iFluor® Dye Selection Guide

AAT Bioquest iFluor® dyes are a series of highly water-soluble fluorescent dyes for labeling biomolecules, such as proteins and antibodies. Available in a variety of excitation-emission profiles, spanning the UV-visible to near-infrared spectrum, there is an iFluor® dye to match any instrument set-up and many combinations for multiplex detection. Conjugates made with iFluor® dyes exhibit superior brightness and photostability, outperforming most Alexa Fluor® conjugates and other spectrally similar conjugates.


Benefits of iFluor® Dyes and Conjugates


Actin Stain

Figure 1. Image of HeLa cells stained with mouse anti-tubulin followed with iFluor® 594 goat anti-mouse IgG. Actin filaments were stained with Phalloidin-iFluor® 488 Conjugate and nuclei were stained with DAPI.

  • Brightness: iFluor® conjugates exhibit more intense fluorescence than other spectrally similar conjugates (e.g. Alexa Fluor® dyes, fluorescein dyes, cyanine dyes, etc.)
  • Photostability: iFluor® conjugates are more photostable than spectrally similar conjugates allowing for more time to capture images.
  • Water solubility: iFluor® reactive dyes are highly water soluble. Conjugation can be performed without organic solvents resulting in conjugates that are resistant to precipitation during storage.
  • pH insensitivity: iFluor® dyes are robust and highly fluorescent across a broad pH range.
  • Instrument compatibility: Absorption spectra of iFluor® dyes are matched to the principal output wavelengths of common excitation sources.
  • Color selection: iFluor® dyes are available in several distinct colors, ranging from violet (350 nm) to infrared (860 nm), maximizing choice and flexibility in multicolor analysis.



iFluor® Dyes Spectral Properties



iFluor® Dye Ex/Em (nm) Ext. Coeff.1 FQY2 CF at 260 nm3 CF at 280 nm4
iFluor® 350 344/488 20,000 0.95 0.83 0.23
iFluor® 405 402/425 37,000 0.91 0.48 0.77
iFluor® 430 433/495 40,000 0.78 0.68 0.3
iFluor® 440 434/480 40,000 N/D 0.352 0.229
iFluor® 450 451/502 40,000 0.82 0.45 0.27
iFluor® 488 491/516 75,000 0.9 0.21 0.11
iFluor® 514 527/554 80,000 0.83 0.25 0.11
iFluor® 532 543/563 90,000 0.68 0.26 0.16
iFluor® 546 541/557 100,000 0.67 0.25 0.15
iFluor® 555 556/569 100,000 0.64 0.23 0.14
iFluor® 560 559/571 130,000 0.57 0.048 0.069
iFluor® 568 568/587 100,000 0.57 0.34 0.15
iFluor® 594 587/603 180,000 0.53 0.05 0.04
iFluor® 610 609/627 110,000 0.85 0.32 0.49
iFluor® 633 638/652 250,000 0.29 0.062 0.044
iFluor® 647 654/669 250,000 0.25 0.03 0.03
iFluor® 660 660/677 250,000 0.26 0.07 0.08
iFluor® 670 669/682 250,000 0.63 0.019 0.024
iFluor® 680 683/700 220,000 0.23 0.097 0.094
iFluor® 700 690/713 220,000 0.23 0.09 0.04
iFluor® 710 712/736 190,000 0.14 0.12 0.07
iFluor® 750 759/777 275,000 0.12 0.044 0.039
iFluor® 790 786/811 275,000 0.13 0.1 0.09
iFluor® 800 801/820 250,000 0.11 0.03 0.08
iFluor® 810 811/822 250,000 0.05 0.09 0.15
iFluor® 820 820/849 250,000 N/D 0.11 0.16
iFluor® 840 836/876 200,000 0.02 0.2 0.09
iFluor® 860 852/877 250,000 N/D 0.1 0.14

Note:

  1. Ext. Coeff. = Extinction coefficient at their maximum absorption wavelength. The units of extinction coefficient are cm-1M-1.
  2. FQY = fluorescence quantum yield in aqueous buffer (pH 7.2).
  3. CF at 260 nm is the correction factor used for eliminating the dye contribution to the absorbance at 260 nm.
  4. CF at 280 nm is the correction factor used for eliminating the dye contribution to the absorbance at 280 nm (for peptides and protein labeling).
  5. Fluorescence intensity is significantly increased upon coupling to proteins.



iFluor® Dye Selection Guide



Fluorophore Ex/Em (nm) Alternative to Reative Targets
Amine Thiol Aldehyde Alkyne Azide
iFluor® 350 344/488 Coumarin • Alexa Fluor® 350 • DyLight™ 350 #1020   #1060 #1080 #1070
iFluor® 405 402/425 Cascade Blue® • Alexa Fluor® 405 • DyLight™ 405 #1021   #1053 #1081 #1071
iFluor® 430 433/495 Alexa Fluor® 430 #1052   #1054
iFluor® 440 434/480   #1041
iFluor® 450 451/502   #1026   #1057
iFluor® 488 492/516 Alexa Fluor® 488 • DyLight™ 488 #1023   #1062 #1082 #1072 #1000 #999
iFluor® 514 527/554 Alexa Fluor® 514 #1024
iFluor® 532 543/563 Alexa Fluor® 532 #1025   #1061
iFluor® 546 541/557 Alexa Fluor® 546 #1048
iFluor® 555 556/569 Cy3® • Alexa Fluor® 555 • DyLight™ 550 #1028   #1063 #1083 #1073 #1093 #1092
iFluor® 560 559/571   #1040
iFluor® 568 568/587 Rhodamine Red • Alexa Fluor® 568 #1049   #1055
iFluor® 594 587/603 Texas Red® • Alexa Fluor® 594 • DyLight™ 594 #1029   #1064
iFluor® 610 609/627 Alexa Fluor® 610 #1038
iFluor® 633 638/652 Alexa Fluor® 633 #1030   #1056
iFluor® 647 654/669 Cy5® • Alexa Fluor® 647 • DyLight™ 650 #1031   #1065 #1085 #1074 #1091 #1090
iFluor® 660 660/677 Alexa Fluor® 660 #1032       #1075
iFluor® 670 669/682 Cy5® B #1033
iFluor® 680 683/700 Cy5.5® • IRDye® 700 • Alexa Fluor® 680 #1035   #1066 #1086 #1076
iFluor® 700 690/713  Alexa Fluor® 700 #1036   #1067 #1087 #1077
iFluor® 710 712/736   #1045       #1078
iFluor® 750 759/777 Cy7® • Alexa Fluor® 750 • DyLight™ 750 #1037   #1068 #1088 #1079
iFluor® 790 786/811 IRDye® 800 • Alexa Fluor® 790 • DyLight™ 800 #1368 #1360 #1366 #1364 #1362
iFluor® 800 801/820   #1379 #1375 #1378
iFluor® 810 812   #1389 #1385 #1388
iFluor® 820 820   #1399 #1395 #1398
iFluor® 840 836   #1403 #1401 #1402
iFluor® 860 854   #1409 #1405 #1408
     Succinimidyl Ester Acid Maleimide Hydrazide Amine Azide Alkyne
Reactive Forms
