Live or Dead™ Fixable Dead Cell Staining Kit *Red Fluorescence Optimized for Flow Cytometry*


Excitation (nm)
Emission (nm)
Our Live or Dead™ Fixable Dead Cell Staining Kits are a set of tools for labeling cells for fluorescence microscopic investigations of cellular functions. The effective labeling of cells provides a powerful method for studying cellular events in a spatial and temporal context. This particular kit is designed to uniformly label fixed mammalian cells in red fluorescence for flow cytometry applications with blue or green laser excitation. The kit uses a proprietary red fluorescent dye that is more fluorescent upon binding to cellular components. The fluorescent dye used in the kit is well excited with the blue (488 nm) and green lasers (532 nm) to fluorescence at 620 nm. The kit provides all the essential components with an optimized cell-labeling protocol. It is an excellent tool for preserving of fluorescent images of particular cells, and can also be used for fluorescence flow cytometry applications.


Flow cytometer

Excitation488 nm or 532 nm laser
Emission610/20 nm filter


Example protocol


Protocol Summary
  1. Prepare samples in HHBS (0.5 mL/assay)
  2. Replace with HHBS
  3. Add Stain It™ Red 620 to the cell suspension
  4. Stain the cells at room temperature or 37 °C for 20 - 60 minutes
  5. Wash the cells
  6. Fix the cells (optional)
  7. Examine the sample with flow cytometer and/or fluorescence microscope using the appropriate Excitation/Emission filter
Important      Thaw all the components at room temperature before starting the experiment.


For guidelines on cell sample preparation, please visit https://www.aatbio.com/resources/guides/cell-sample-preparation.html


Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

Stain It™ Red 620 stock solution (500X)
Add 200 µL DMSO (Component B) into the vial of Stain It™ Red 620 (Component A) to have 500X Stain It™ Red 620 stock solution.


Table 1. Fluorescence spectra properties and suggested excitation laser for flow cytometry analysis
Cat. #DescriptionEx (nm)Em (nm)Excitation Source
22500Blue Fluorescence with 405 nm Excitation410450405 nm
22501Green Fluorescence with 405 nm Excitation408512405 nm
22502Orange Fluorescence with 405 nm Excitation398550405 nm
22599Red Fluorescence Optimized for Flow Cytometry523617488 nm
22600Blue Fluorescence353442335 nm
22601Green Fluorescence498521488 nm
22602Orange Fluorescence547573561 nm or 488 nm
22603Red Fluorescence583603 561 nm
22604Deep Red Fluorescence649660633 nm
22605Near Infrared Fluorescence749775 633 nm
  1. Prepare cells using 1X Hanks and 20 mM Hepes buffer (HHBS) or sodium azide-free and serum/protein-free buffer of your choice.
  2. Wash cells once with HHBS or the azide- and serum/protein-free buffer of your choice.
  3. Resuspend cells at 5 - 10 × 106/mL in HHBS or in the azide- and serum/protein-free buffer of your choice.
  4. Add 1 µL of 500X Stain It™ Red 620 stock solution to 0.5 mL of cells/assay and mix it well.
  5. Incubate at room temperature or 37 °C, 5% CO2 incubator for 20 - 60 minutes, protected from light.
    Note     The optimal stain concentrations and incubation time should be experimentally determined for different cell lines.
  6. Wash cells twice and resuspend cells with HHBS or the buffer of your choice.
  7. Fix cells as desired (optional).
  8. Analyze cells with flow cytometer and/or fluorescence microscope using the appropriate Excitation/Emission filter (see Table 1).


Open in Advanced Spectrum Viewer

Spectral properties

Excitation (nm)526
Emission (nm)620
