LysoBrite™ Blue
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
International | See distributors |
Bulk request | Inquire |
Custom size | Inquire |
Shipping | Standard overnight for United States, inquire for international |
Molecular weight | 331.42 |
Solvent | DMSO |
Excitation (nm) | 434 |
Emission (nm) | 480 |
Certificate of Origin | Download PDF |
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
Storage | Freeze (< -15 °C); Minimize light exposure |
UNSPSC | 12352200 |
LysoBrite™ Red DND-99 |
LysoBrite™ Green DND-26 |
Overview | SDSProtocol |
Molecular weight 331.42 | Excitation (nm) 434 | Emission (nm) 480 |
Platform
Flow cytometer
Excitation | 405 nm laser |
Emission | 450/40 nm filter |
Instrument specification(s) | Pacific Blue channel |
Fluorescence microscope
Excitation | DAPI filter set |
Emission | DAPI filter set |
Recommended plate | Black wall/clear bottom |
Example protocol
AT A GLANCE
Prepare cells.
Add dye working solution.
Incubate at 37 °C for 30 minutes.
Wash the cells.
Analyze under a fluorescence microscope.
The LysoBrite™ Blue stock solution provided is 500X in DMSO. It should be stable for at least 6 months if stored at -20°C. Protect from light, and avoid freeze/thaw cycles.
PREPARATION OF WORKING SOLUTION
Warm LysoBrite™ Blue dye to room temperature.
Prepare dye working solution by diluting 20 µL of 500X LysoBrite™ Blue with 10 mL of Hanks and 20 mM HEPES buffer (HBSS) or buffer of your choice.
Note: 20 µL of LysoBrite™ Blue dye is enough for one 96-well plate. Aliquot and store unused LysoBrite™ dye stock solutions at < -15 °C. Protect it from light and avoid repeated freeze-thaw cycles.
Note: The optimal concentration of the fluorescent lysosome indicator varies depending on the specific application. The staining conditions may be modified according to the particular cell type and the permeability of the cells or tissues to the probe.
SAMPLE EXPERIMENTAL PROTOCOL
This protocol only provides a guideline and should be modified according to your specific needs.
Grow cells in a 96-well black wall/clear bottom plate (100 µL/well/96-well plate) or on coverslips inside a petri dish filled with the appropriate culture medium.
When cells reach the desired confluence, add an equal volume of the dye-working solution (from Preparation of Working Solution Step 2).
Incubate the cells in a 37 °C, 5% CO2 incubator for 30 minutes.
Wash the cells twice with pre-warmed (37 °C) Hanks and 20 mM HEPES buffer (HBSS) or buffer of your choice. Then fill the cell wells with HBSS or growth medium.
Observe the cells using a fluorescence microscope fitted with the desired filter set.
Note: It is recommended to increase either the labeling concentration or the incubation time to allow the dye to accumulate if the cells do not appear to be sufficiently stained.
Add an equal volume of the dye-working solution (from Preparation of Working Solution Step 2).
Incubate the cells in a 37 °C, 5% CO2 incubator for 30 minutes.
Wash the cells twice with pre-warmed (37 °C) Hanks and 20 mM HEPES buffer (HBSS) or buffer of your choice. Then fill the cell wells with HBSS or growth medium.
Observe the cells using a fluorescence microscope fitted with the desired filter set.
Note: It is recommended to increase either the labeling concentration or the incubation time to allow the dye to accumulate if the cells do not appear to be sufficiently stained.
Note: Suspension cells may be attached to coverslips treated with BD Cell-Tak® (BD Biosciences) and stained as adherent cells (see Protocol for Preparing and Staining Adherent Cells).
Calculators
Common stock solution preparation
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 301.732 µL | 1.509 mL | 3.017 mL | 15.087 mL | 30.173 mL |
5 mM | 60.346 µL | 301.732 µL | 603.464 µL | 3.017 mL | 6.035 mL |
10 mM | 30.173 µL | 150.866 µL | 301.732 µL | 1.509 mL | 3.017 mL |
Molarity calculator
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Product Family
Name | Excitation (nm) | Emission (nm) |
LysoBrite™ Green | 501 | 510 |
LysoBrite™ Orange | 543 | 565 |
LysoBrite™ Red | 576 | 596 |
LysoBrite™ Deep Red | 597 | 619 |
LysoBrite™ NIR | 636 | 651 |
