Cal-520L®-Dextran Conjugate *MW 10,000*
Overview | ![]() ![]() |
Molecular weight 11000 |
Calcium measurement is critical for numerous biological investigations. Fluorescent probes that show spectral responses upon binding calcium have enabled researchers to investigate changes in intracellular free calcium concentrations by using fluorescence microscopy, flow cytometry, fluorescence spectroscopy and fluorescence microplate readers. Cells may be physically loaded with the cell-impermeant dextran-conjugated calcium indicators using patch pipette or microinjection. The fluorescence signal from these cells is measured using fluorescence microscopy. The dextran forms of our calcium indicators show a dramatic reduction in both leakage and compartmentalization compared to the AM ester forms. Among the fluorescent calcium indicator dextran conjugates, Cal-520 dextran conjugates might be the best choice due to their high fluorescence quantum yield and large fluorescence enhancement by calcium. This Cal-520L dextran exhibits low affinity to calcium ion than Cal-520 dextran, and optimized for monitoring high level calcium ion.
Platform
Fluorescence microscope
Excitation | 498 nm |
Emission | 521 nm |
Recommended plate | Black wall/clear bottom |
Calculators
Common stock solution preparation
Table 1. Volume of Water needed to reconstitute specific mass of Cal-520L®-Dextran Conjugate *MW 10,000* to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 9.091 µL | 45.455 µL | 90.909 µL | 454.545 µL | 909.091 µL |
5 mM | 1.818 µL | 9.091 µL | 18.182 µL | 90.909 µL | 181.818 µL |
10 mM | 909.091 nL | 4.545 µL | 9.091 µL | 45.455 µL | 90.909 µL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Product family
Name | Excitation (nm) | Emission (nm) |
Cal-590™-Dextran Conjugate *MW 10,000* | 563 | 584 |
Cal-590™-Dextran Conjugate *MW 3,000* | 563 | 584 |
Cal-590L® Dextran Conjugate *MW 10,000* | 569 | 590 |
Cal-630™-Dextran Conjugate *MW 10,000* | 609 | 626 |
Cal-630™-Dextran Conjugate *MW 3,000* | 609 | 626 |
Cal-670™-Dextran Conjugate *MW 10,000* | 667 | 680 |
Cal-670™-Dextran Conjugate *MW 3,000* | 667 | 680 |
Cal-770™-Dextran Conjugate *MW 10,000* | 758 | 783 |
Cal-770™-Dextran Conjugate *MW 3,000* | 758 | 783 |
