Cy3 tyramide

Immunofluorescent image of paraffin-embedded human lung carcinoma labeled with EpCAM Rabbit mAb followed with HRP-labeled goat anti-rabbit IgG (H+L) (Cat#16793). The signal was developed with AAT’s Cy3 tyramide (Cat#11065, Red). Cells were also counterstained with DAPI (Blue).
Immunofluorescent image of paraffin-embedded human lung carcinoma labeled with EpCAM Rabbit mAb followed with HRP-labeled goat anti-rabbit IgG (H+L) (Cat#16793). The signal was developed with AAT’s Cy3 tyramide (Cat#11065, Red). Cells were also counterstained with DAPI (Blue).
Chemical structure for Cy3 tyramide
Ordering information
Price ()
Catalog Number11065
Unit Size
Find Distributor
Additional ordering information
Telephone1-408-733-1055
Fax1-408-733-1304
Emailsales@aatbio.com
InternationalSee distributors
ShippingStandard overnight for United States, inquire for international
Physical properties
Molecular weight863.96
SolventDMSO
Spectral properties
Correction Factor (260 nm)0.07
Correction Factor (280 nm)0.073
Extinction coefficient (cm -1 M -1)1500001
Excitation (nm)555
Emission (nm)569
Quantum yield0.151
Storage, safety and handling
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12171501
Direct upgrades
iFluor® 555 Tyramide

OverviewpdfSDSpdfProtocol


Molecular weight
863.96
Correction Factor (260 nm)
0.07
Correction Factor (280 nm)
0.073
Extinction coefficient (cm -1 M -1)
1500001
Excitation (nm)
555
Emission (nm)
569
Quantum yield
0.151
For many immunohistochemical (IHC) applications, the traditional enzymatic amplification procedures are sufficient for achieving adequate antigen detection. However, several factors limit the sensitivity and utility of these procedures. Tyramide signal amplification (TSA) has proven to be a particularly versatile and powerful enzyme amplification technique with improved assay sensitivity. TSA is based on the ability of HRP, in the presence of low concentrations of hydrogen peroxide, to convert labeled tyramine-containing substrate into an oxidized, highly reactive free radical that can covalently bind to tyrosine residues at or near the HRP. To achieve maximal IHC detection, tyramine is prelabeled with a fluorophore. The signal amplification conferred by the turnover of multiple tyramide substrates per peroxidase label translates ultrasensitive detection of low-abundance targets and the use of smaller amounts of antibodies and hybridization probes. In immunohistochemical applications, sensitivity enhancements derived from TSA method allow primary antibody dilutions to be increased to reduce nonspecific background signals, and can overcome weak immunolabeling caused by suboptimal fixation procedures or low levels of target expression. Cy3 tyramide contains the bright Cy3 that can be readily detected with the standard Cy3 filter set.

Platform


Fluorescence microscope

ExcitationCy3/TRITC filter set
EmissionCy3/TRITC filter set
Recommended plateBlack wall/clear bottom
Instrument specification(s)Cy3/TRITC filter set

Example protocol


AT A GLANCE

Protocol summary

  1. Fix/permeabilize/block cells or tissue
  2. Add primary antibody in blocking buffer
  3. Add HRP-conjugated secondary antibody
  4. Prepare tyramide working solution and apply in cells or tissue for 5-10 minutes at room temperature

Cat. #

Product Name

Unit

Ex (nm)

Em (nm)

11070

AF 488 Tyramide reagent

200 slides

491

518

11075

AF 546 Tyramide reagent

200 slides

554

570

11082

AF 594 Tyramide reagent

200 slides

590

617

11061

Azido-Cy5 Tyramide

1 mg

644

665

11065

Cy3 Tyramide

1 mg

555

565

11066

Cy5 Tyramide

1 mg

644

665

45100

iFluorTM 488 Tyramide

200 slides

491

514

45105

iFluorTM 555 Tyramide

200 slides

552

567

45110

iFluorTM 647 Tyramide

200 slides

649

665

PREPARATION OF STOCK SOLUTION

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

Tyramide stock solution (1000X):
Add appropriate amount of DMSO to make 1-5 mM of Tyramide stock solution. Note: Unused Tyramide stock solution can be stored at 2-8o C.

PREPARATION OF WORKING SOLUTION

Tyramide working solution (1X):
Add 1 µL of Tyramide stock solution into 1 mL of buffer of your choice containing 0.003% H2O2Note: Tris Buffer, pH=7.4 can be used for optimal performance. Note: Tyramide working solution should be used immediately and made fresh on the day of use.

SAMPLE EXPERIMENTAL PROTOCOL

This protocol is applicable for both cells and tissues staining.

Cell fixation and permeabilization

  1. Fix the cells or tissue with 3.7% formaldehyde or paraformaldehyde, in PBS at room temperature for 20 minutes.

  2. Rinse the cells or tissue with PBS twice.

  3. Permeabilize the cells with 0.1% Triton X-100 solution for 1-5 minutes at room temperature.

  4. Rinse the cells or tissue with PBS twice.

 Tissue fixation, deparaffinization and rehydration

Deparaffinize and dehydrate the tissue according to the standard IHC protocols. Perform antigen retrieval with preferred specific solution/protocol as needed.

Protocol can be found at
https://www.aatbio.com/resources/guides/paraffin-embedded-tissue-immunohistochemistry-protocol.html

 Peroxidase labeling

  1. Optional: Quench endogenous peroxidase activity by incubating cell or tissue sample in peroxidase quenching solution (such as 3% hydrogen peroxide) for 10 minutes. Rinse with PBS twice at room temperature.

  2. Optional: If using HRP-conjugated streptavidin, it is advisable to block endogenous biotins by biotin blocking buffer.

  3. Block with preferred blocking solution (such as PBS with 1% BSA) for 30 minutes at 4°C.

  4. Remove blocking solution and add primary antibody diluted in recommended antibody diluent for 60 minutes at room temperature or overnight at 4°C.

  5. Wash with PBS three times for 5 minutes each.

  6. Apply 100 µL of secondary antibody-HRP working solution to each sample and incubate for 60 minutes at room temperature. Note: Incubation time and concentration can be varied depending on the signal intensity.

  7. Wash with PBS three times for 5 minutes each.

 Tyramide labeling

  1. Prepare and apply 100 µL of Tyramide working solution to each sample and incubate for 5-10 minutes at room temperature. Note: If you observe non-specific signal, you can shorten the incubation time with Tyramide.  You should optimize the incubation period using positive and negative control samples at various incubation time points. Or you can use lower concentration of Tyramide in the working solution.

  2. Rinse with PBS three times.

 Counterstain and fluorescence imaging

  1. Counterstain the cell or tissue samples as needed. AAT provides a series of nucleus counterstain reagents as listed in Table 1. Follow the instruction provided with the reagents.

  2. Mount the coverslip using a mounting medium with anti-fading properties.

  3. Use the appropriate filter set to visualize the signal from the Tyramide labeling.

Table 1. Products recommended for nucleus counterstain.

Cat#

Product Name

Ex/Em (nm)

17548

Nuclear Blue™ DCS1

350/461

17550

Nuclear Green™ DCS1

503/526

17551

Nuclear Orange™ DCS1

528/576

17552

Nuclear Red™ DCS1

642/660

Calculators


Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of Cy3 tyramide to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.

0.1 mg0.5 mg1 mg5 mg10 mg
1 mM115.746 µL578.73 µL1.157 mL5.787 mL11.575 mL
5 mM23.149 µL115.746 µL231.492 µL1.157 mL2.315 mL
10 mM11.575 µL57.873 µL115.746 µL578.73 µL1.157 mL

Molarity calculator

Enter any two values (mass, volume, concentration) to calculate the third.

Mass (Calculate)Molecular weightVolume (Calculate)Concentration (Calculate)Moles
/=x=

Spectrum


Open in Advanced Spectrum Viewer
spectrum

Spectral properties

Correction Factor (260 nm)0.07
Correction Factor (280 nm)0.073
Extinction coefficient (cm -1 M -1)1500001
Excitation (nm)555
Emission (nm)569
Quantum yield0.151

Product family


NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yieldCorrection Factor (260 nm)Correction Factor (280 nm)
Cy3 tetrazine55556915000010.1510.070.073
Cy3 phosphoramidite55556915000010.1510.070.073
Cy3 aldehyde55556915000010.1510.070.073
DBCO-Cy355556915000010.1510.070.073
Cy5 tyramide65167025000010.271, 0.420.020.03
Biotinyl tyramide------
Cy7 tyramide7567792500000.30.050.036
XFD514 tyramide51854380000-0.310.18
XFD532 tyramide534553810000.6110.240.09
Fluorescein Tyramide4985178000010.79001, 0.9520.320.275
Show More (11)
