MMP Green™ substrate

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
International	See distributors
Bulk request	Inquire
Custom size	Inquire
Shipping	Standard overnight for United States, inquire for international

Physical properties

Molecular weight	~2000
Solvent	DMSO

Spectral properties

Excitation (nm)	494
Emission (nm)	515

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
Storage	Freeze (< -15 °C); Minimize light exposure
UNSPSC	12352200

Alternative formats

Overview SDS Protocol

Platform

Fluorescence microplate reader

Excitation	490 nm
Emission	525 nm
Cutoff	515 nm
Recommended plate	Solid black

Example protocol

AT A GLANCE

Protocol summary

Add appropriate controls or test samples with or without APMA (50 µL)
Pre-incubate for 10 - 15 minutes
Add MMP Green™ substrate working solution (50 µL)
Skip incubation step for kinetic reading or incubate for 30 to 60 minutes for end point reading
Monitor fluorescence intensity at Ex/Em = 490/525 nm

Important Thaw the reagents includig the substrate at room temperature before starting the experiment. Prepare MMPs containing biological samples as desired.

PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

MMP Green™ Substrate stock solution

For Cat# 13520, prepare 1- 10 mg/mL stock solution by adding appropriate amount of DMSO to MMP Green™ substrate vial.
Note Store stock solution in single used aliquots and protect from light.

PREPARATION OF WORKING SOLUTION

MMP Green™ Substrate working solution

For Cat# 13520, prepare 20-100 µg/mL MMP Green™ Substrate working solution in buffer of your choice. For Cat# 13519, Add 50 µL of MMP Green™ solution (vial provided) into 5 mL of buffer of your choice.

SAMPLE EXPERIMENTAL PROTOCOL

Table 1.Protocols for MMP activation.

MMPs	Activated by treating with
MMP-1 (collagenase)	1 mM APMA (diluted component C) at 37 °C for 3 hr
MMP-2 (gelatinase)	1 mM APMA (diluted component C) at 37 °C for 1 hr
MMP-3 (stromelysin)	1 mM APMA (diluted component C) at 37 °C for 24 hr
MMP-7 (matrilysin, PUMP-1)	1 mM APMA (diluted component C) at 37 °C for 20 min - 1 hr
MMP-8 (neutrophil collagenase)	1 mM APMA (diluted component C) at 37 °C for 1 hr
MMP-9 (92 kDa gelatinase)	1 mM APMA (diluted component C) at 37 °C for 2 h
MMP-10 (stromelysin-2)	1 mM APMA (diluted component C) at 37 °C for 24 hr
MMP-11 (stromelysin-3)	Already in active form. No APMA treatment is necessary
MMP-12 (macrophage elastase)	1 mM APMA (diluted component C) at 37 °C for 2 hr
MMP-13 (collagenase-3)	1 mM APMA (diluted component C) at 37°C for 40 min
MMP-14	1 mM APMA (diluted component C) at 37°C for 2 - 3 hr

Prepare MMPs containing biological samples as desired.
To activate pro-MMPs, add 2 mM APMA working solution (2X) to the plate.
Note APMA belongs to organic mercury. Handle with care! Dispose it according to local regulations. Next, incubate the MMP containing-samples or purified MMPs with equal volume of 2 mM APMA working solution (2X). Refer to Table 1 for incubation time. Activate MMPs immediately before the experiment.
Note Keep enzyme-containing samples on ice. Avoid vigorously vortexing the enzyme. Prolonged storage of the activated enzyme will deactivate the enzyme. For enzyme activation, it is preferably activated at higher protein concentration. After activation, you may further dilute the enzyme.
Prepare controls and test samples (TS) with 50 µL per well. For a 384-well plate, use 20 µL of reagent per well instead of 50 µL.
Pre-incubate the plate at a desired temperature for the enzyme reaction (e.g. 25 °C or 37 °C) for 10 - 15 minutes if you are screening MMPs inhibitors.
Add 50 µL (96-well) or 20 µL (384-well) of MMP Green™ substrate working solution to the sample and control wells of the assay plate. Mix the reagents well.
Monitor the fluorescence intensity with a fluorescence plate reader at Ex/Em = 490/525 nm. For kinetic reading: Immediately start measuring fluorescence intensity and continuously record data every 5 minutes for 30 to 60 minutes. For end-point reading: Incubate the reaction at room temperature for 30 to 60 minutes, kept from light if possible. Mix the reagents well, and then measure the fluorescence intensity.

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Excitation (nm)	494
Emission (nm)	515

Product Family

Name	Excitation (nm)	Emission (nm)
MMP Red™ substrate	545	572

Images

Figure 1. The internally quenched FRET peptide substrate is digested by a protease to generate the highly fluorescent peptide fragment. The fluorescence increase is proportional to the protease activity.
