iFluor™ 488 succinimidyl ester

! Interactive Product Finder: This product has alternative forms and/or upgrades. View now


Image Viewer
Select color channel(s)
HeLa cells were incubated with (Tubulin+) or without (Tubulin-) mouse anti-tubulin followed by iFluor™ 488 goat anti-mouse IgG conjugate (Green, Left) or Alexa Fluor® 488 goat anti-mouse IgG conjugate (Green, Right), respectively. Cell nuclei were stained with Hoechst 33342 (Blue).
Roll over image to zoom in


Loading...

Unit Size: Cat No: Price (USD): Qty:
1 mg 1023 $195


Export item/cart as Excel file

Send item/cart as email
EXPORT TO EXCEL X

Export:
EXPORT TO EMAIL X
Important: We request your email address to ensure that the recipient(s) knows you intended for them to see the email, and that it is not junk mail.
Export:
Your Name*:
Your Email*:
Recipient Email*:
Your Personal Message:
Additional Ordering Information
Telephone: 1-800-990-8053
Fax: 1-408-733-1304
Email: sales@aatbio.com
International: See distributors





Overview

Ex/Em (nm)491/516
MW945.07
CF2800.11
CF2600.21
Quantum Yield0.9
Extinction Coefficient
(cm-1 M-1)
75000
SolventDMSO
Storage Freeze (<-15 °C)
Minimize light exposure
Category Superior Labeling Dyes
iFluor Dyes and Kits
Related Amine-Reactive Probes
Labeling via Amino Groups
Although FITC is still the most popular fluorescent labeling dye for preparing green fluorescent bioconjugates, there are certain limitations with FITC, such as severe photobleaching for microscope imaging and pH-sensitive fluorescence. Protein conjugates prepared with iFluor™ 488 dyes are far superior compared to conjugates of fluorescein derivatives such as FITC. iFluor™ 488 conjugates are significantly brighter than fluorescein conjugates and are much more photostable. Additionally, the fluorescence of iFluor™ 488 is not affected by pH (4-10). This pH insensitivity is a major improvement over fluorescein, which emits its maximum fluorescence only at pH above 9. iFluor™ 488 SE dye is reasonably stable and shows good reactivity and selectivity with protein amino groups. This iFluor™ 488 has spectral properties and reactivity similar to Alexa Fluor® 488 NHS ester ( Alexa Fluor® is the trademark of Invitrogen).




Calculators
Common stock solution preparation

Table 1. Volume of DMSO needed to reconstitute specific mass of iFluor™ 488 succinimidyl ester to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.



Molarity calculator

Table 2. Enter any two values (mass, volume, concentration) to calculate the third.

Mass Molecular weight Volume Concentration Moles
/ = x =







Spectrum Advanced Spectrum Viewer

Sorry, your browser does not support inline SVG. Relative Intensity (%) 100 80 60 40 20 0 Sorry, your browser does not support inline SVG.
Sorry, your browser does not support inline SVG. Sorry, your browser does not support inline SVG.
Move mouse over grid to display wavelength & intensity values.

300
400
500
600
700
800
900
Wavelength (nm)

















References

Deep Sequencing Analysis of the Eha-Regulated Transcriptome of Edwardsiella tarda Following Acidification
Authors: D Gao, N Liu, Y Li, Y Zhang, G Liu
Journal: Metabolomics (Los Angel) (2017): 2153--0769

Suramin inhibits cullin-RING E3 ubiquitin ligases
Authors: Kenneth Wu, Robert A Chong, Qing Yu, Jin Bai, Donald E Spratt, Kevin Ching, Chan Lee, Haibin Miao, Inger Tappin, Jerard Hurwitz
Journal: Proceedings of the National Academy of Sciences (2016): E2011--E2018

Glycosaminoglycan mimicry by COAM reduces melanoma growth through chemokine induction and function
Authors: Helene Piccard, Nele Berghmans, Eva Korpos, Chris Dillen, Ilse Van Aelst, Sandra Li, Erik Martens, Sandra Liekens, Sam Noppen, Jo Van Damme
Journal: International Journal of Cancer (2012): E425--E436






Resources

Safety Data Sheet (SDS)


Documents
1. AssayWise Letters 2012, Vol 1(1)

Certificate of Analysis
