectrometer, with a sample measurement of 2~2.5 µL. Utilize the protein label function for readings.

DATA ANALYSIS - CALCULATIONS
1. Calculate the change of absorbance at 500 nm:

ΔA500 = A500 of negative control - A500 of Biotin sample or positive control

2. Calculate the biotin concentration (M):

M = [ΔA500 ÷ εHABA/Biotin] x DF

Where:

  • εHABA/Biotin = 34,500 M-1cm-1
  • DF = Dilution Factor
3. Calculate protein concentration (P)

P = protein concentration (mg/mL) ÷ molecular weight of protein

4. Calculate molar ratio of biotin to protein (MR)

MR = M/P

Where:

  • M = Biotin Concentration
  • P = Protein Concentration

References


View all 50 references: Citation Explorer
Quantification of Hepatitis E Virus ORF2 Protein by a Novel Sandwich ELISA.
Authors: Subramaniam, Sakthivel and Fares-Gusmao, Rafaelle and McGivern, David R
Journal: Viruses (2024)
A picogram BA-ELISA quantification assay for rLj-RGD3, a platelet fibrinogen receptor antagonist, in the rat plasma and its application to a pharmacokinetic study.
Authors: Wang, Yuping and Liu, Zhien and Han, Guozhu and Yu, Ping and Yang, Xiaobo and Wang, Jihong and Lv, Li
Journal: PLoS neglected tropical diseases (2023): e0011568
Simultaneous quantification of multiple single nucleotide variants in PIK3CA ctDNA using mass-tagged LCR probe sets.
Authors: Wang, Zhongcheng and Li, Li and Kuang, Yuqiong and Yao, Jiang and Xu, Feifei and Chen, Yun
Journal: Talanta (2023): 124426
Quantification of 10 B vitamins in mouse colon by LC-MS/MS: Application on breast cancer mice treated with doxorubicin.
Authors: Wu, Jing and Xu, Yan and Yang, Jiahong and Yu, Xinyue and Han, Zhaodi and Guo, Linling and Huang, Yin and Zhang, Yuxin
Journal: Journal of chromatography. B, Analytical technologies in the biomedical and life sciences (2023): 123714
Mitochondrial Replication Assay (MIRA) for Efficient in situ Quantification of Nascent mtDNA and Protein Interactions with Nascent mtDNA (mitoSIRF).
Authors: Lozen, Macy and Chen, Yue and Boisvert, Rebecca A and Schlacher, Katharina
Journal: Bio-protocol (2023): e4680
A Chemiluminescence Enzyme Immunoassay Based on Biotinylated Nanobody and Streptavidin Amplification for Diazinon Sensitive Quantification.
Authors: Guo, Pengyan and Huang, Kaiyin and Chen, Zijian and Xu, Zhenlin and Ou, Aifen and Yin, Qingchun and Wang, Hong and Shen, Xing and Zhou, Kai
Journal: Biosensors (2023)
Multiplex Digital Quantification of β-Lactamase Genes in Antibiotic-Resistant Bacteria by Counting Gold Nanoparticle Labels on Silicon Microchips.
Authors: Presnova, Galina V and Presnov, Denis E and Filippova, Anna A and Tsiniaikin, Ilia I and Ulyashova, Mariya M and Rubtsova, Maya Yu
Journal: Biosensors (2022)
Simple Amplifier Coupled with a Lanthanide Labeling Strategy for Multiplexed and Specific Quantification of MicroRNAs.
Authors: Kang, Qi and Chen, Beibei and He, Man and Hu, Bin
Journal: Analytical chemistry (2022): 12934-12941
Selective quantification of the 22-kDa isoform of human growth hormone 1 in serum and plasma by immunocapture and LC-MS/MS.
Authors: Sleumer, Bas and van Faassen, Martijn and Vos, Michel J and Bischoff, Rainer and Kema, Ido P and van de Merbel, Nico C
Journal: Analytical and bioanalytical chemistry (2022): 6187-6200
Quantification of mRNA in Single Cells Based on Dimerization-Induced Photoluminescence Nonblinking of Quantum Dots.
Authors: Yang, Jie and Dong, Chaoqing and Zhang, Aidi and Ren, Jicun
Journal: Analytical chemistry (2022): 12407-12415
