The concentration of the gel is crucial for any gel electrophoresis experiment, and the optimal gel concentration, regardless of matrix type, for an experiment depends on the sizes of the starting proteins and desired fragments size.
Agarose Gel
For any gel used in electrophoresis, the concentration determines the resolution of the fragmented results. One of the largest benefits of agarose gels is their ease of construction. In essence, a desired amount of agarose powder can be mixed with tris-borate-EDTA (TAE) buffer, briefly heated, and dissolved.
Note: Caution must be taken to prevent bubbles from forming within the gel, as these may disrupt the integrity of the gel.
During the gelation process, agarose polymers associate non-covalently and form a polysaccharide web. The pore sizes of this web determine a gel's molecular sieving abilities. Though gels with 0.5-3% agarose concentration can be used, 0.7-2.0% is most common. Higher agarose concentration results in a greater resolving power, however gels that are too high in concentration are brittle and may not set evenly. Alternatively, low concentration of agarose gel can be used for isoelectric focusing, though gels that are too low in concentration are weak and may break when handled. Really, 0.7-2.0% agarose concentration leaves very little room for error, so it is critical that required concentration be determined prior to experimentation. For reference, approximate fragment resolution based on agarose concentration in agarose gels is shown below.
| Agarose Concentration | Native DNA (bp) |
|---|---|
| 0.50 % | 1,000-30,000 |
| 0.70 % | 800-12,000 |
| 1.00 % | 500-10,000 |
| 1.20 % | 400-7,000 |
| 1.50 % | 200-3,000 |
| 2.00 % | 50-2,000 |
Polyacrylamide Gel
Two-fold dilution series of His-tagged annexin V were separated on a NuPAGE® 4-12% Bis-Tris gel and stained with the ProLite™ His-Tag Protein Gel Staining Kit according to standard protocols. Lane 1: His-tagged protein ladder, Lane 2 to 5: two-fold dilution of His-tagged annexin V.
In SDS-PAGE, the gel is made of two parts, termed the stacking and resolving gels. The stacking gel is the upper portion of the gel close to the wells and is normally a concentration of around 4% acrylamide while the resolving gel located at the bottom of the assembly is usually a concentration of around 15%. In experimentation, the stacking gel concentrates the proteins into a sharp band prior to separation in the higher concentration resolving gel.
Alternatively, a gradient gel may be preferred. These gels have lower acrylamide percentages where the sample enters, which increases along the sample's path so that a broader range of protein sizes can be separated. Though the construction is timelier, polyacrylamide gradient gels allow for a broader range of protein sizes to be resolved in one gel, produce sharper bands, and better separate similar-sized proteins. For reference, approximate fragment resolution based on acrylamide concentration is shown below for double-stranded (native) and single-stranded (denatured) DNA.
| Acrylamide Concentration | Native DNA/RNA (bp) | Denatured DNA/RNA (bp) |
|---|---|---|
| 5.0 % | 200-2,000 | 70-800 |
| 6.0 % | 80-800 | 50-500 |
| 8.0 % | 60-400 | 30-300 |
| 10.0 % | 50-300 | 20-200 |
| 12.0 % | 40-200 | 15-150 |
| 20.0 % | 5-100 | 5-50 |
