Live or Dead™ Fixable Dead Cell Staining Kit *Deep Red Fluorescence*


Excitation (nm)
Emission (nm)
Our Live or Dead™ Fixable Dead Cell Staining Kits are a set of tools for labeling cells for fluorescence microscopic investigations of cell functions. The effective labeling of cells provides a powerful method for studying cellular events in a spatial and temporal context. This particular kit is designed to uniformly label fixed mammalian cells in red fluorescence for long term microscopic examination. The kit uses a proprietary red fluorescent dye that is more fluorescent upon bonding to cellular components. The fluorescent dye used in the kit is quite photostable so that the images can be repeatedly examined. The kit provides all the essential components with an optimized cell-labeling protocol. It is an excellent tool for preserving of fluorescent images of particular cells, and can also be used for fluorescence microscope demonstrations.


Flow cytometer

Excitation640 nm laser
Emission660/20 nm filter
Instrument specification(s)APC channel

Fluorescence microscope

Excitation649 nm
Emission660 nm
Recommended plateBlack wall/clear bottom


Component A: Stain It™ Deep Red1 vial
Component B: DMSO1 vial (200 µL)

Example protocol


Protocol summary

  1. Prepare samples in HHBS (0.5 mL/assay)
  2. Replace with HHBS
  3. Add Stain It™ Deep Red to the cell suspension
  4. Stain the cells at room temperature or 37°C for 20 - 60 minutes
  5. Wash the cells
  6. Fix the cells (optional)
  7. Examine the sample with flow cytometer and/or fluorescence microscope using the appropriate Excitation/Emission filter

Important notes
Thaw all the components at room temperature before starting the experiment.


Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles.

1. Stain It™ Deep Red stock solution (500X):
Add 200 µL DMSO (Component B) into the vial of Stain It™ Deep Red (Component A) to have 500X Stain It™ Deep Red stock solution.

For guidelines on cell sample preparation, please visit


Table 1. Fluorescence spectra properties and suggested excitation laser for flow cytometry analysis

Cat. # Description Ex (nm) Em (nm) Excitation Source
22500 Blue Fluorescence with 405 nm Excitation 410 450 405 nm
22501 Green Fluorescence with 405 nm Excitation 408 512 405 nm
22502 Orange Fluorescence with 405 nm Excitation 398 550 405 nm
22599 Red Fluorescence Optimized for Flow Cytometry 523 617 488 nm
22600 Blue Fluorescence 353 442 335 nm
22601 Green Fluorescence 498 521 488 nm
22602 Orange Fluorescence 547 573 561 nm or 488 nm
22603 Red Fluorescence 583 603  561 nm
22604 Deep Red Fluorescence 649 660 633 nm
22605 Near Infrared Fluorescence 749 775  633 nm
  1. Prepare cells using 1X Hanks and 20 mM Hepes buffer (HHBS) or sodium azide-free and serum/protein-free buffer of your choice.

  2. Wash cells once with HHBS or the azide- and serum/protein-free buffer of your choice.

  3. Resuspend cells at 5 - 10 × 106/mL in HHBS or in the azide- and serum/protein-free buffer of your choice.

  4. Add 1 µL of 500X Stain It™ Deep Red stock solution to 0.5 mL of cells/assay and mix it well.

  5. Incubate at room temperature or 37°C, 5% CO2 incubator for 20 - 60 minutes, protected from light. Note: The optimal stain concentrations and incubation time should be experimentally determined for different cell lines.

  6. Wash cells twice and resuspend cells with HHBS or the buffer of your choice.

  7. Fix cells as desired (optional).

  8. Analyze cells with flow cytometer and/or fluorescence microscope using the appropriate Excitation/Emission filter (see Table 1).


Open in Advanced Spectrum Viewer

Spectral properties

Excitation (nm)649
Emission (nm)664
