Cy5®-streptavidin conjugate

Related products
Cy5NS acid
Cy5NS succinimidyl ester
Cy5.5NS, acid
Cy5.5NS succinimidyl ester
Cy5 trans-cyclooctene [Cy5 TCO]
Cy5 tertrazine [Cy5 tertrazine]
Cy5 phosphoramidite
Cy5® goat anti-mouse IgG (H+L)
Cy5® goat anti-mouse IgG (H+L) *Cross Adsorbed*
Cy5® goat anti-rabbit IgG (H+L)
Cy5® goat anti-rabbit IgG (H+L) *Cross Adsorbed*
Cy5 tyramide
Cy5 tetrazine
Cy5DIGE NHS ester
Cy5.5 biotin conjugate
Cy5 aldehyde
Cy5 Dye qPCR Calibration Solution *10,000X*
Cy5 Dye qPCR Calibration Plate *Optimized for ABI7500 Fast 96-Well*
Cy5.5 tetrazine
RPE-iFluor® 647-streptavidin conjugate
RPE-iFluor® 750-streptavidin conjugate
APC-iFluor® 750-streptavidin conjugate
Texas Red®-streptavidin conjugate
trFluor™ Eu-streptavidin conjugate
trFluor™ Tb-streptavidin conjugate
mFluor™ Violet 450-streptavidin conjugate
mFluor™ Violet 510-streptavidin conjugate
mFluor™ Violet 540-streptavidin conjugate
mFluor™ Blue 570-streptavidin conjugate
mFluor™ Green 620-streptavidin conjugate
mFluor™ Yellow 630-streptavidin conjugate
mFluor™ Red 700-streptavidin conjugate
mFluor™ Red 780-streptavidin conjugate
iFluor® 350-streptavidin conjugate
iFluor® 405-streptavidin conjugate
iFluor® 488-streptavidin conjugate
iFluor® 514-streptavidin conjugate
iFluor® 532-streptavidin conjugate
iFluor® 555-streptavidin conjugate
iFluor® 594-streptavidin conjugate
iFluor® 633-streptavidin conjugate
iFluor® 680-streptavidin conjugate
iFluor® 700-streptavidin conjugate
iFluor® 750-streptavidin conjugate
iFluor® 546-streptavidin conjugate
iFluor® 568-streptavidin conjugate
RPE-Cy7-streptavidin conjugate
iFluor® 790-streptavidin conjugate
iFluor® 800-streptavidin conjugate
iFluor® 820-streptavidin conjugate
iFluor® 840-streptavidin conjugate
iFluor® 860-streptavidin conjugate
MegaWox™ polyHRP-Streptavidin Conjugate
RPE-Cy5-streptavidin conjugate
mFluor™ UV455-streptavidin conjugate
mFluor™ Violet 545-streptavidin conjugate
mFluor™ Violet 550-streptavidin conjugate
mFluor™ Violet 590-streptavidin conjugate
mFluor™ Violet 610-streptavidin conjugate
mFluor™ UV420-streptavidin conjugate
Show More (50)
Streptavidin conjugates are widely used together with a conjugate of biotin for specific detection of a variety of proteins, protein motifs, nucleic acids and other molecules since streptavidin has a very high binding affinity for biotin. This Cy5-streptavidin conjugate comprises streptavidin (as the biotin-binding protein) with Cy5 covalently attached (as the fluorescent label). Our Cy5-streptavidin conjugate was prepared using AAT Bioquest's proprietary labeling technology. It demonstrated much brighter signal compared to the similar Cy5-streptavidin conjugates from other commercial sources, thus can significantly increase assay sensitivities. It is commonly used as a second step reagent for indirect immunofluorescent staining, when used in conjunction with biotinylated primary antibodies. It is a valuable tool for biotin-streptavidin-based biological assays and tests using flow cytometry with a Cy5 filter set. A variety of the complementary biotinylated reagents are available from numerous commercial vendors.
HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by Cy5®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by Cy5®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
HeLa cells were incubated with mouse anti-tubulin and biotin goat anti-mouse IgG followed by Cy5®-streptavidin conjugate (Red). Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17530).
Ordering information
Price
Unit size
Catalog Number16913
Quantity
Add to cart
Additional ordering information
Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
ShippingStandard overnight for United States, inquire for international
Request quotation
Physical properties
Molecular weight~52000
SolventWater
Spectral properties
Correction Factor (260 nm)0.02
Correction Factor (280 nm)0.03
Correction Factor (482 nm)0.009
Correction Factor (565 nm)0.09
Extinction coefficient (cm -1 M -1)2500001
Excitation (nm)651
Emission (nm)670
Quantum yield0.271, 0.42
Storage, safety and handling
Certificate of OriginDownload PDF
H-phraseH303, H313, H333
Hazard symbolXN
Intended useResearch Use Only (RUO)
R-phraseR20, R21, R22
StorageFreeze (< -15 °C); Minimize light exposure
UNSPSC12352200
Spectrum
Product family
NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yieldCorrection Factor (260 nm)Correction Factor (280 nm)
Cy5 biotin conjugate65167025000010.271, 0.420.020.03
RPE-streptavidin conjugate56557419600000.82-0.175
APC-streptavidin conjugate651660730000--0.195
PerCP-streptavidin conjugate477678406000--0.22
FITC-streptavidin conjugate491516730000.92-0.35
Cy3®-streptavidin conjugate55556915000010.1510.070.073
Cy7®-streptavidin conjugate7567792500000.30.050.036
XFD350-streptavidin conjugate *XFD350 Same Structure to Alexa Fluor™ 350*34344119000-0.250.19
XFD488-streptavidin conjugate *XFD488 Same Structure to Alexa Fluor™ 488*499520730000.9210.30.11
XFD594-streptavidin conjugate *XFD594 Same Structure to Alexa Fluor™ 594*590618920000.6610.430.56
Show More (1)
Citations
View all 1 citations: Citation Explorer
Overexpression of MACC1 and the association with hepatocyte growth factor/c-Met in epithelial ovarian cancer
Authors: Li, Hongyu and Zhang, Hui and Zhao, Shujun and Shi, Yun and Yao, Junge and Zhang, Yanyan and Guo, Huanhuan and Liu, Xingsuo
Journal: Oncology letters (2015): 1989--1996
References
View all 47 references: Citation Explorer
A streptavidin paramagnetic-particle based competition assay for the evaluation of the optical selectivity of quadruplex nucleic acid fluorescent probes
Authors: Largy E, Hamon F, Teulade-Fichou MP.
Journal: Methods. (2012)
Biotin-4-fluorescein based fluorescence quenching assay for determination of biotin binding capacity of streptavidin conjugated quantum dots
Authors: Mittal R, Bruchez MP.
Journal: Bioconjug Chem (2011): 362
Iminobiotin binding induces large fluorescent enhancements in avidin and streptavidin fluorescent conjugates and exhibits diverging pH-dependent binding affinities
Authors: Raphael MP, Rappole CA, Kurihara LK, Christodoulides JA, Qadri SN, Byers JM.
Journal: J Fluoresc (2011): 647
Streptavidin-Binding Peptide (SBP)-tagged SMC2 allows single-step affinity fluorescence, blotting or purification of the condensin complex
Authors: Kim JH, Chang TM, Graham AN, Choo KH, Kalitsis P, Hudson DF.
Journal: BMC Biochem (2010): 50
Determination of 17beta-oestradiol by fluorescence immunoassay with streptavidin-conjugated quantum dots as label
Authors: Sun M, Du L, Gao S, Bao Y, Wang S.
Journal: Steroids (2010): 400
