FITC-xtra
Ordering information
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Additional ordering information
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
International | See distributors |
Bulk request | Inquire |
Custom size | Inquire |
Shipping | Standard overnight for United States, inquire for international |
Physical properties
Molecular weight | 620.52 |
Solvent | DMSO |
Spectral properties
Excitation (nm) | 498 |
Emission (nm) | 526 |
Storage, safety and handling
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
Storage | Freeze (< -15 °C); Minimize light exposure |
UNSPSC | 12171501 |
Overview | SDSProtocol |
See also: Fluoresceins
Molecular weight 620.52 | Excitation (nm) 498 | Emission (nm) 526 |
Although FITC is still the most popular fluorescent labeling dye for preparing green fluorescent bioconjugates, there are certain limitations with FITC, such as severe photobleaching for microscope imaging and pH-sensitive fluorescence. Protein conjugates prepared with FITC-xtra are far superior compared to the corresponding FITC conjugates. FITC-xtra conjugates are significantly brighter than FITC conjugates and are much more photostable. Additionally, the fluorescence of FITC-xtra is not affected by pH (4-10). This pH insensitivity is a major improvement over FITC, which emits its maximum fluorescence only at pH above 9. FITC-xtra has spectral properties almost identical FITC. In addition, FITC-xtra give much higher conjugation yield under mild conjugation conditions than FITC. Like 5-FITC, FITC-xtra antibody conjugates have excitation ideally suited to the 488 nm laser line, making them alternatives to the corresponding FITC-labeled antibody conjugates. Under the same conditions tested, FITC-xtra antibody conjugates give much higher signal/background ratios than the corresponding FITC-labeled conjugates.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of FITC-xtra to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 161.155 µL | 805.776 µL | 1.612 mL | 8.058 mL | 16.116 mL |
5 mM | 32.231 µL | 161.155 µL | 322.31 µL | 1.612 mL | 3.223 mL |
10 mM | 16.116 µL | 80.578 µL | 161.155 µL | 805.776 µL | 1.612 mL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Product Family
Name | Excitation (nm) | Emission (nm) | Extinction coefficient (cm -1 M -1) | Quantum yield | Correction Factor (280 nm) |
5-FITC [Fluorescein-5-isothiocyanate] *CAS 3326-32-7* | 491 | 516 | 73000 | 0.92 | 0.35 |
Images
Figure 1. HeLa cells were incubated with (Tubulin+) or without (Tubulin-) mouse anti-tubulin and biotin goat anti-mouse IgG followed by FITC-Xtra streptavidin conjugate (Green, Left) or FITC-streptavidin conjugate (Green, Right), respectively. Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
